Panasonic SA-AKX12PH Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Stereo System
  5. SA-AKX12PH
  6. Service manual

Panasonic SA-AKX12PH Service Manual

Hide thumbs Also See for SA-AKX12PH:
Table of Contents

Advertisement

Quick Links

Download this manual
Please refer to the original service manual for:
CD Mechanism Unit (BRS1C), Order No. PSG1102001CE
Speaker system SB-AKX12PN-K, Order No. PSG1102026CE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Use (For PH only)-------------------------------- 3
1.3. Caution For Fuse Replacement------------------------ 3
1.4. Before Repair and Adjustment ------------------------- 4
1.5. Protection Circuitry ---------------------------------------- 4
1.6. Safety Parts Information --------------------------------- 5
2 Warning -------------------------------------------------------------- 6
2.2. Precaution of Laser Diode------------------------------- 7
3 Service Navigation ----------------------------------------------11
Model No.
Product Color: (K)...Black Type
PAGE
3.1. Service Information -------------------------------------- 11
4 Specifications ---------------------------------------------------- 12
5.1. Main Unit Key Button Operation---------------------- 13
5.3. Media Information---------------------------------------- 15
6.1. Cold-Start -------------------------------------------------- 16
6.2. Doctor Mode Table--------------------------------------- 17
(BRS1C))--------------------------------------------------- 20
6.4. Self-Diagnostic Mode ----------------------------------- 21
© Panasonic Corporation 2011. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
CD Stereo System
SA-AKX12PH
SA-AKX12PN
PSG1102024CE
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-AKX12PH

Summary of Contents for Panasonic SA-AKX12PH

  • Page 1: Table Of Contents

    2.4. Handling Precautions for Traverse Unit-------------- 9 6.5. Self-Diagnostic Error Code Table -------------------- 21 3 Service Navigation ----------------------------------------------11 6.6. Sales Demonstration Lock Function ---------------- 22 © Panasonic Corporation 2011. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 7 Troubleshooting Guide---------------------------------------- 23 16.4. Panel, LCD, Remote Sensor & USB Circuit ------ 85 7.1. Troubleshooting Guide for F61 and/or F76 -------- 23 16.5. Tuner & Voltage Selector Circuit--------------------- 86 7.2. Part Location ---------------------------------------------- 24 16.6. SMPS Circuit---------------------------------------------- 87 7.3. D-Amp IC Operation & Control ----------------------- 26 17 Printed Circuit Board------------------------------------------ 89 8 Disassembly and Assembly Instructions --------------- 28 17.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 4: Before Repair And Adjustment

    1.4. Before Repair and Adjustment Disconnect AC power to discharge unit AC Capacitors as such (C5700,C5701, C5703, C5704, C5705, C5708) through a 10 Ω, 10 W resistor to ground. Caution: DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices. After repairs are completed, restore power gradually using a variac, to avoid overcurrent.

  • Page 5: Safety Parts Information

    1.6. Safety Parts Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.

  • Page 6: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...

  • Page 7: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 µW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 8: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 9: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.
  • Page 10 Grounding for electrostatic breakdown prevention 2.4.2. Some devices such as the DVD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electric- ity in the working environment. Proceed servicing works under the working environment where grounding works is completed. 2.4.2.1.

  • Page 11: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 12: Specifications

    2. Total harmonic distortion is measured by the digital spectrum analyzer. AMPLIFIER SECTION System: SC-AKX12PH-K RMS output power stereo mode Main Unit: SA-AKX12PH-K Front (both channels driven) Front Speakers: SB-AKX12PN-K 125 W per channel (4 Ω), 1 kHz, 10% THD System: SC-AKX12PN-K...

  • Page 13: Location Of Controls And Components

    5 Location of Controls and Components 5.1. Main Unit Key Button Operation Standby/on switch ( /l, POWER) Press to switch the unit from on to standby mode or vice versa.In standby mode, the unit is still consuming a small amount of power.

  • Page 14: Remote Control Key Button Operation

    5.2. Remote Control Key Button Operation SLEEP PLAY EXT -IN RADIO SOUND D.BASS PRESET EQ DISPLA Y DIMMER AUTO OFF...

  • Page 15: Media Information

    5.3. Media Information...

  • Page 16: Self-Diagnostic And Special Mode Setting

    6 Self-Diagnostic and Special Mode Setting 6.1. Cold-Start Here is the procedure to carry out cold-start or initialize to shipping mode. 1. Unplug AC power cord 2. Press & hold [POWER] button 3. Plug AC power cord while [POWER] button being pressed FL Display will show “_ _ _ _ _ _ _ _”...

