ASFC Settings

Power supply

The jumper settings at connectors X7 and X8 define the voltage level as follows.
Voltage
230 VAC
115 VAC

Charging circuit monitoring

For each inverter module in the system (one to three) there is a charging current
monitoring on the ASFC unit. Switch S1 enables the monitoring for inverter 1, S2 for
inverter 2 and S3 for inverter 3. All enabled monitoring circuits must detect current
less than 0.7 A (= capacitor bank nearly full) to allow the release of the switch fuse
locking solenoid and to allow the inverter power switch-on.
Switch
S1
S2
S3
Note: The ASFC unit does not control the main contacts of the switch fuse closed
unless at least one of switches S1 to S3 is in enabled position.
X7
1 2 3 4 1
Position Description
DIS Inverter 1 charging current monitoring is disabled and Inverter 1 start is
disabled (no INV1 EN signal is allowed)
EN Inverter 1 charging current monitoring is enabled and Inverter 1 start is
enabled (INV1 EN signal sent after charging is completed)
DIS Inverter 2 charging current monitoring is disabled and Inverter 2 start is
disabled (no INV2 EN signal allowed)
EN Inverter 2 charging current monitoring is enabled and Inverter 2 start is
enabled (INV2 EN signal sent after charging is completed)
DIS Inverter 3 charging current monitoring is disabled and Inverter 3 start is
disabled (no INV3 EN signal allowed)
EN Inverter 3 charging current monitoring is enabled and Inverter 3 start is
enabled (INV3 EN signal sent after charging is completed)
X8
2 3 4
