ABB Ability Smart Sensor Installation Manual

—
I N S TA L L AT I O N G U I D E
ABB Ability
Installation with flat surface mount
ATTENTION
The Smart Sensor should be installed by technically
qualified personnel. Failure to install the sensor in
compliance with applicable codes and regulations
and according to the manufacturer's recommen-
dations may result in electrical shock, fire hazard,
unsatisfactory performance or equipment failure,
and may void the sensor warranty.
ATTENTION
The mounting piece must be grounded if the sensor
is installed in Ex Zone 0 or Zone 20 environments.
Grounding can be achieved by attaching a wire to
the M3 screw provided.
WARNING
Only qualified individuals who are familiar with
appropriate national codes, local codes and sound
practices should install, repair or modify electric
motors and/or related accessories. Installation
should conform to appropriate codes and practices.
Failure to follow these instructions could result in
serious personal injury, death and/or property damage.
Smart Sensor for hazardous areas
TM
It is important to read these
instructions in their entirety before
installing the ABB Ability™ Smart
Sensor for hazardous areas with flat
surface mount.
WARNING
Electrical live circuit hazard. Do not touch electrically
live parts or equipment. Disconnect, lock out and tag
out the motor's power supply before installing or
servicing the sensor.
CAUTION
Motor surface temperature hazard. The external
surface of an electric motor may reach temperatures
which can cause discomfort, burns or injury to indi-
viduals who come into contact with the hot surface.
For safety reasons the motor should be switched off
and allowed to cool before attempting to install the
sensor. Motor surface temperatures should only be
measured with suitable instruments and not estima-
ted by hand touch or direct skin contact. Failure to
observe this precaution could result in bodily injury.
CAUTION
Do not replace batteries! Incorrect use of batteries
voids the certifications of the Smart Sensor, such as
hazardous area certifications, safety certifications,
and IP rating. Dispose of used sensors according to
instructions.
