XT1000 Cross trainer
Assembly & User Instructions-
782/4832
Please Keep for future reference
Important –
Please read these instructions fully before assembly or use
These Instructions contain important information which will help you get best from your
equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 600 1714
or visit www.argos-support.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pro Fitness XT1000

  • Page 1 XT1000 Cross trainer Assembly & User Instructions- 782/4832 Please Keep for future reference Important – Please read these instructions fully before assembly or use These Instructions contain important information which will help you get best from your equipment and ensure safe and correct assembly, use and maintenance.
  • Page 2: Table Of Contents

    Contents Safety Information Components - Parts Components – Fixings Assembly Instructions 5-12 Workout Area Exercise Information 14-20 . Before Starting . Muscle Chart . Warning up and Cooling Down 16-17 . Console operation 18-19 . Adjustment of the resistance Care and Maintenance Exploded Parts Diagram Parts List 23-24...
  • Page 3: Safety Information

    Safety Information 、 Important – Please read fully before assembly or use This exercise equipment is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble, operate or use this equipment.
  • Page 4: Components - Parts

    If you have damaged or missing parts, please Components - Parts 0345 600 1714 call the Customer Helpline: http://www.argos-support.co.uk Please check you have all parts listed below Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully before contacting Argos regarding any missing components.
  • Page 5: Components - Fixings

    Components – Fixings Please check you have all the fixings listed below Note : The quantities below are the correct amount to complete the assembly. In some cases more hardware may be supplied than are required. Some of the fixings are pre-fitted to the larger components. Please check carefully before contacting Argos regarding any missing fixings.
  • Page 6: Assembly Instructions

    Assembly Instructions Total mass of the product is 43 kg. Total size of the equipment is (width) 67.5 cm × (depth) 122.5 cm × (height) 160.5 cm. Main Frame Left Pedal Left Footplate Bar Right Pedal Right Footplate Bar Handrail Axle Sleeve Front Stabilizer Handrail Front Cover Rear Stabilizer...
  • Page 7 Assembly Instructions Step 1 a. Attach the Front Stabilizer (4) to the Main Frame (1) using 2 x M10x20mm Allen Bolts (80), 2 x 10mm Washers (74) and 2x10mm Spring Washers (71). b. Attach the Rear Stabilizer (5) to the Main Frame (1) using 2 x M10x20mm Allen Bolts (80), 2 x 10mm Washers (74) and 2x10mm Spring Washers (71).
  • Page 8 Assembly Instructions Step 2 a. Attach the Left Footplate (32) to the Left Footplate Bar (2) using 3 x M8×15mm Allen Bolts (79), 3 x Ø8mm Spring Washers (73) and 3 x Ø8mm Washers (75). b. Attach the Right Footplate (33) to the Right Footplate Bar (3) using 3 x M8×15mm Allen Bolts(79), 3 x Ø8mm Spring Washers (73) and 3 x Ø8mm Washers (75).
  • Page 9 Assembly Instructions Step 3 a. Connect the Wire (C) to the wire (C1). b. Fix the Front Post (11) to the Main Frame (1) using 6 x M8×15mm Allen Bolts (79), 6 x Ø8mm Spring Washers (73), 2 x Ø9xØ22×R19mm Arc Washers (85) and 4 x Ø8mm Washers (75). c.
  • Page 10 Assembly Instructions Step 4 a. Fix the Left Footplate Bar (2) to the Left Action Arm (12) using 1 x Ø11.5×67mm Allen Bolt (82) and 1 x M8 Aircraft Nut (70). b. Fix the Right Footplate Bar (3) to the Right Action Arm (13) using 1 x Ø11.5×67mm Allen Bolt (82) and 1 x M8 Aircraft Nut (70).
  • Page 11 Assembly Instructions Step 5 Attach the Handle (10) to the bracket on the Front Post (11), and secure with M8 Lock knob (48). Note: To adjust the position of the handle, turn the M8 lock knob (48) anti clockwise to loosen the handle (10) as shown in the diagram, and adjust the handle (10) to your required position, then secure the M8 lock knob (48).
  • Page 12 Assembly Instructions Step 6 a. Insert the Left Handle (8L) to the Left Action Arm (12); insert the Right Handle (8R) into the Right Action Arm (13). b. Fix the Left Handle (8L) to the Left Action Arm (12) using 2 x M8×42mm Hex Bolt (83), 2 x Ø9ר22×R19mm Arc Washers (85) and 2 x M8 Nuts (70).
  • Page 13 Assembly Instructions Step 7 a. Fix the Handle Front Cover (35) and Handle Rear Cover (36) to the Left Action Arm (12) and Right Action Arm (13) respectively using 4 x ST4.2×15mm Philips Screws (86). b. Fix the Water Bottle Bracket (43) to the Front Post (11) using 2 x ST4.8×15mm Philips Screws (88). c.
  • Page 14: Workout Area