  • Page 17: Doctor Mode Table

    6.2. Doctor Mode Table 6.2.1. Doctor Mode Table 1 Item Key Operation FL Display Mode Name Description Front Key Doctor Mode To enter into Doctor Mode In CD Mode: 1. Press [ ] button on main unit follow by [4] and [7] on remote control.
  • Page 18 6.2.2. Doctor Mode Table 2 Item Key Operation FL Display Mode Name Description Front Key Volume Setting To check the volume setting of a main In Doctor Mode: Check unit. 1. Press [7], [8], [9] button on remote control. Press [7]: VOL50 Volume Press [8]: VOL35 Press [9]: VOL0...
  • Page 19 6.2.3. Doctor Mode Table 3 Item Key Operation FL Display Mode Name Description Front Key i. Function: To display result of In Doctor Mode: Self- Adjustment self-adjustment for CD. 1. Press [10] [4] button on remote control. (AJST) This is used for servicing Result Display and analysis.

  • Page 20: Reliability Test Mode (Cd Mechanism Unit (Brs1C))

    6.3. Reliability Test Mode (CD Mechanism Unit (BRS1C)) Below is the process flow chart of the aging test for the CD Mechanism Unit (BRS1C). OPEN First Track Operation Access OPEN wait First Track fot 1 s Play 5 s CLOSE Last Track Operation Access...

  • Page 21: Self-Diagnostic Mode

    6.4. Self-Diagnostic Mode Item Key Operation FL Display Mode Name Description Front Key Self Diagnostic To enter into self diagnostic checking Step 1: Select CD mode Mode (Ensure no disc is inserted). Step 2: Press & hold [ ] follow by ] on main unit for 2 seconds.

  • Page 22: Sales Demonstration Lock Function

    6.5.2. CD Mechanism Error Code Table (CD Mechanism Unit (BRS1C)) Error Code Diagnostic Contents Description of error Automatic FL Display Remarks CD H15 CD Open Abnormal During operation Press [ ] on main unit for POS_SW_R On fail to be next error.

  • Page 23: Troubleshooting Guide

    7 Troubleshooting Guide 7.1. Troubleshooting Guide for F61 and/or F76 This section illustrates the checking procedures when upon detecting the error of “F61” and/or “F76” after power up of the unit. It is for purpose of troubleshooting and checking in SMPS & Main P.C.B. Symptom Checking Items Possible Fault(s)

  • Page 24: Part Location

    7.2. Part Location 7.2.1. SMPS P.C.B. AC Inlet: P5701 Fuse: Switching Regulator IC: IC5799 Switching Regulator IC: Thermistor: IC5701 TH5860 Photocoupler: PC5702, PC5799 Rectifier Diode D5801, D5802 Photocoupler: PC5720 Connector: Transformer: CN5802 T5701 Fig. 1 SMPS P.C.B.
  • Page 25 7.2.2. Main P.C.B. Audio Digital Amp IC: IC5902 Cable wire: ZJ2002 Voltage Regulator IC: IC2010 Switching Regulator IC: IC2011 Fig. 2 Main P.C.B.

  • Page 26: D-Amp Ic Operation & Control

    7.3. D-Amp IC Operation & Control...
  • Page 27 1170 ~ 1250 1260 ~ 1450 1460 ~ 1540 1550 ~ 1710 Table 4: F_HOP Control during 10 kHz Step Note: During activating, the 3 control pins namely MUTE_F, MUTE_A and MODE_DA must be used to cover the “Pop” sound cause by F-HOP switching.

  • Page 28: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions • Illustration is based on SA-AKX12PH-K. Caution Note: • This section describes the disassembly and/or assembly procedures for all major printed circuit boards & main compo- nents for the unit. (You may refer to the section of “Main components and P.C.B Locations” as described in the service manual) •...

  • Page 29: Disassembly Flow Chart

    8.1. Disassembly Flow Chart 8.3. Top Cabinet 8.20. CD Mechanism Unit 8.4. Tuner P.C.B. 8.11. Main P.C.B. (BRS1C) 8.5. Front Panel 8.21. Rear Panel 8.12. Voltage Regulator Unit IC (IC2010) 8.22. Voltage Selector P.C.B. 8.13. Audio Digital Amp 8.6. Panel P.C.B. IC (IC5902) 8.7.

  • Page 30: Main Components And P.c.b. Locations

    8.2. Main Components and P.C.B. Locations...

  • Page 31: Disassembly Of Top Cabinet

    8.3. Disassembly of Top Cabinet Step 4 Slightly lift up both side of Top Cabinet in an outward direction as shown. Step 1 Remove 2 screws on each side. Step 5 Remove Top Cabinet. Step 2 Remove 5 screws. Step 3 Slightly pull both side of Top Cabinet outwards as arrow shown.

  • Page 32: Disassembly Of Tuner P.c.b

    8.4. Disassembly of Tuner P.C.B. 8.5. Disassembly of Front Panel Unit • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 1 screw. Step 1 Detach 17P FFC at the connector (CN2003) on Main P.C.B.
  • Page 33 Step 4 Release tabs at bottom. Step 6 Remove Front Panel Unit Step 5 Push inwards slightly at the Bottom Chassis and release tab at right side of Front Panel Unit.

