  • Page 2 Warning Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid: Risk of injury or death. A child climbing Never allow children to climb on or play with Children climbing on furniture.
  • Page 3 Avertissement Prière d’utiliser le mobilier à bon escient et avec prudence. Une mauvaise utilisation peut être à l’origine de risques d’accident ou peut endommager le mobilier et les articles ménagers. Lire attentivement le tableau suivant. Les risques : Comment éviter : Faites attention : Enfants monter sur des meubles.
  • Page 4 Advertencia Por favor use su mueble correctamente y seguramente. El uso impropio puede causar riesgos de seguridad o daño al mueble o artículos domésticos. Cuidadosamente lea la tabla a continuación. Tenga cuidado con: Puede ocurrir: Como evitar: Riesgo de lesión o muerte. Un niño Nunca permita que lo niños se suban o Niños subiéndose a los muebles.
  • Page 5 LISTE DES PIÈCES LISTA DE PIEZAS PARTS LIST Qty. Qté Qty. Qté Name/Nom/Nombre Part/Pièce/Pieza Name/Nom/Nombre Part/Pièce/Pieza Cantidad Cantidad Corner Top Box Drawer Back Panneau supérieur du Panneau arrière du tiroir simple meuble de coin Parte trasera del cajón Tablero de esquina Box Drawer Bottom Return Top Panneau supérieur du retour...
  • Page 6 LISTE DES PIÈCES LISTA DE PIEZAS PARTS LIST Spare Spare Qty. Qté Qty. Qté Épargner Épargner Name/Nom/Nombre Part/Pièce/Pieza Name/Nom/Nombre Part/Pièce/Pieza Cantidad Cantidad Sobrante Sobrante Left Keyboard Slide 2 ” Screw Coulisse gauche de Vis de 51mm tablette du clavier Tornillo de 51mm Teclado corredero izquierdo Right Keyboard Slide 1 ”...
  • Page 7 COMPARISON SIZE CHART TABLEAU DE COMPARAISON DE TAILLES TABLA DE COMPARACIÓN DE TAMAÑOS 2” Screw Vis de 51mm Tornillo de 51mm 1” Screw Vis de 25mm Tornillo de 25mm 1/2” Screw Vis de 12mm Tornillo de 12mm 1/2” Screw Vis de 12mm Tornillo de 12mm 9/16”...
  • Page 8 Installation of Cams and Pins : Screw the Pin into hole. To set Cams correctly, ensure the arrow on the Cam head points to the hole of the Pin it is locking. Lock Cam by turning Cam head one third clockwise with screwdriver. Do not overtighten.
  • Page 9 STEP 1 [ 10 ] [ 4 ] [ 2 ]...
  • Page 10 STEP 2 [ 1 ] [ 4 ] [ 1 ] [ 4 ]...
  • Page 11 STEP 3 [ 2 ] [ 8 ] [ 2 ] [ 8 ]...
  • Page 12 STEP 4 [ 2 ] [ 2 ] [ 4 ]...
  • Page 13 Desk Set-Up Before proceeding to the next step, the Desk can be set-up with two configurations, Option “ A ” and Option “ B ” as shown on this page. 1. If you choose to set-up your Desk as shown in Option “ A ” below; proceed to Step 5 and continue the assembly process.
  • Page 14 STEP 5 [ 6 ] [ 12 ] [ 1 ] [ 1 ] [ 4 ]...
  • Page 15 STEP 6 [ 6 ] [ 4 ]...
  • Page 16 STEP 7 [ 2 ] [ 2 ] [ 10 ]...
  • Page 17 STEP 8 [ 2 ]...
  • Page 18 STEP 9 [ 3 ]...
  • Page 19 STEP 10 [ 3 ]...
  • Page 20 STEP 11 [ 4 ]...
  • Page 21 STEP 12 [ 2 ]...
  • Page 22 STEP 13 [ 4 ] [ 2 ] [ 4 ]...
  • Page 23 STEP 14 [ 2 ]...
  • Page 24 STEP 15 [ 2 ] [ 2 ]...
  • Page 25 STEP 16 [ 2 ]...
  • Page 26 STEP 17 [ 2 ] [ 2 ]...
  • Page 27 STEP 18 [ 3 ]...
  • Page 28 STEP 19 [ 6 ] [ 2 ] [ 4 ]...
  • Page 29 STEP 20 [ 6 ] [ 2 ]...
  • Page 30 STEP 21 [ 4 ] [ 2 ] [ 4 ]...
  • Page 31 STEP 22 [ 4 ] [ 4 ]...
  • Page 32 STEP 23 [ 4 ]...
  • Page 33 STEP 24 [ 4 ]...
  • Page 34 STEP 25 [ 4 ] [ 4 ]...
  • Page 35 STEP 26 [ 4 ]...
