Sealey MS0630 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Instruction
Manual
1. SAFETY
Maintain the dolly in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Locate the dolly in a suitable work area. Keep area clean and tidy and free from unrelated materials, and ensure that there is adequate
9
lighting.
Ensure that the floor is level and strong enough (preferably concrete) to take the weight of the dolly and the motorcycle.
9
DO NOT use the dolly on tarmacadam, as the surface may be unstable.
8
Keep the dolly clean for best and safest performance.
9
The maximum motorcycle weight is 500kg. DO NOT exceed this rated capacity.
9
Use appropriate straps to secure the motorcycle to the dolly when manoeuvring.
9
Pull rather than push the motorcycle when manoeuvring on the dolly to reduce the risk of pushing the motorcycle off its side stand.
9
Maintain correct balance and footing, DO NOT over reach. Ensure the floor is not slippery and wear non-slip shoes. Keep children and
9
unauthorised persons away from the work area.
DO NOT use the dolly for a task it is not designed to perform.
8
DO NOT use the dolly if it is damaged.
8
DO NOT use the dolly when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT allow untrained persons to use the dolly.
8
DO NOT make any modifications to the dolly.
8
Before storing in safe area, ensure that all parts are clean and free of grease and oil.
9
WARNING!: The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that may
‰
occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied
by the operator.
2. INTRODUCTION
Motorcycle dolly holds a single motorcycle with a side stand, weighing up to 500kg. Easy to manoeuvre around the workshop or garage. Front
wheel stays in contact with the ground allowing the motorcycle to be steered into the desired position. Pivoting feature allows flexibility in side
stand designs. Side stand holder can be adjusted to cater to the majority of motorbikes.
3. SPECIFICATION
Model No. .................................................................MS0630
Max. Capacity ..............................................................500Kg
Overall Dimensions (LxW) ..............................1300 x 650mm
Loading Track Dimensions(L x W x H) ..............550 x 250mm
© Jack Sealey Limited
MOTORCYCLE DOLLY REAR WHEEL - SIDE
STAND TYPE
MS0630
MODEL NO:
Original Language Version MS0630 Issue 1 24/02/21