  • Page 34: Disassembly Of Panel P.c.b

    8.6. Disassembly of Panel P.C.B. Step 4 Release catches by following the sequences (1-3). • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove the Volume Knob. Step 2 Remove the Track Knob. Step 5 Remove the Panel P.C.B.

  • Page 35: Disassembly Of Remote Sensor P.c.b

    Step 6 Desolder 7 pins at (ZJ600B) on Panel P.C.B.. 8.7. Disassembly of Remote Sensor Step 7 Remove the Panel P.C.B.. P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to (Step 1) to (Step 5) of item 9.6.. Step 1 Remove Remote Sensor P.C.B..

  • Page 36: Disassembly Of Lcd P.c.b

    8.8. Disassembly of LCD P.C.B. Caution: During assembling, ensure that LCD Unit is prop- erly located & seated onto the guides. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove 2 screws. Step 2 Lift up LCD Unit.

  • Page 37: Disassembly Of Usb P.c.b

    8.9. Disassembly of USB P.C.B. 8.10. Disassembly of CD Lid • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove 2 screws.

  • Page 38: Disassembly Of Main P.c.b

    8.11. Disassembly of Main P.C.B. Step 3 Remove 2 screws. Step 4 Detach Main P.C.B. from Rear Panel according to arrow • Refer to “Disassembly of Top Cabinet”. shown. • Refer to “Disassembly of Front Panel Unit”. Step 1 Detach 15P Cable Wire at the connector (CN5802) on SMPS P.C.B..

  • Page 39: Replacement Of Voltage Regulator Ic (Ic2010)

    Step 5 Detach 27P FFC at the connector (CN2706) on Main 8.12. Replacement of Voltage Regu- P.C.B.. lator IC (IC2010) Step 6 Detach 9P FFC at the connector (CN2010) on Main P.C.B.. • Refer to “Disassembly of Main P.C.B.”. Step 7 Remove Main P.C.B.. 8.12.1.

  • Page 40: Replacement Of Audio Digital Amp Ic (Ic5902)

    8.12.2. Assembly of Voltage Regulator IC 8.13. Replacement of Audio Digital (IC2010) Amp IC (IC5902) Step 1 Apply grease to the Heatsink. • Refer to “Disassembly of Main P.C.B.”. Step 2 Fix the Voltage Regulator IC (IC2010) on Main P.C.B.. 8.13.1.
  • Page 41 Step 3 Remove Heatsink Clip. Step 4 Solder pins of the Audio Digital Amp IC (IC5902) on the Step 4 Remove Audio Digital Amp IC (IC5902). solder side of Main P.C.B.. 8.13.2. Assembly of Audio Digital Amp IC (IC5902) Step 1 Apply grease to the Heatsink. Step 2 Fix the Audio Digital Amp IC (IC5902) on Main P.C.B.

  • Page 42: Disassembly Of Smps P.c.b

    8.14. Disassembly of SMPS P.C.B. Step 4 Flip the SMPS P.C.B. and position it according to dia- gram shown. • Refer to “Disassembly of Top Cabinet.”. Step 5 Place SMPS P.C.B. on an insulated material. • Refer to “Disassembly of Front Panel Unit”. Step 6 Desolder 2 Wire pins, TL7 (Black), TL8 (Red) wires pin.

  • Page 43: Replacement Of Switching Regulator Ic (Ic5701)

    8.15. Replacement of Switching Reg- Step 2 Remove 1 screw. Step 3 Remove the Switching Regulator IC (IC5701). ulator IC (IC5701) Caution: Avoid touching the Heatsink A due to its high temperature after prolonged use. Touching it may lead to •...

  • Page 44: Replacement Of Rectifier Diode (D5702)

    Step 4 Solder pins of the Switching Regulator IC (IC5701) on 8.16. Replacement of Rectifier Diode the solder side of SMPS P.C.B.. (D5702) • Refer to “Disassembly of SMPS P.C.B.”. 8.16.1. Disassembly of Rectifier Diode (D5702) Step 1 Desolder pins of the Rectifier Diode (D5702) on the sol- der side of SMPS P.C.B.
  • Page 45 Step 3 Remove 1 screw at Switching Regulator IC (IC5701). 8.16.2. Assembly of Rectifier Diode Step 4 Remove the Heatsink A with Rectifier Diode (D5702). (D5702) Step 5 Remove 1 screw. Step 1 Apply grease to the Heatsink A. Step 6 Remove the Rectifier Diode (D5702) from the Heatsink Step 2 Screw the Rectifier Diode (D5702) to the Heatsink A.

  • Page 46: Replacement Of Rectifier Diode (D5801)

    Step 5 Solder pins of the Rectifier Diode (D5702) on the solder 8.17. Replacement of Rectifier Diode side of SMPS P.C.B.. (D5801) Step 6 Solder pins of the Heatsink A on the solder side of SMPS P.C.B.. • Refer to “Disassembly of SMPS P.C.B.”. Caution: Ensure pins of the Rectifier Diode (D5702) are properly seated and soldered on SMPS P.C.B..

