- Page 1 VPT300 Intelligent Camera V500R003C10 Product Overview Issue Date 2017-04-10 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: About This Document
Product Overview About This Document About This Document Purpose This document describes the positioning, features, application scenarios, and technical specifications of the VPT300, an intelligent camera developed by Huawei. Intended Audience This document is intended for: End users Huawei agents Symbol Conventions The symbols that may be found in this document are defined as follows. - Page 4 Changes between document issues are cumulative. The latest document issue contains all the changes made in earlier issues. Issue 02 (2017-04-10) This issue is the second official release. Issue 01 (2017-01-05) This issue is the first official release. Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 5: Table Of Contents
6 Operation and Maintenance......................12 6.1 Maintenance Using the Web Interface..........................12 6.2 Remote Maintenance Using Command Lines......................12 6.3 Log Management................................12 6.4 VPT300 and VPC600 Upgrade............................ 13 6.5 Restoration to Factory Settings or Original Version.....................13 7 Technical Specifications......................14 7.1 Physical Specifications..............................14 7.2 Ports and Protocols............................... -
Page 6: Product Positioning
Product Overview 1 Product Positioning Product Positioning The VPT300 is designed for conference rooms in enterprises and educational institutions. Each VPT300 integrates two face detection cameras (a dual-camera system) and 16 microphones (a microphone array) to deliver optimal conferencing experience. -
Page 7: Product Highlights
SDI Port, Addressing Long-Distance Transmission of Video Images The SDI port transmits video images taken by the VPT300 to an endpoint that is up to 60 m away without any distortions. Compared with the analog port, the SDI port does not have any attenuation when transmitting RGB and YPbPr video signals, providing quality video at lower costs. -
Page 8: Application Scenarios
140-degree range of 10 m radius. A VPT300 can be equipped with two VPC600s to implement intelligent tracking. The two VPC600s are connected to the VPT300 through the HD-VI input ports on both sides at its back (shown in Figure 3-1). - Page 9 VPT300 to video input port 1 (that is, HD-VI input port) on the TE40. Use the audio cable delivered with the VPT300 to connect the LINE IN audio input port on the VPT300 to audio output port 1 on the TE40.
- Page 10 Connect one end of the HD-VI to DVI/Serial cable (delivered with the TE50) to the HD- VI output port on the VPT300 and connect the other end of the cable to the COM 1 or COM 2 port on the TE50 through a network cable.
-
Page 11: Product Structure
Figure 4-1 shows the appearance of the VPT300. Figure 4-1 VPT300 appearance 4.2 Front Panel and Rear Panel Figure 4-2 shows the front panel of the VPT300. Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 12 (on for 1s, off for 2s) on standby steady red faulty (hardware) steady yellow faulty (software) blinking yellow twice per second overheating Figure 4-3 shows the rear panel of the VPT300. Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 13 VPT300 Intelligent Camera Product Overview 4 Product Structure Figure 4-3 VPT300 rear panel Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 14: Features
Takes a panoramic view when many participants are speaking at the same time or in turn. 5.2 Manual Tracking After the VPT300 that has two VPC600s installed is connected to an endpoint, you can use the endpoint's remote control to control the VPC600s. However, only one VPC600 can be controlled at a time, which can be specified on the endpoint's web interface. -
Page 15: Pip Display
5.6 Sleep and Wake-up You can put the VPT300 and its VPC600 in sleep mode and wake them up from the connected TE40/TE50/TE60/TX50 endpoint. The VPT300 in sleep mode will wake up if you upgrade the VTP300 or use the VPT300 to upgrade the VPC600. - Page 16 VPT300 Intelligent Camera Product Overview 5 Features The Android operating system that the VPT300 has installed has been hardened and does not allow any third-party applications. Network Layer Security The VPT300 IP address is configured by the administrator using command lines. It must be deployed on the private network and completely isolated from the public network.
-
Page 17: Operation And Maintenance
Logs are saved as files. Users can log in to the VPT300 by Telnet or SSH and run specific commands to query all or some log records. However, VPT300 logs cannot be queried or exported from the web interface of the TE40/TE50/TE60/TX50 endpoint. -
Page 18: Vpt300 And Vpc600 Upgrade
6.4 VPT300 and VPC600 Upgrade You can upgrade the VPT300 to the latest version to fix its vulnerabilities, and then enjoy new functions provided in the latest version. Information regarding the upgrade is as follows: The VPT300 can be upgraded using the upgrade tool released with it or using the TE40/ TE50/TE60/TX50 upgrade tool. -
Page 19: Technical Specifications
VPT300 Intelligent Camera Product Overview 7 Technical Specifications Technical Specifications 7.1 Physical Specifications Table 7-1 lists physical specifications of the VPT300. Table 7-1 Physical specifications Item Specification Electricity Supply Requirements Input voltage range 100 V AC to 240 V AC Output voltage 19 V DC, 7.89A... -
Page 20: Ports And Protocols
Built-in Microphone Features Sound pickup capabilities l Sound pickup distance: 10 m l Sound pickup range: 140° 7.2 Ports and Protocols Table 7-2 lists ports provided and protocols used by the VPT300. Table 7-2 Port description Port Quantity and Protocols Remarks... -
Page 21: Standards Compliance
Used to upgrade the VPT300. port Mbit/s LAN Power port 7.3 Standards Compliance Table 7-3 lists protocols supported by the VPT300. Table 7-3 Protocols supported by the VPT300 Item Protocol Supported Network TCP, DHCP, Telnet, SSH, HTTP, and HTTPS transmission protocols... -
Page 22: A Glossary
For details, see RFC2818. Picture in Picture red green blue recognition Consumer awareness of having seen or heard an advertising message. serial digital interface. Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 23 Telnet allows users to log in to remote systems and use resources as if they were connected to a local system. Telnet is defined in RFC 854. Issue 02 (2017-04-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
