Summary of Contents for Argos NOMAD 727/7290
- Page 1 Nomad Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 10/09/19...
- Page 2 ● Regularly check and ensure that all bolts and fittings are tighten properly. ● This product is compliant EN12521 Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales).
- Page 3 Fittings (Shown to scale) Bag 1 7 x 30mm Screw x 10 5 x 50mm Screw x 6 4 x 40mm Screw x 8 7 x 39mm Locking Pin x 16 8 x 30mm Dowel x 12 Tube Cover x 6 15 x 12mm Locking Nut x 16 4 x 24mm Screw x 4...
- Page 4 Hardware 450mm Outside Runner x 4 450mm Inside Runner x 4 958 x 20 x 20mm 375 x 20 x 20mm Lagre Upper Support x 1 Bottom Support x 2 960 x 20 x 20mm Lagre Bottom Support x 1 586 x 725 x 20mm Lagre Left Post x 1 163 x 586 x 20mm...
- Page 5 Tools required Phillips screwdriver Ruler/tape (small & medium) measure Phillips screwdriver Eye protection (small & medium) (when using a hammer or glue) Small hammer Power Drill Large hammer Pencil Drill Heads Mallet Set Square Spirit Level...
- Page 6 Panels Small Back (382 x 118mm) Top (1400 x 596mm) Drawer Front (375 x 197mm) Bottom (420 x 596mm) Drawer Back (331 x 160mm) Drawer Right Side (500 x 160mm) Right Side (590 x 543mm) Drawer Left Side (500 x 160mm) Left Side (590 x 543mm) Drawer Bottom (340 x 493mm) Middle Panel (382x 588mm)
- Page 7 7 x 30mm Screw x 10 5 x 50mm Screw x 6 4 x 40mm Screw x 8 7 x 39mm Locking Pin x 4 8 x 30mm Dowel x 4 Tube Cover x 6 7 x 39mm Locking Pin x 16 8 x 30mm Dowel x 12 15 x 12mm Locking Nut x 16 4 x 24mm...
- Page 8 8 x 30mm Dowel x 8 15 x 12mm Locking Nut x 2...
- Page 9 15 x 12mm Locking Nut x 2 Finished bottom surface...
- Page 10 5 x 50mm Screw x 6 Tube Cover x 4 Allen Key x 1 6 x 15mm Screw x 5 163 x 586 x 20mm Right Post x 1 40 x 17 x 17mm 375 x 20 x 20mm Metal Connector Bottom Support x 2 163 x 586 x 20mm Left Post x 1...
- Page 11 Allen Key x 1 7 x 30mm Screw x 4 Rotate Product 5 x 37mm Screw x 1 Allen Key x 1 6 x 15mm Screw x 1 958 x 20 x 20mm Lagre Upper Support x 1 960 x 20 x 20mm Lagre Upper Support x 1...
- Page 12 Tube Cover x 2 Allen Key x 1 6 x 15mm Screw x 2 586 x 725 x 20mm Lagre Left Post x 1 7 x 39mm Locking Pin x 4...
- Page 13 Allen Key x 1 7 x 30mm Screw x 6 15 x 12mm Locking Nut x 4 Bracket x 4 Rotate Product...
- Page 14 4 x 33mm Screw x 2 4 x 14.5mm Screw x 2 Wall Plug x 2 Wall Strap x 2 7 x 39mm Locking Pin x 8 Repeat...
- Page 15 15 x 12mm Locking Nut x 8 Repeat 4 x 40mm Screw x 8 Unfinished bottom surface Repeat Repeat...
- Page 16 450mm Inside Runner x 4 3 x 12mm Screw x 12 FRONT Repeat 4 x 24mm Screw x 4 160 x 20 x 16mm Handle x 2 Repeat...
