Appendix C
Managing the display using RS-232
Enabling room control on the display
Configuring the computer's serial interface settings
Commands and responses
Power states
Commands
You can connect an RS-232 cable from a computer or a control system's serial output to the display's
RS-232 in connector to remotely select video inputs, turn the display on or off, and get information about
the display's current settings, such as volume and power state.
IMPORTANT
Use only a standard RS-232 cable. Do not use a null modem cable. Null modem cables typically have
ends of the same type.
smarttech.com/kb/171744
88
88
89
91
92
87
