EnergyWise
Wi-Fi Switch User Manual
©2015 Duke Energy Corporation SBDR1509 11/15
Business
®
Look inside for a complete guide to the setup
and operation of your new Wi-Fi
Installed by: ____________________________________________
Date: __________________________________________________
Number of Wi-Fi switches: ______________________________
Notes: ________________________________________________
switch.
®

Advertisement

loading

Related Manuals for Duke Energy EnergyWise Business

Summary of Contents for Duke Energy EnergyWise Business

  • Page 1 ® Wi-Fi Switch User Manual Look inside for a complete guide to the setup and operation of your new Wi-Fi switch. ® Installed by: ____________________________________________ Date: __________________________________________________ Number of Wi-Fi switches: ______________________________ Notes: ________________________________________________ ©2015 Duke Energy Corporation SBDR1509 11/15...
  • Page 2 EnergyWise Business Wi-Fi Switch Applications Guide ® EnergyWise Business is available to customers of Duke Energy Carolinas and Duke Energy Progress. EnergyWise Business Wi-Fi switch can be installed to control the following loads. Description It requires connection to line power and must be installed by a trained, experienced technician.
  • Page 3 Link LED The Link LED is used to indicate the status of the communication link. When it stays on solid, it indicates good end-to-end communication with the controlling software system. If any link along the communication chain is lost, the LED will blink in different patterns as shown below.
  • Page 4 Hardware Error Reporting If the EnergyWise Business Wi-Fi switch hardware senses an error that prevents normal operation of the switch, then all LEDs will flash as an indicator of this condition. If this happens repeatedly, then the switch should be replaced.
  • Page 5 Please follow the steps below to reset the credentials stored in EnergyWise Business Wi-Fi switch: 1. Note the serial number of EnergyWise Business Wi-Fi switch. There should be a serial label on the side of the product. Note the last four digits of the serial number.
  • Page 6 5. If the settings page does not appear after a few seconds, type “directlink/settings” in the address bar, and then press ENTER. 6. Use the pull-down on the 7. If your Wi-Fi router is set to settings page to select your hide the network name, or user network name.

  • Page 7: Specifications

    Specifications Power Input 120VAC – 240VAC auto-ranging Power Consumption Less than 12 VA Operating Condition -35° to +85° C, 0% - 95% humidity (non-condensing) Regulatory FCC part 15; UL 916 Relay Rating/Cycles 2 Function (2F): 24VAC, 2 Amp 1 Function (1F): 240VAC, 30 Amp Resistive Electrical Endurance: 250,000 cycles at rated worst-case loads Mechanical Endurance: 10 million cycles at...
