Technical Specifications
5.6 Operating Environment
5.6

Operating Environment

The RUGGEDCOM RS900 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.7

Mechanical Specifications

Weight
Ingress Protection
Enclosure
5.8

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
28
-40 to 85 °C (-40 to 185 °F)
a
-40 to 85 °C (-40 to 185 °F)
b
5% to 95%
2000 m (6562 ft)
1.2 kg (2.7 lbs)
IP30
20 AWG Galvanized Steel
RUGGEDCOM RS900
Installation Manual, 04/2022, C79000-G8976-1024-14
