Lossnay Signal Output Terminal
MODEL:
PZ-4GS-E
Installation and Instruction Manual
■ This manual must be read both fully and carefully before commencing installation procedures; furthermore, the subsequent installation must be
performed correctly and safely in accordance with the instructions given.
■ Be sure to give this instruction manual to the customer once installation is complete.
1. Safety Precautions
WARNING
- Use a dedicated circuit for the equipment to be connected, and use the voltage and breaker appropriate for the connected load.
- Connected equipment should be used within the rated voltage and control capacity range.
- Never modify or repair by yourself.
If the product is modified or inappropriately repaired, electric shock, fire, etc. could result. Contact your dealer for repair.
- Do not move or reinstall the product by yourself.
If it is installed improperly, electric shock, fire, etc. could result. Contact your dealer or technical representative.
- Use the specified cables for wiring and connect them securely. Hold the cables so as not to apply external force of the cables to the
Terminal block of this product.
Improper connection could result in heat generation or fire.
- All electrical work must be performed by a licensed technician, according to local regulations and the instructions given in this Installation
manual.
- Ensure that installation work is done correctly following this Installation manual.
If it is installed improperly, electric shock, fire, etc. could result.
- Close the control cover after installation.
- Do not install the product in a place where flammable gases may leak.
If gas should leak or accumulate around the product, fire or explosion could result.
- Do not use the product in special environments.
The product could be damaged if it is used in locations subject to large quantities of oil (including machine oil), steam, or sulfide gas.
- Do not install the unit in a place where the temperature rises above 40 ˚C (104 °F), where large amounts of oil, steam, organic solvents, or
corrosive gases, such as sulfuric gas, are present, or where acidic/alkaline solutions or sprays are used frequently.
These substances can compromise the performance of the unit or cause certain components of the unit to corrode, which can result in electric
shock, malfunctions, smoke, or fire.
CAUTION
- Wire so that it does not receive any tension.
Tension could cause wire breakage, heating or fire.
- Put on gloves during installation.
Failure to do so could cause injury.
2. Dimensional Outline Drawing
53 (2 3/32)
Incorrect handling could cause serious injury or death.
Incorrect handling could cause injury or damage to property or household effects.
■ Accessory Parts
60 (2 23/64)
Installation screws (cross recessed truss screws M4 x 8): 2
Connection cable (for connecting with the Lossnay unit): 1
Note:
• Do not damage the circuit board during unpacking.
Unit: mm (inch)