  • Page 47: Replacement Of Rectifier Diode (D5802)

    8.17.2. Assembly of Rectifier Diode 8.18. Replacement of Rectifier Diode (D5801) (D5802) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix the Rectifier Diode (D5801) on SMPS P.C.B. Caution: Ensure pins of the Rectifier Diode (D5801) is properly inserted on SMPS P.C.B.

  • Page 48: Replacement Of Regulator Diode (D5803)

    8.18.2. Assembly of Rectifier Diode 8.19. Replacement of Regulator (D5802) Diode (D5803) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix the Rectifier Diode (D5802) on SMPS P.C.B.. Caution: Ensure pins of the Rectifier Diode (D5802) is properly inserted on SMPS P.C.B.

  • Page 49: Disassembly Of Cd Mechanism Unit (Brs1C)

    8.19.2. Assembly of Rectifier Diode 8.20. Disassembly of CD Mecha- (D5803) nism Unit (BRS1C) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of Top Cabinet”. Step 2 Fix Rectifier Diode (D5803) on SMPS P.C.B. • Refer to “Disassembly of Front Panel Unit”. Caution: Ensure pins of the Rectifier Diode (D5803) are properly inserted on SMPS P.C.B.
  • Page 50 Step 3 Remove 3 screws. Step 5 Lift up and remove SMPS Inner Chassis Unit. Caution: During assembling, ensure that SMPS Inner Chassis is catched onto Rear Panel properly. Step 4 Detach Voltage Selector P.C.B. from Rear Panel as arrow shown.

  • Page 51: Disassembly Of Rear Panel

    Step 6 Remove 2 screws. 8.21. Disassembly of Rear Panel • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Tuner P.C.B.”. Step 1 Remove 8 screws. Step 2 Detach Voltage Selector P.C.B. from Rear Panel as arrow shown. Step 7 Lift up &...

  • Page 52: Disassembly Of Voltage Selector P.c.b

    Step 3 Lift up SMPS Inner Chassis Unit to release the catch 8.22. Disassembly of Voltage Selec- between the SMPS Inner Chassis Unit & the Rear Panel. tor P.C.B. • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 1 screw. Step 4 Release 2 tabs.
  • Page 53 Step 3 Desolder 2 Wire pins, TL5 (Black), TL6 (Red) on the Voltage Selector P.C.B.. Step 4 Remove Voltage Selector P.C.B..

  • Page 54: Replacement Of Traverse Unit

    9 Replacement of Traverse Unit 9.1. Disassembly of Traverse Unit Step 2: Slide the tray out fully. • Refer to “Disassembly of CD Mechanism Unit (BRS1C)”. Caution: Refer to “2.4 Handling Precaution for Traverse Unit” to prevent static damage to the Optical Pickup Unit. Note: 1.
  • Page 55 Step 4: Release the guide as shown & slide the Traverse Slide Step 6: Lift the Traverse Unit by approximately 45°. Plate to the end. Step 7: Slide out the traverse unit as arrow shown. Step 5: Detach 5P FFC at the connector (CN7003) on CD Servo P.C.B..

  • Page 56: Assembly Of Traverse Unit

    9.2. Assembly of Traverse Unit Step 2: Slot the Traverse Unit at approximately 45° into the mecha chassis as arrow shown. Step 1: Release the guide as shown & slide the Traverse Slide Plate to the end.
  • Page 57 Step 3: Ensure the Traverse Unit seated properly onto the Step 6: Slide the Traverse Slide Plate unit it stop at the Guide. Groove. Step 7: Slot the Tray into the guides as Picture shown. Step 4: Slide Traverse Slide Plate to lock the Traverse Unit as shown.

  • Page 58: Disassembly Of Cd Servo P.c.b

    Step 8: Ensure the guides is align with the groove when sliding 9.3. Disassembly Servo the tray in. P.C.B. • Refer to “Disassembly of CD Mechanism Unit (BRS1C)”. • Refer to “Replacement of Traverse Unit”. Caution: It is required to short the circuit. Step 1: Solder the 3 solder points.
  • Page 59 Caution 2: During assembling, desolder the solder points. Step 5 Slightly lift up the CD Servo P.C.B. Step 6 Flip the CD Servo P.C.B. Step 2 Remove 3 screws. Step 3 Desolder 4 pins. Step 4 Detach 5P FFC at the connector (CN7003) on CD Servo P.C.B..
  • Page 60 Step 9 Ground the 24P FFC with a short pin.

  • Page 61: Service Position

    10 Service Position 10.2. Checking and Repairing of Panel P.C.B. Note: For description of the disassembly procedures, see the Section 9. Step 1 Remove Top Cabinet. Step 2 Remove Front Panel Unit. 10.1. Checking and Repairing of Step 3 Attach 5P Cable Wire to the connector (CN1113) on Main P.C.B.

