inbody BSM 370 Quick Reference page 2

6. Proper Posture
Turn your back towards the stand and stand
❶
on the foot plate.
Look straight ahead and stand upright.
❷
Do not lean on the stand.
While measuring, do not stain your body and
❸
maintain a relaxed posture.
Physically disabled persons or children should
not attempt to take measurements alone, but
WARNING
instead should get help by have a parent hold
them from the side or back to prevent injury or
incorrect measurement.
If the examinee leans on the stand, the weight
might get distributed and the results might be
NOTE
inaccurate. Be careful not to lean on the stand.
When you use thermal printer
Thermal printers are sold separately.
NOTE
Connect the thermal printer firmly to
❶
the thermal printer base.
Fasten 4 screws to fix them together.
Remove the sticker on the side of
❷
the stand. Adjust the thermal printer
tray's screw hole to the one of the
stand. And screw tightly.
Thermal printer cables must be
❸
connected in the same manner as
shown in the picture.
Place the printer paper as illustrated
❹
in the picture. Extend the paper one
inch out of the printer.
Only the thermal printer & the printer paper provided by InBody can be
used with the BSM370.
NOTE
Measurement Mode
Press the 'MODE' button in the home screen. Using ▲,▼,◀,▶ buttons,
select the mode to use. Press 'ENTER' to save the mode.
Weight : Weight measurement mode
: When the examinee steps on the foot
❶
plate, this screen shows the weight.
Height : Height measurement mode
: When the examinee steps on the foot
❷
plate, the height is automatically
measured.
: When the examinee steps on the foot
❸
plate, you can measure height by
pressing the 'ENTER' button.
BMI : Weight and Height measurement mode.
: When the examinee steps on the foot
❹
plate, the weight and height are
automatically measured.
: When the examinee steps on the foot plate, the weight is
❺
automatically measured. And then, you can measure height
by pressing the 'ENTER' button.
The default measurement mode is set as BMI
out of the factory.
NOTE
7. Results
When the test completed, the test result displays on LCD screen.
When the examinee steps out from the foot plate, BSM370 will return to the
home screen.
Please see the below example case when it is set for BMI
measurement mode.
When you use remote control device
Remote control devices are connected in the same manner as shown
in the picture.
SETUP
The setup menu consists of
Press the 'SETUP' button in the home screen. Press the ◀,▶ buttons to
move menu you want to modify. You can change it using▲,▼ buttons.
When you are finished with the modification, press the 'ENTER' button.
(1) WEIGHT OFFSET
Modifies the weight offset value. When you need to adjust weight due to
clothes and accessories, you can set a weight value to compensate and
the value will be reflected in the result.
❶
(2) UNIT: Select units to be used. (kg/cm, lb./in.)
(3) DATE & TIME: Set the current date and time.
❷ ❸
(4) SPEED
❹ ❺
❶
❷ NORMAL: Weight measurement complete when a examinee stay still
Max 250.0 kg / 553.3 lbs.
Min 2.0 / 4.5
kg lbs.
e 100 / 0.1
g lb.
InBody Co., Ltd. [HEAD OFFICE]
InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul 06106 KOREA
TEL: +82-2-501-3939
Website: https://www.inbody.com
InBody reserves the right to modify the dimensions or exterior of BSM370 to improve the
when the system is
quality of the products, without consent of the customer.
Max 250.0 / 553.3
kg lbs.
Min 2.0 / 4.5
kg lbs.
e 100 / 0.1
g lb.
NOTE
<Results Screen>
10cm(4in.) Cable
2m(6ft. 7in.) Cable
Remote control device are sold separately.
NOTE
weight offset, unit, date&time and
FAST: Weight measurement complete in four second regardless of
examinee's movement.
in stable position.
FAX: +82-2-578-2716
E-mail: info@inbody.com
automatic
<Thermal Printer Paper>
Customers in the US will be provided the
lb/in version of the LCD and result paper.
speed.
ⓒ2018 InBody Co., Ltd. All rights reserved. BM-ENG-98-G-181224
