JUKI TL-2020 PE Instruction Manual

TL-2020 PE ACCESSORY BOX
INSTRUCTION MANUAL
❶ ❶ ❸ ❸
❷ ❷
Accessory box No. 1
❶
1/5" Quilting Foot
❷
1/4" Quilting Foot
❸
Quilting Foot Front Open Toe
❹
1/4" Quilting Foot (for Ruler)
❺
Echo Quilting Foot
Changing the presser foot
Screw in the
presser foot
Accessory box No. 1
❶ 1/5" Quilting Foot
❷ 1/4" Quilting Foot
❸ Quilting Foot Front Open Toe
● 1/5 inch =
5.0 mm type
This type is suited
for free-motion
quilting in general.
1/8 inch
(3.2 mm)
Install the
1
quilting foot.
Needle clamp screw
Plate
Presser
bar
Screw in the
presser foot
Put the plate on the needle clamp
screw, insert the installing portion into
the presser bar, and securely tighten
the screw in the presser foot.
❹ ❹
❺ ❺
❻
❼
❽
❾

CAUTION:
1
Turn off power and remove the presser foot.
2
Install the presser foot.
Presser
foot
● 1/4 inch =
6.5 mm type
This type is suit-
ed as a guide for
1/5 inch
sewing stitches
(5.0 mm)
at regular inter-
vals.
Position Feed Dog in lower
2
position.
❾ ❾

❼ ❼ ❽ ❽
❻ ❻
Accessory box No. 2
1/4" Presser Foot
Compensating Foot (Right 1/4")
Hemming Foot
Zipper Attaching Foot
Quilt Guide for Even Feed Foot
Turn OFF the power switch when replacing the presser foot.
This quilting foot is convenient for free motion quilting, quilting along with
the pattern, free-hand embroidery, etc.
1/4 inch
(6.5 mm)
1/8 inch
(3.2 mm)
Position stitch length
3
adjusting dial "0".
Rotate presser foot pres-
sure regulator until blue
bar in pressure indication
window is at top.
- 1 -
Accessory bag

Even Feed Foot
● Front open type
This type is suited for
free-motion quilting.
The needle entry point
is easily observed
since the front section
1/8 inch
is open.
(3.2 mm)
Lower the foot and
4
start sewing.

1/5 inch
(5.0 mm)