  • Page 62: Checking And Repairing Of Lcd P.c.b

    10.3. Checking and Repairing of LCD 10.4. Checking and Repairing of P.C.B. SMPS P.C.B. Step 1 Remove Top Cabinet. Step 1 Remove Top Cabinet. Step 2 Remove Front Panel Unit. Step 2 Remove Front Panel Unit. Step 3 Position LCD Unit on the insulated material as shown. Step 3 Remove SMPS P.C.B..

  • Page 63: Checking And Repairing Of Cd Servo P.c.b

    10.5. Checking and Repairing of CD Servo P.C.B. Step 1 Remove Top Cabinet. Step 2 Remove Front Panel Unit. Step 3 Remove SMPS Chassis Unit. Step 4 Remove CD Mechanism Unit (BRS1C). Step 5 Position Front Panel Unit, SMPS Chassis Unit as dia- gram shown.

  • Page 64: Voltage & Waveform Chart

    Measuring instrument and its measuring condition and product itself. 11.1. CD Servo P.C.B. IC7002 REF NO. MODE CD PLAY IC7002 REF NO. MODE CD PLAY IC7851 REF NO. MODE CD PLAY REF NO. Q7601 MODE CD PLAY SA-AKX12PH/PN CD SERVO P.C.B.

  • Page 65: Main P.c.b. (1/2)

    POWER ON 5.2 STANDBY IC2010 REF NO. MODE POWER ON 16.6 12.1 STANDBY 16.6 12.1 IC2011 REF NO. MODE POWER ON 16.7 STANDBY 16.7 Q2011 Q2014 Q2015 Q2022 Q2035 REF NO. MODE POWER ON 35.2 STANDBY 35.2 SA-AKX12PH/PN MAIN P.C.B.

  • Page 66: Main P.c.b. (2/2)

    Q5901 REF NO. MODE CD PLAY 12.1 12.1 -35.0 -35.1 STANDBY 12.1 12.1 -35.0 -35.1 Q5902 Q5903 Q5904 Q5905 QR2400 REF NO. MODE CD PLAY STANDBY QR2402 QR5900 QR5901 REF NO. MODE CD PLAY -34.6 STANDBY -34.6 SA-AKX12PH/PN MAIN P.C.B.

  • Page 67: Lcd P.c.b

    POWER ON 3.3 STANDBY IC900 REF NO. MODE POWER ON 1.4 STANDBY IC900 REF NO. MODE POWER ON 1.4 STANDBY Q900 REF NO. MODE POWER ON STANDBY SA-AKX12PH/PN LCD P.C.B. 11.5. Tuner P.C.B. IC52 REF NO. MODE TUNER SA-AKX12PH/PN TUNER P.C.B.

  • Page 68: Smps P.c.b

    POWER ON 1.2 STANDBY Q5720 Q5721 Q5722 Q5860 Q5861 REF NO. MODE POWER ON 7.3 19.7 19.7 19.0 19.6 35.2 STANDBY 19.7 19.7 19.0 19.6 35.2 Q5862 Q5898 QR5801 QR5802 QR5810 REF NO. MODE POWER ON -3.0 STANDBY -2.9 SA-AKX12PH/PN SMPS P.C.B.

  • Page 69: Waveform Table

    11.7. Waveform Table 0.1Vp-p(200usec/div) 0.2Vp-p(100usec/div) 2Vp-p(10usec/div) 3Vp-p(20usec/div) 3.6Vp-p(200usec/div) 1.4Vp-p(1msec/div) 0.1Vp-p(200usec/div) 1.3Vp-p(200usec/div) 100Vp-p(1usec/div) 1.5Vp-p(500usec/div)

  • Page 70: Illustration Of Ics, Transistor And Diode

    12 Illustration of ICs, Transistor and Diode RFKWMAK12M0 C1BB00001151 (32P) C0HBA0000295 (44P) C3EBFY000006 (8P) C1BA00000497 (23P) VUEALLPT031 (20P) (100P) No.1 No.1 No.1 No.1 MN6627947RB C0GBY0000117 C0AABB000125 (8P) MIP2F20MSSCF (8P) C0DBFYY00049 C3EBFC000042 (144P) No.1 C0DAAYG00001 (5P) C0DABFC00002 B1ABGC000005 B1ABCF000176 C5HACYY00004 (7P) C0CAAKG00046 B1ADCE000012 B1GBCFJJ0051...

  • Page 71: Simplified Block Diagram

    13 Simplified Block Diagram 13.1. Overall Simplified Block Diagram...

  • Page 72: Power Block Diagram

    13.2. Power Block Diagram Subwoofer AMP (15mA) FROM Headphone SMPS Amp (15mA) +/-VCC = 35V, DIGITAL AMP IC (NXP) Bi-AMP filter (15mA) IC2010 +18V 245mA Regulator (11.5V ~ 19V) +12V (403mA) 1A Max BACKUP Reg4 +3.3V 200mA 9.9V 7.5V CD module motor +7.5V (200mA) discrete...

