ALARMS

The appliance is programmed to communicate 7 fundamental alarms. The alarms are listed below:
ALPE
Appears when the temperature during the WORK mode drops below the fixed threshold: this indicates that the appliance is
switching off or switched off due to lack of pellets. To reset the alarm simply press the Flame Button: The appliance will begin a
new start up phase. It is mandatory to empty and clean the brazier, and then to fill the pellet tank before repeating the STA RT
phase.
ALAC
Appears once the START phase has finished if the smoke does not reach a certain temperature. To reset the alarm simply press
the Flame Button: the appliance will begin a new start up phase. It is mandatory to empty and clean the brazier before repeating
the START phase: pellets emptied from the brazier must not be fed into the tank.
ALOP
This occurs when the smoke outlet is partially blocked. To reset the alarm the power to the appliance must be switched off then on
by turning the switch 0-1 located in the power panel. Before restarting the appliance check for any irregularities such as blocked flue
outlet, open firebox door, etc. and solve the problem.
AL T max
Appears when the temperature of the appliance body exceeds 125°C. Once the causes for the overtemperature have been
identified and remedied unscrew the plastic cover from the thermostat located on the power panel and press the button (the
temperature of the appliance must lower considerably). To reset the alarm the power to the appliance must be switched off then on
by turning the switch 0-1 located on the power panel.
AL SMOKE TEMP SENSOR
Appears when the smoke thermocouple is damaged, disconnected or absent.
.
AL SMOKE FAN
Activates when the smoke suction unit sensor detects a very slow rotation speed: clean the vent A3, the smoke channels and the
flue outlet (see para. 8). If the problem persists contact the technical assistance service.
To reset the alarm the power to the appliance must be switched off then on by turning the switch 0-1 located on the power panel.
AL SMOKE RPM SENSOR: trips when the smoke suction unit revolution sensor fails to detect any rotation; the smoke suction unit
is not working, call the technical assistance service.