    Workout Area The free area must be at least 0.6m greater than the training area. This is a space where you can safely dismount, without obstruction, in case of an emergency. Where two pieces of equipment are positioned adjacent to each other the free area may be shared. 0.6m (Free area) 0.6m...
  • Page 15: Exercise Information

    Exercise Information Before starting Tailor your exercise program according to your physical condition. If you have been inactive for several years, or are overweight, you must start slowly and increase your time on the equipment; a few minutes per workout increase is advisable. Initially, you may be able to exercise only for a few minutes in your target zone, however, your aerobic fitness will improve over the next six to eight weeks.
  • Page 16: Muscle Chart

    Exercise Information Muscle Chart Aerobic Exercise Aerobic exercise improves the fitness of your lungs and heart - your body’s most important muscle. Aerobic exercise is promoted by any activity that uses your large muscles (arms, legs, or buttock, for example). Weight Training Along with aerobic exercising which helps get rid of and keep off the excess fat that our bodies can store, weight training is an essential part of an exercise routine.
  • Page 17: Warning Up And Cooling Down

    Exercise Information Warming up and Cooling down Each workout should include the following three parts: 1. A warm-up, consisting of 5 to 10 minutes of stretching and light exercise. A proper warm-up increases your body temperature, heart rate, and circulation in preparation for exercise. 2.
  • Page 18 Exercise Information Calf/achilles stretch With one leg in front of the other, reach forward and place your hands against a wall. Keep your back leg straight and your back foot flat on the floor. Bend your front leg, lean forward and move your hips toward the wall.
  • Page 19: Console Operation

    Exercise Information Console Operation Display Mode Reset Recovery RECOVERY Key: The recovery function will test your fitness recovery. To do this, hold the hand pulse sensors for one minute after which a fitness value will be displayed; F1.0 is excellent fitness and F6.0 is very poor fitness. MODE: This key lets you select and lock on to a particular function which you want.
  • Page 20 Exercise Information Console Operation the heartbeat signal is received during the measurement. When no heart rate signal is input, the heart rate is displayed as P. Press UP or DOWN button one time, the heart rate will increase or decrease by 1 each time. Long press for rapid accumulation or subtraction.
  • Page 21: Adjustment Of The Resistance

    Exercise Information Adjustment of the resistance Adjustment of the Resistance level by turning the 8-level tension knob either to the right (increase) or the left (decrease).
  • Page 22: Care And Maintenance

    Care and Maintenance Replace defective Should you have any difficulty The safety level of the components immediately and with assembly, operation or equipment can only be keep the equipment out of use use of your exercise product maintained if it is examined until repair;...
  • Page 24: Parts List

    Parts List Description Code Main Frame 2A1205861 Left Footplate Bar 2A1205859 Right Footplate Bar 2A1205858 Front Stabilizer 2A1205856 Rear Stabilizer 2A1205857 Crank Connector 2A1205865 Magnet Bracket 2A1300077 2A1205863 Handle (L&R) 2A1205864 Idle Wheel Bracket 2A1300086 Fixed Handle 2A1300090 Front Post 2A1205862 Left Action Arm 2A1205863...
  • Page 25 Parts List Right Handle Cover 3C51JBG00660 Cross Bracket Axle Sleeve 3C59J00074 φ38×1.5mm Cone End Cap 3C51JBB00153 φ25×1.5mm Cone End Cap 3C51JBB00158 Water Bottle Bracket 3D600024 φ45×4mm D-hole Washer 3B53DIZ00013 φ32×4mm D hole Washer 3B53DIZ00017 φ45×φ11.8×9.5mm Bushing 3B800023 φ45×φ19×9.5mm Bushing 3B800024 T-shaped Knob 3C51JBD00042 φ23×φ29×390mm Handle Grip...
  • Page 26 Parts List M8×15mm Allen Bolt 3B51DBD00233 M10×20mm Allen Bolt 3B51DBD00205 φ10×69mm Allen Bolt 3B51DBD00219 ф11.5×67mm Allen Bolt 3B51DBD00207 M8×42mm Hex Bolt 3B51DBJ00095 M5×10mm Hex Bolt φ9×φ22×R19mm Arc Washer 3B53DIC00020 ST4.2×15mm Philips Screw 3B55DDD00003 ST4.2×15mm Philips Screw 3B55DDA00009 ST4.8×12mm Philips Screw 3B55DDD00006 φ20mm Corrugated Washer 3B53DIZ00009...
  • Page 27 Product Guarantee This product is guaranteed against manufacturing defects from a period of Year This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.