  • Page 73: Block Diagram

    CD CLOSE SW CD CLOSE SW CD CLOSE SW CN7003 SW OPEN CD OPEN SW CN7002 CN2706 CD OPEN SW CD OPEN SW CD OPEN SW NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN SERVO & SYSTEM CONTROL BLOCK DIAGRAM...

  • Page 74: Audio

    ASP DATA MUTING 19 SDA 23 MODE CIRCUIT MUTE F MUTE F ASP CLK ASP CLK 18 SCL TH5900 CD-L CD-L 8 DIFFL CD-R CD-R 6 DIFFR DC DET AMP DC DET AMP DC DETECT Q5904,Q5905 SA-AKX12PH/PN AUDIO BLOCK DIAGRAM...

  • Page 75: Power Supply

    TUNER P.C.B. Q2035 D5725 SMPS BP FROM SERVO & FEEDBACK BEATPROOF SMPS BP SYSTEM CONTROL CIRCUIT CIRCUIT FOR PH FOR PN IC5801 C0DABFC00002 SHUNT REGULATOR COLD NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN POWER SUPPLY BLOCK DIAGRAM...

  • Page 76: Wiring Diagram

    CN7003 (SOLDER SIDE) (SOLDER SIDE) CN6006 TL6* TL5* S5701 SENSOR FM ANT AM ANT IR6000 FOR DEBUG TO LOADING MOTOR PCB (CD MECHANISM UNIT BRS1C) VOLT ADJ NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX12PH/PN WIRING CONNECTION DIAGRAM...

  • Page 77: Schematic Diagram

    16 Schematic Diagram • For PH only 16.1. Schematic Diagram Notes • This schematic diagram may be modified at any time with the development of new technology. Notes: S5701: Voltage ADJ switch (For PH only). S6001: Power switch ( S6002: USB switch.

  • Page 79: Cd Servo Circuit

    LASER DRIVE R7601 C7601 C7670 C7230 R7221 0.01 0.01 LDSW K7101 R7207 C7239 R7220 D7650 AGND X7201 B0BC5R6A0266 R7214 H2D169500017 X7205 C7226 C7231 H0J120500076 1000P 6.3V47 C7225 1000P C7253 C7227 C7228 C7205 C7206 C7626 C7233 1000P 0.01 SA-AKX12PH/PN CD SERVO CIRCUIT...
  • Page 80 CD_CLOSE_SW C7207 D7341 D7342 D7343 C7341 B0ECKM000016 B0ECKM000016 B0ECKM000016 C7751 6.3V47 CN7003 SW_CLOSE C7334 10V100 LOADING MOTOR P.C.B. SW_OPEN (CD MECHANISM UNIT BRS1C) LDM- C7335 LDM+ 0.01 NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN CD SERVO CIRCUIT...

  • Page 81: Main Circuit

    5600P K2706 SWITCH SGND R2362 C2246 470K C2138 R2351 5600P R2349 Q2038 Q2051 100K R2364 R2360 C2244 R2357 2.2K B1ABCF000176 100K 4.7M B1ADCE000012 SWITCH R2131 CLIP SENSING R2376 D2301 R2347 B0ACCK000012 8.2K R2128 TO MAIN CIRCUIT (3/4) SA-AKX12PH/PN MAIN CIRCUIT...
  • Page 82 1.5K B1GBCFJJ0051 Q5900 B1ABCF000176 SWITCH B1ABGC000005 DC DETECT SWITCH R5909 R5927 C5946 6.8K 10V100 R5918 2.7K Q5901 R5914 B1ADCE000012 SWITCH R5920 2.7K Q5902 R5917 B1ABCF000176 R5915 SWITCH MOD_DA R5919 Q5903 MUTE_F B1ABCF000176 SWITCH TO MAIN CIRCUIT (4/4) SA-AKX12PH/PN MAIN CIRCUIT...
  • Page 83 FL-GND 4.7K FL-GND ROTARY_JOG ROTARY_JOG C2150 Q2014 R2214 KEY1 KEY1 50V3.3 B1GBCFLL0037 KEY2 KEY2 PCONT PCONT UP_DGND CN2002 MM0D0 R2096 MMOD X2001 H2B800400007 NRST R2095 MICORST OCD_SCK OCD_SDL FOR DEBUG R2093 3.9K OCD_SDA R2094 3.9K OCD_SDA SYS3.3V SA-AKX12PH/PN MAIN CIRCUIT...
  • Page 84 G0A101ZA0028 C2215 0.47 R2309 R2311 2.7K 1.5K VOUT R2334 R2337 R2339 R2341 CD_3.3V C2195 C2201 C2216 R2303 C2227 C2235 0.01 6.3V820 0.01 R2335 Q2035 CD_DGND B1BABG000007 BEATPROOF SWITCH NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN MAIN CIRCUIT...

