Summary of Contents for Toto WASHLET K300
- Page 1 Instruction Manual WASHLET SW3036R ■ Thank you for your recent purchase of this product. Please read the enclosed information to ensure the safe use of your product. ■ Be sure to read this Instruction Manual before using your product and keep it in a safe place for future reference.
- Page 2 What functions are available on your product? Part No. Product name (Model) WASHLET Ref. Part No. SW3036R Functions Page Rear cleansing Rear soft cleansing Cleansing ● Front cleansing Wand position adjustment Water pressure adjustment Basic Changing the cleansing Functions Oscillating cleansing ●...
-
Page 3: Table Of Contents
Keep It Table of Contents ...... 4 Safety Precautions ..11 Operational Precautions Clean ......12 Parts Names ........ 14 Preparation ....16 Basic Operations Sanitary Toilet Automatic Functions ....18 (Cleaning Features) Deodorizer, Auto wand CLEAN, Lights to show that the Pre-mist "CLEAN"... -
Page 4: Safety Precautions
Safety Precautions IMPORTANT SAFEGUARDS READ ALL INSTRUCTIONS BEFORE USING Symbols and Meanings WARNING May result in death or serious injury. CAUTION May result in injury or property damage. The following symbols are used to indicate important safety instructions for the use of the product. Symbol Meaning This symbol indicates a prohibited use of the product. - Page 5 WARNING Do not use the product if a malfunction occurs. In case of breakdown or other problem, be sure to cut off power by means such as unplugging the power plug. Close the water shutoff valve to stop water supply. Possible malfunctions: ...
- Page 6 Safety Precautions (Continued) WARNING Refrain from sitting on the seat for long periods. It may cause low-temperature burns. To prevent the following persons from getting a moderate temperature burn during use, other person should turn off the toilet seat heater and set the dryer temperature to "Low". ...
- Page 7 WARNING When leaking battery fl uid adheres to your body or clothes, wash it away with clean water. The fl uid may damage your eyes or skin. Preliminary studies in females suggest that overuse of continuous spraying can increase the possibility of vaginal mucosa drying and potential reduction in desirable microbial organisms.
- Page 8 Safety Precautions (Continued) CAUTION Do not fold or crush the water supply hose; do not damage by cutting with a sharp object. Doing so may cause water leaks. Do not install the base plate, which is not attached. ...
- Page 9 DANGER To reduce the risk of electrocution: 1. Do not use while bathing. 2. Do not place or store the product where it can fall or be pulled into a tub or sink. 3. Do not place in or drop into water or other liquid. 4.
- Page 10 Safety Precautions (Continued) Grounding Instructions This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electrical current. This product is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
-
Page 11: Operational Precautions
Operational Precautions For prevention of malfunctions Disconnect the power plug if there is a risk of lightning. < About the seat switch > Do not urinate on the main unit, toilet seat or When you sit on the toilet seat, the seat switch wand. -
Page 12: Parts Names
Parts Names Main display Power LED Seat LED Energy saver LED Wand CLEAN LED <All the LEDs light up in the fi gure> Part No., etc. Toilet lid Warm air outlet cover Heated seat Water supply hose Wand cover Power plug Shutoff... - Page 13 Left side of main unit Right rear of main unit Water fi lter drain valve (Page 32) Cover Deodorizer outlet Toilet lid cushions Toilet seat cushions Right side of main unit Remote control receiver Main unit removal button (Page 30) Deodorizing fi...
-
Page 14: Preparation
Preparation Using the Product for the First Time If the remote control is secured 1. Insert the battery (for anti theft) Remove the Remove the screw from the remote control remote control fi xture. from the Remote hanger. control (View from side) Remote control Hanger Wall... - Page 15 2. Turn on the power 3. Open the shutoff valve Fully open the shutoff valve. Insert the power plug. The wand extends and then retracts. Check that the "Power" LED lights up. When it is off , switch the "Power" to "ON". To operate from the back of remote control Press "Power ON/OFF"...
-
Page 16: Basic Operations
Basic Operations Operate the controls on the remote control; a beep sounds when the main unit receives the signal. Stopping ● Functions that operate when a button is pressed during "Rear "Stopping" cleansing", "Rear soft cleansing" Stops the operation. or "Front cleansing" cleansing. Note Cleansing ... - Page 17 This section is an overview of the settings that can be confi gured with the remote control. See the corresponding pages for the detailed descriptions. Remote control back side Temperatures Energy saver Adjust temperatures (Page 20) Saving energy (Page 24) "Toilet seat "Timer energy temperature"...
