Installing the Device
2.4.1 Mounting the Device on a DIN Rail
Note
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with either DIN rail or panel hardware installed,
refer to
2.4.1
Mounting the Device on a DIN Rail
The RUGGEDCOM RS900 can be ordered with a DIN rail adapter preinstalled on the
back of the chassis. Use the adapter to mount the device to a standard 35 mm (1.4
in) IEC/EN 60715 or TS35 DIN rail.
8
"Dimension Drawings (Page
28)".
Installation Manual, 04/2022, C79000-G8976-1024-14
RUGGEDCOM RS900
