Circuit diagrams of inverter power supply equipped
with switch fuse

What this chapter contains

This chapter shows the connections between one switch fuse, one Switch Fuse
Control Unit (ASFC) and one, two or three inverters. In each case, the diagrams also
show the appropriate ASFC settings (switches S1...S3, jumpers X7 and X8).
