Installation

What this chapter contains

This chapter instructs how to install the ASFC unit into a user-defined cabinet.

Planning the installation of the ASFC unit

Placing
Install the ASFC unit in a heated indoor environment. Ensure the temperature meets
the requirement given in chapter
conditions meet the requirements of ACS800-104 inverter modules. See ACS800-
104 Inverter Module Hardware Manual (3AFE64809032 [English].
Do not install the ASFC unit far from the inverters. The fibre optic cable(s) between
the unit and inverter(s) may not exceed four metres in length.
No condensation is allowed. There are connectors that are connected to drive main
circuit potential.

Cable selection

See ACS800-104 Inverter Module Hardware Manual (3AFE64809032 [English]).
Always follow the specification given by ABB. The cables are connected to drive
main circuit potential.
Protecting against contact
Protect the ASFC unit against accidental contact. There are connectors that are
connected to drive main circuit potential.
Installation
Technical data. Also ensure that the ambient