  • Page 36 STEP 27 [ 1 ] [ 2 ]...
  • Page 37 STEP 28...
  • Page 38 STEP 29...
  • Page 39 STEP 30 [ 1 ] [ 2 ]...
  • Page 40 STEP 31 [ 1 ] [ 1 ] [ 6 ]...
  • Page 41 STEP 32 [ 4 ]...
  • Page 42 STEP 33 [ 2 ]...
  • Page 43 STEP 34 [ 4 ]...
  • Page 44 STEP 35 [ 4 ] [ 2 ]...
  • Page 45 STEP 36 [ 2 ] [ 2 ]...
  • Page 46 STEP 37 [ 2 ] [ 2 ]...
  • Page 47 STEP 38 [ 7 ]...
  • Page 48 STEP 39 [ 7 ] [ 7 ]...
  • Page 49 STEP 40 [ 2 ] [ 4 ]...
  • Page 50 STEP 41 [ 3 ]...
  • Page 51 STEP 42 [ 4 ]...
  • Page 52 STEP 43 [ 6 ] [ 12 ] [ 1 ] [ 1 ] [ 4 ]...
  • Page 53 STEP 44 [ 6 ] [ 4 ]...
  • Page 54 STEP 45 [ 2 ] [ 2 ] [ 10 ]...
  • Page 55 STEP 46 [ 2 ]...
  • Page 56 STEP 47 [ 3 ]...
  • Page 57 STEP 48 [ 3 ]...
  • Page 58 STEP 49 [ 4 ]...
  • Page 59 STEP 50 [ 2 ]...
  • Page 60 STEP 51 [ 4 ] [ 2 ] [ 4 ]...
  • Page 61 STEP 52 [ 2 ]...
  • Page 62 STEP 53 [ 2 ] [ 2 ]...
  • Page 63 STEP 54 [ 2 ]...
  • Page 64 STEP 55 [ 2 ] [ 2 ]...
  • Page 65 STEP 56 [ 3 ]...
  • Page 66 STEP 57 [ 6 ] [ 2 ] [ 4 ]...
  • Page 67 STEP 58 [ 6 ] [ 2 ]...
  • Page 68 STEP 59 [ 4 ] [ 2 ] [ 4 ]...
  • Page 69 STEP 60 [ 4 ] [ 4 ]...
  • Page 70 STEP 61 [ 4 ]...
  • Page 71 STEP 62 [ 4 ]...
  • Page 72 STEP 63 [ 4 ] [ 4 ]...
  • Page 73 STEP 64 [ 4 ]...
  • Page 74 STEP 65 [ 1 ] [ 2 ]...
  • Page 75 STEP 66...
  • Page 76 STEP 67...
  • Page 77 STEP 68 [ 1 ] [ 2 ]...
  • Page 78 STEP 69 [ 1 ] [ 1 ] [ 6 ]...
  • Page 79 STEP 70 [ 4 ]...
  • Page 80 STEP 71 [ 2 ]...
  • Page 81 STEP 72 [ 4 ]...
  • Page 82 STEP 73 [ 4 ] [ 2 ]...
  • Page 83 STEP 74 [ 2 ] [ 2 ]...
  • Page 84 STEP 75 [ 2 ] [ 2 ]...
  • Page 85 STEP 76 [ 7 ]...
  • Page 86 STEP 77 [ 7 ] [ 7 ]...
  • Page 87 STEP 78 [ 2 ] [ 4 ]...
  • Page 88 STEP 79 [ 3 ]...
  • Page 89 STEP 80 [ 4 ]...
  • Page 90 Office Depot, Inc. Limited Five Year Product Warranty This limited warranty covers the original purchase of new product used for normal commercial, personal or household use. Office Depot, Inc. (ODI) warrants its products will be free from defects in materials and workmanship (normal wear and tear excepted), for five (5) years from the date of purchase, except as provided below.
  • Page 91 Office Depot, Inc. Garantie limitée de cinq (5) ans Cette garantie limitée couvre les produits neufs utilisés dans le cadre d'applications commerciales ou domestiques normales. Office Depot, Inc. (ODI) garantit ses produits contre les défauts de matériel et de main-d'oeuvre (à l'exception de l'usure normale) durant cinq (5) ans à compter de la date d'achat, à...
  • Page 92 Office Depot, Inc. Garantía limitada de cinco años para el producto Esta garantía limitada cubre la adquisición original de un producto nuevo utilizado con fines comerciales, personales o domésticos normales. Office Depot, Inc. (ODI) garantiza que sus productos estarán exentos de defectos materiales y de fabricación (a excepción de los derivados de un uso y desgaste normal) durante cinco (5) años a partir de la fecha de compra del producto, con la salvedad de lo dispuesto a continuación.
