P ARTS LIST
No. Description
1 Power cable
2 Ball bearing
3 Bearing block
4 Bearing block
5 Ball bearing
6 Washer
7 Bolt
8 Main shaft
9 Fixed Centre
10 Tool post Support
11 Cap screw
12 Tool Post
13 Locking screw
14 Revolving centre
15 Ball bearing
16 Screw shaft
17 Tailstock
18 Nut
19 Locking screw
20 Hand wheel
21 Rail extension
22 Clamping plate
23 Spring washer
24 Nut
25 Screw
26 Switch
27 Screw
28 Switch bracket
29 Window
30 Lathe head
SPARE PARTS AND SERVICING
For spare parts or servicing, please contact your nearest Clarke dealer or Clarke International on
one of the following numbers.
Qty Part No.
1 see your dealer
1 GB27882
1 RWL1000B0302
1 RWL1000B0303
1 GB27882
12 GB97187
8 GB57832000
1 RWL1000B0301A
1 RWL1000B0304A
1 RWL1000B0201
2 GB57832000
1 RWL1000B0202
1 RWL1000B0203
1 RWL1000B0101
1 GB27882
1 RWL1000B0103
1 RWL1000B0102A
1 GB61702000
1 GB/T802000
1 RWL1000B0104A
1 RWL1000IA0002
2 RWL1000B0009
4 GB9387
4 GB61702000
2 GB57832000
1 see your dealer
6 GBT8182000
1 RWLZB2
1 RWL1000B0002A
1 RWL1000IA0001A
PARTS & SERVICE TEL: 020 8988 7400
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
No. Description
31 Nut
32 Nut
33 Lock Washer
34 Washers
35 Spring washer
36 Wire bracket
37 Screw
38 Belt pulley
39 Belt pulley
40 Cover
41 Motor
42 Screw
43 Cord clamp
44 Washers
45 Belt
46 Spanner
47 Instruction manual
48 Allen Key
49 Face Plate
50 End cover
51 Locking screw
52 Screw handle
53 Handgrip
58 Axis Screw
59 Washer
60 Lock Washer
61 Washer
62 Spring washer
63 Bolt
69 Circlip
30
Qty Part No.
2 GB61702000
1 GB61702000
2 GB862287
2 GB97187
2 GB9387
1 RWL1000E105
1 GBT8182000
1 RWL1000B0006A
1 RWL1000B0006
2 RWL1000I05
1 YY7124A
6 GBT8182000
1 DJ250A05007
6 GB93-87
1 GB117174
1 RWL1000B0012
1 see your dealer
1 GB535685
1 RWL1000B0004A
1 RWL1000B0500A
2 GBT802000
2 RWL1000B0702
2 RWL1000B0701
2 RWL1000IA09
4 GB9585
1 GB862287
4 GB9685
4 GB9387
4 GB57832000
1 GB894186
