be connected to the LAN and DHCP server.
IMPORTANT: The UAP­AC­HD cannot be powered by the US­8 or US­8­
60W; however, it can be powered by other UniFi PoE Switches that
provide 802.3at PoE+ power.
Mounting Plate
The Mounting Plate offers a variety of mounting holes for different applications.
The legend printed on the Mounting Plate identifies the holes used for each
application.
Hardware Installation
The UniFi AP can be mounted on a wall, ceiling tile, drop ceiling T­rail (up to 40
mm), or electrical junction box. Perform the steps for the appropriate installation.
Note for UniFi AP replacement: The holes marked "A" on the Mounting
Plate line up with the holes of mounting brackets used for previous UniFi
AP models.
Wall Mount
1.