  • Page 85: Panel, Lcd, Remote Sensor & Usb Circuit

    LCD DRIVER SEG14 R906 DATA SEG14 [34] SEG10 [1] /CS SEG13 R905 SEG13 [35] SEG9 [44] SEG0 SEG12 SEG12 SEG11 R903 SEG11 NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN PANEL / LCD / REMOTE SENSOR / USB CIRCUIT...

  • Page 86: Tuner & Voltage Selector Circuit

    AM ANT 4.7K AM ANT 4.7K 0.47 VOLTAGE SELECTOR CIRCUIT (FOR PH) (BLK) TL5* SMPS CIRCUIT IN SCHEMATIC S5701 VOLT ADJ DIAGRAM - 10 TL6* (RED) NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN TUNER / VOLTAGE SELECTOR CIRCUIT...

  • Page 87: Smps Circuit

    50V56 R5806 B0BC019A0007 C5721 C5722 220P 1000P R5805 C5818 D5723 2.2K B0ACCK000012 C5737...PH 820P R5865 PC5701 C5727...PN R5726 B3PBA0000503 D5725 3300P 0.1...PH B0BC6R100010 FEEDBACK 0.15...PN SYS3.3V R5727 R5817 R5810 0.13 QR5810 B1GBCFLL0037 FOR PN PCONT SWITCH PCONT SA-AKX12PH/PN SMPS CIRCUIT...
  • Page 88 200K IC5899 10V220 200V560...PN R5895 K8...PH C5794 R5795 C0DAEMZ00001 C5790 1000P 470K C5898 SHUNT REGULATOR 2200P K6...PN D5793 B0HAMP000094 R5891 R5797 FOR PH C5708 C5796 C5795 F1BAF1020020 1000P NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX12PH/PN SMPS CIRCUIT...

  • Page 89: Printed Circuit Board

    17.1. CD Servo P.C.B. CD SERVO P.C.B. (REPX0918C) (TO OPTICAL PICKUP (CD MECHANISM UNIT BRS1C)) (TRAVERSE MOTOR) (FOR DEBUG) (RESET SW) (TO LOADING PCB (CD MECHANISM UNIT BRS1C)) (SPINDLE MOTOR) SA-AKX12PH/PN NOTE: * REF IS FOR INDIC ATION ONLY. CD SERVO P.C.B.

  • Page 90: Main & Tuner P.c.b

    R5922 Q5903 Q2222 Q5900 C5937 C5925 C5980 C2226 R5909 Q5902 QR2400 QR2402 R5928 Q2040 R5936 Q5901 C5952 R5917 Q2041 C5978 QR5900 R5914 QR5901 HEATSINK 0728AA 0728AA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX12PH/PN MAIN / TUNER P.C.B.

  • Page 91: Panel, Lcd, Remote Sensor & Usb P.c.b

    S6008 S6009 S6011 (RWD) (MANUAL_EQ) (FWD) VR6002 (OPEN/CLOSE) JK1111 CN1113 LB1200 K1200 ALBUM/TRACK USB PORT K1210 C1110 0728AB 0728AB 0728AE 0728AE NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX12PH/PN PANEL / LCD / REMOTE SENSOR / USB P.C.B.

  • Page 92: Smps & Voltage Selector P.c.b

    W5511 IC5899 R5894 C5844 R5800 D5896 W5521 Q5860 W5522 W5523 D5804 R5892 Q5898 15 14 13 12 11 10 R5897 CN5802 C5812 W5512 0727CA 0727CA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX12PH/PN SMPS / VOLTAGE SELECTOR P.C.B.

  • Page 93: Smps P.c.b

    C5831 C5832 PC5799 PC5702 W5511 IC5899 R5894 C5844 R5800 D5896 W5521 Q5860 W5522 W5523 D5804 R5892 Q5898 15 14 13 12 11 10 R5897 CN5802 C5812 W5512 0727AA 0727AA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX12PH/PN SMPS P.C.B.

  • Page 95: Terminal Function Of Ics

    18 Terminal Function of ICs 18.1. IC2003 (RFKWMAKX12M0): IC Terminal Name Function MICRO-PROCESSOR OPT_DET Optical In Audio Data Detec- tion (L: No signal) No Connection Terminal Name Function No Connection No Connection No Connection No Connection No Connection EE_CS EEPROM IC Chip select No Connection EE_SCL EEPROM IC Serial clock...

  • Page 96: Ic900(C0Hba0000295): Ic Fl Driver

    18.2. IC900(C0HBA0000295): IC FL Driver Terminal Name Function Chip Selection Input Read Clock Input Write Clock Input DATA I/O Serial Data Input Negative Power Supply VLCD LCD Power Input Positive Power Supply O Tone Frequency Output Pair COM0 O Common Output 0 COM1 O Common Output 1 COM2...

