Hitachi E-Compact Medium Power Series Operation Manual page 75

8 7
H
08
G
F
E
D
C
Fix the filter hanger clamp
on the cabinet rod.
B
A
8 7
6 5
Screw in the filter on
the cabinet top.
6 5
4 3
E-Compact Medium Power
08
4 3
2 1
REF DESCRIPTION
08 MOD 40243 - EIA 1-5/8" low pass filter
EC702MP / EC704MP
LOW PASS FILTER INSTAL