-
Page 18: Automatic Functions (Cleaning Features)
Automatic Functions Cleaning Features As you As you As you "EWATER+" is used automatically to clean the approach stand up wand and bowl unit. • Operation under the initial settings is described below. Starts the auto Removing odors inside the power deodorizer bowl unit (After about 10 seconds) - Page 19 Lights to show that the "CLEAN" functions are operating. ■"Wand CLEAN" LED Lights to show that the "Auto wand CLEAN" functions or the "Wand CLEAN" functions are operating. During "Auto wand CLEAN" or "Wand CLEAN": Flashes ■ Changing ■ Note settings "EWATER+"...
-
Page 20: Temperature Adjustment (Toilet Seat, Warm Water, Drying)
Temperature Adjustment Toilet Seat, Warm Water, Drying Three diff erent temperature levels (High / Medium / Low) and "OFF" setting can be made. Displaying the temperature level of the pressed button When seat temperature is set Drying air temperature Toilet seat (When you want to adjust the temperature drying air temperature) - Page 21 When seat temperature is "OFF" <Seat> To turn the warm water temperature and toilet seat temperature "OFF" The "Drying" cannot be turned "OFF". Remove the remote control from the hanger. • If the remote control is secured to prevent theft. (Page 14) Select a temperature button you want to turn "OFF"...
-
Page 22: Energy Saver Features
Energy Saver Features Type "Auto energy saver", "Auto energy saver+" or "Timer energy saver" can be selected. To save energy, the temperature of the toilet seat becomes low (or "OFF"). ● "Auto energy saver" takes about 10 days to detect time periods in which the toilet seat is never or infrequently used. Energy saver is on Type Situation... - Page 23 Main display <Power> <Seat> <Energy saver> When energy saver is in operation Toilet seat heater Example: Used infrequently from 9 pm to 6 am (Orange) Set temperature temperature temperature Example: Not used from 0 am to 4 am (Orange) Set temperature temperature temperature Example: Set from 8 am to 5 pm...
- Page 24 Energy Saver Features How to Set Remote control back side Auto energy Auto energy saver saver button Timer energy Auto energy saver button saver+ button Auto energy saver+ Timer energy saver <Energy saver> When energy saver is set, the "Energy saver" LED (green) lights up.
- Page 25 The setting changes each time the button is pressed once For setting to "Auto energy saver" For setting to "OFF" Press "Auto Lit (Green) energy saver" button. The setting changes each time the button is pressed once For setting to "Auto energy saver+" For setting to "OFF"...
-
Page 26: Maintenance
Maintenance Power Plug Power Plug WARNING (Approximately once a month) Always unplug the power plug from the outlet before maintenance or inspection. (Failure to do so may cause electric shock or malfunction, resulting in a breakdown.) Dry cloth Wet cloth Unplug the power plug and For safety, unplug the power wipe it with a dry cloth. -
Page 27: Main Unit
Main Unit Main Unit (Approximately daily) ・ Toilet paper Soft cloth soaked ・ Dry cloth in water ・ Nylon scrubbing brush (May cause damage.) Unplug the power plug. Wipe with a soft cloth that has been soaked in water and wrung-out thoroughly. -
Page 28: Deodorizing Filter
Maintenance Deodorizing Filter Deodorizing Filter (Approximately once a month) Unplug the power plug. Remove the deodorizing fi lter. • Hold the knob and pull outward. • Do not pull with undue force. (May cause damage or malfunction.) Deodorizing Filter Clean with a tool such as a toothbrush. -
Page 29: Wand
Wand Wand (Approximately once a month) < If you notice dirt (Wand cleaning)> Toilet paper, etc. Soft cloth (May cause damage.) Extend the wand. To operate from the back of remote control Press "Wand cleaning" button. To operate from the front of remote control *Recommended if the remote control is secured to prevent theft. -
Page 30: The Bowl Unit
Maintenance Gap between the Main Unit and Bowl Unit Gap between the Main Unit and Bowl Unit (Approximately once a month) You can remove the main unit to clean the top of the bowl unit and the bottom of the main unit. Soft cloth soaked in water Toilet paper, etc. -
Page 31: Gap Between The Main Unit And The Toilet Lid
Gap between the Main Unit and the Toilet Lid Gap between the Main Unit and the Toilet Lid (Approximately once a month) The toilet lid can be removed for thorough cleaning. Soft cloth soaked in water Toilet paper, etc. (May cause damage.) Unplug the power plug. -
Page 32: Water Filter Drain Valve
Maintenance Drain Valve Water Filter Water Filter Drain Valve (Approximately once every 6 months) <If you think the water pressure has weakened> Close the shutoff valve. • The water supply stops. CAUTION Shutoff Do not remove the water fi lter drain valve valve while the shutoff... - Page 33 Reinstall the water fi lter drain valve and cover. • Insert the water fi lter drain valve and use a fl at-head screwdriver to tighten it securely. Insert the power plug. • The "Power" LED lights up. Open the shutoff valve. Water fi...
