Pneumatic Arm Monitor & Touch Screen Desk Stand
Instruction Manual
SKU: STAND-V001R
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001r
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V001R
Summary of Contents for Vivo STAND-V001R
- Page 1 Pneumatic Arm Monitor & Touch Screen Desk Stand Instruction Manual SKU: STAND-V001R Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001r GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 4.4-22lbs Failure to do so may result in serious injury. (2-10kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Assemble the monitor arm (B) to the lower arm (C) using M6x20 bolts (F), and tighten with the 4mm Allen wrench (G). Attach the cover (D) to the lower arm using the M4x8 bolt (E). - Page 4 STEP 2 Attach the assembled monitor arm to the base (A) using M6x20 bolts (F), and tighten with the 4mm Allen wrench (G). STEP 3 Insert 12mm bolts (M-A, M-B) with washers (M-C) into the top two mounting holes of the monitor, leaving 3mm of thread exposed.
- Page 5 STEP 4 Hang the monitor over the slots in the VESA mounting plate, insert two more bolts (M-A, M-B) with washers (M-C) into the lower two holes, and tighten with a Phillips screwdriver.
- Page 6 STEP 5 Adjust tilt support by removing the cap from the side and tightening the bolt underneath with the 6mm Allen wrench (H), then replace the cap. Route cables through the opening in the lower arm. STEP 6 To adjust gas spring support, hold the gas spring arm down to the straight-forward position and turn the adjustment screw using the 6mm Allen wrench (H).
- Page 7 Adjust as Desired...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
