Installation of Exhaust Pipe
Please avoid the following situations when installing the exhaust pipe.
1. Over bending.
2. Bending too much.
3. The bend of the pipe comes too close to the main body.
4. The pipe shrinks.
Electrical engineering-wiring
1. Installation and wiring must be done by qualified electrical engineering contractor.
2. Please use the product under rated voltage and rated frequency in accordance with its
rating label.
3. Please prepare the unique air switch for this product in the user's house, and let the air
switch should be consistent with air switch off contact all extremely disconnected
requirements of distance is greater than 3mm, in order to cut off the power of the product
immediately in case of accident.
4. Must be connected to the ground wire.
5. During installation, the fixed power wiring must be in accordance with local safety
regulations.
6. For metal net bottom, steel wire net bottom of walls or wooden houses with the metal
surface, etc. when install metal exhaust pipe through, do paying attention that there shall be
no electrical contact.
7. When the power supply is insufficient, contact with electric power supply company.
8.Prior to the opening front cover, please make sure that the machine is powered off.
9. This product shall not be placed directly below the power outlet, do not install too close to
the socket to prevent the host electrical equipment from being damaged and damage other
electrical appliances.
Over bending
Bending too much
DRY COOL
DRY HOT
CIR
HEAT
AUTO
VENT
ION
MODE
TIMER
OSC
FAN
Delay
TURBO
ON/OFF
Vent Function
15 minutes
Infrared Wireless
Remote Control
-07-
The bend of the
The pipe shrunks
pipe comes too
close to the main
body