-
Page 34: Changing Settings
Changing Settings Setting List Setting Types Auto wand CLEAN Pre-mist Auto Cleaning functions Features Deodorizer Auto power deodorizer Beep sound Other settings Personal setting lock To change the settings, All LEDs on the control panel flash. check that all LEDs on the control panel are flashing! Press "Stopping"... - Page 35 How to Set Available Settings Ref. Page • Bold: Initial settings Set whether or not to clean the wand / OFF automatically • Set whether or not to spray mist in the / OFF bowl unit automatically Page 36 •...
- Page 36 Changing Settings Cleaning Features Set whether or not to clean the wand automatically Press "Stopping" Auto wand CLEAN button until all LEDs on the remote control start fl ashing. (about 10 seconds) Set whether or not to spray mist in the bowl unit automatically Pre-mist Set whether or not to deodorize...
- Page 37 The setting changes each time the button is pressed once Press "Timer Set whether or not to clean the wand automatically energy saver" For setting to "ON" For setting to "OFF" button and "Setting confi rmation" Short beep Long beep button at the same time.
- Page 38 Changing Settings Other settings Set whether or not to make a beep sound Press "Stopping" Beep sound button until all LEDs on the remote control start fl ashing. (about 10 seconds) Set whether or not to use the personal setting lock Personal setting lock Stopping button...
- Page 39 The setting changes each time the button is pressed once Set whether or not to make a beep sound Press "Rear cleansing" For making a beep sound For not making a beep sound button. Short beep Long beep ▶ The setting changes each time the button is ▶...
-
Page 40: What To Do
What to Do? If the water does not fl ow due to a water service interruption If you cannot operate with the remote control If the water does not fl ow due to a water service interruption Large bucket Use a bucket to fl ush water. Pour strongly, aiming at the center of the If the water level is low after... -
Page 41: Freeze Damage Prevention
Freeze Damage Prevention When the ambient temperature is likely to drop to 32 °F (0 °C) or lower, take measures to prevent freezing. Attention! • When the ambient temperature is likely to drop to 32 °F (0 °C) or lower, do not use the energy saver feature. (May damage the product.) •... -
Page 42: Long Periods Of Disuse
What to Do? Long Periods of Disuse If the toilet is in a location you will not visit for a long time, drain the water. (The water in the tank may cause malfunctions or become contaminated and cause skin irritation or other problems.) How to drain the water Drain the water from the toilet tank. -
Page 43: Removal Of Operation Guide
Removal of Operation Guide To remove, follow the procedure below. How to remove the operation guide Unplug the power plug. Remove the remote control from the hanger. (Page 14) Remove the hanger and Screw operation guide. Phillips screwdriver Hanger Operation guide Screw the hanger on the wall. -
Page 44: Troubleshooting
Troubleshooting First, try the actions described on pages 44 - 48. If the problem CAUTION persists, consult the installer, seller or TOTO customer service (see contact information on the back cover). If a water leak occurs, close the shutoff valve. - Page 45 If the same symptom reappears. There may be a malfunction. The wand Consult with TOTO customer service (see contact information on the back cover). (or cleansing The seat switch will not turn on unless you sit on the seat properly.
- Page 46 Troubleshooting Warm air drying Ref. Trouble Please check Page The dryer ▶ temperature is Is the dryer temperature set to low level? The feature stops automatically after about 10 minutes of continuous use. Stops in the Does the seat switch have diffi culty detecting? ▶...
- Page 47 If the "Wand CLEAN" LED does not light up, it is time to replace the component that CLEAN LED ▶ generates "EWATER+". Consult the installer, seller, or TOTO customer service (see does not light contact information on the back cover).
- Page 48 (Do not use any tool.) ▶ the plumbing If the water leak does not stop, close the shutoff valve and consult with TOTO customer service (see contact information on the back cover). connections There is clearance between the toilet seat cushion and the bowl unit for activating the seat switch.
-
Page 49: Specifi Cations
W 1.26 ft x D 1.74 ft x H 0.43 ft (W 384 mm x D 531 mm x H 131 mm) Weight About 11 lb (about 5 kg) *1 Temperature around the warm air outlet measured by TOTO. ● When disposing of this product, please follow your local or state guidelines for proper disposal. -
Page 50: Warranty
Limited Warranty One Year Limited Warranty... - Page 51 MEMO...
- Page 52 • You are advised to record the following information to allow quick service. Date of purchase : Name of shop : Date : year month day Tel : ( 2020.7.22 D07980...