  • Page 97: Exploded View And Replacement Parts List

    19.1.1. Cabinet Parts Location (PANEL P.C.B.) Z900 *ZJ6000B CN6005 *ZJ6000A CN6001 (LCD P.C.B.) VR6001 VR6002 CN6006 IR6000 (REMOTE SENSOR P.C.B.) CN1113 JK1111 (USB P.C.B.) 10-1 10-1 SA-AKX12PH/PN-K CABINET DRAWINGS NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY.
  • Page 98 (CD MECHANISM UNIT BRS1C) JK52 JK51 (TUNER P.C.B.) CN51 CN7901 CN7001 CN7002 CN7801 S7201 (CD SERVO P.C.B.) CN7003 SA-AKX12PH/PN-K NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. " ^ " PART IS FOR PH ONLY. CABINET DRAWINGS...
  • Page 99 19.1.2. Packaging ACCESSORIES BAG SB-AKX12PN REMOTE CONTROL AC CORD (FOR PN ONLY) AC CORD (FOR PH ONLY) OI BOOK SA-AKX12PH/PN AM LOOP ANTENNA FM INDOOR ANTENNA AC PLUG ADAPTOR (FOR PH ONLY) POLYFOAM (TOP) SC-AKX12PH/PN-K POLYFOAM (BOTTOM) PACKAGING DRAWINGS...
  • Page 101 19.1.3. Mechanical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks RMQX1088 MECHA HOLDER Description RWJA007120XX CABLE WIRE CABINET (LCD-PANEL) CHASSIS XTB3+10JFJ SCREW RHD30007-K2J SCREW REEX1135 (MAIN- RHD30111-31 SCREW TUNER)
  • Page 102 Safety Ref. Part No. Part Name & Qty Remarks Description RPNX1096 POLYFOAM RPFX0198 MIRAMAT ACCESSORIES N2QAYB000636 REMOTE CONTROL K2CB2CB00021 AC CORD K2CQ2CA00007 AC CORD RQTX1286-M O/I BOOK (Sp/En) RQTX1288-M O/I BOOK (Sp) N1DYYYY00010 AM LOOP ANTENNA RSAX0002 INDOOR ANTENNA K2DAYYY00002 AC PLUG ADAPTER...

  • Page 103: Electrical Replacement Part List

    19.2. Electrical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks IC2009 C0DBFYY00049 Description IC2010 C0CAAKG00046 PRINTED CIRCUIT IC2011 C0DAAYG00001 BOARDS IC2101 C1BB00001151 IC2201 C0AABB000125 PCB1 REPX0918C CD SERVO P.C.B.
  • Page 104 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description Q5900 B1ABGC000005 TRANSISTOR VA51 EZAEG2A50AX VARISTOR Q5901 B1ADCE000012 TRANSISTOR Q5902 B1ABCF000176 TRANSISTOR SWITCHES Q5903 B1ABCF000176 TRANSISTOR Q5904 B1ABCF000176 TRANSISTOR S5701 K0ABCA000007 SW VOLT ADJ Q5905...
  • Page 105 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description H0A327200097 CRYSTAL OSCILLA- W951 D0GBR00JA008 1/16W W952 D0GDR00JA017 1/8W X2000 H0A327200097 CRYSTAL OSCILLA- W5302 D0GBR00JA008 1/16W W5305 D0GDR00JA017 1/8W X2001 H2B800400007 CRYSTAL OSCILLA- W5306...
  • Page 106 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R2123 D0GB564JA008 560K 1/16W R2337 ERG2SJ471E R2126 D0GB101JA008 1/16W R2338 ERG2SJ471E R2127 D0GBR00JA008 1/16W R2339 ERG2SJ471E R2128 D0GBR00JA008 1/16W R2340 ERG2SJ471E R2129 D0GB101JA008...
  • Page 107 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R5841 D0GB124JA008 120K 1/16W R7221 D0GB101JA008 1/16W R5860 ERJ3GEYF103V 1/10W R7253 D0GB101JA008 1/16W R5861 ERJ3GEYF332V 3.3K 1/10W R7254 D0GB102JA008 1/16W R5862 D0GD183JA017 1/8W...
  • Page 108 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C2116 F1J0J106A020 10uF 6.3V C2307 F1H1H104A013 0.1uF C2117 F1H1H2210001 220P C2308 F1H1H104A013 0.1uF C2118 F1H1A154A001 0.15uF C2402 F1J0J106A020 10uF 6.3V C2119 F1H1H683A783 0.068uF 50V...
  • Page 109 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C5931 F1H1A474A001 0.47uF C7241 F1H1H102A219 1000pF C5933 F2A2A220A388 22uF 100V C7243 F1H1H103A885 0.01uF C5936 F1H1H104A013 0.1uF C7244 F1H1C153A001 0.015uF 16V C5937 F1K2A1040007 0.1uF...
  • Page 110 MMH1102...

This manual is also suitable for:

Sa-akx12pn

Table of Contents
