Lyric Controller Programming Guide

Program Zones

The Lyric supports both Honeywell 5800 Series and SiX™ Series Bi-Directional sensors. The steps required to
enroll these sensors differ. It should be noted that once a SiX™ Series sensor has been enrolled in the panel it
must be deleted before it can be enrolled in a different panel. Refer to deleting Wireless Zones or Keys section
for additional information. A Zone Descriptor should be assigned to each enrolled device to ensure that Zones
can be easily identified.
Batch learning Mode - Multiple SiX™ Series sensors can be enrolled using the Batch Learning Mode. Refer to the
Batch Learning Enrollment section for additional information.
Before enrolling SiX™ Series sensors, ensure that the Lyric Controller has been updated with the
latest firmware version.
Programming Field
Zones
Serial Number
˅
Use the down " " arrow to scroll to the next page of options or the "
return to the previous page.
1. New
3. Front Door
5. Window
7. New
9. – 126. New
127. – 130. New (Main) (reserved for Garage Door Zones)
131. – 162. (Button Zones)
280. – 291. Temperature (Z-Wave Thermostat zones)
850. – 857. SiX™ Keypads
995. Fire
996. Medical
998. Local Alarm
999. Police
Select a zone and then select "Edit" or "Add New" to program the next available zone.
The following fields are displayed (dependent upon selected Zone).
NOTE: This field does not apply to Hardwire Zone 1 and 2 or Temperature Zones 280-291
When "Serial Number" has been selected "Enter Serial Number or Activate" is
displayed. Follow the applicable steps below to enroll the SiX™ or 5800 Series sensors.
Enroll SiX™ Series Devices (Refer to the documentation provided with the specific
SiX™ device being enrolled for additional information.)
Enroll via RF Learning
1. Insert the battery in the sensor or pull the battery tab as applicable. The sensor's
green LED will flash rapidly. Allow up to 20 seconds for pairing to complete. If the
sensor has been successfully paired with the control, the sensor's green LED will
light steady for three seconds and the control will beep once to confirm. If the
pairing is not successful, remove the battery and repeat this step.
2. Two transmissions (open/close) of the device will be required. The device serial
number is displayed on the screen following the first transmission and the panel
beeps two times. Following the second transmission the system beeps three times
and returns to the Zone Programming Screen.
3. The device's battery level and signal strength is displayed on the Lyric control's
Zones programming screen. For additional information regarding signal strength
refer to the Installation & Reference Guide.
Enroll Six Series Devices Manually
1. Select the "RF Type" to scroll through the available Six Series device types:
Contact
Glass Break
Motion
Smoke
Wireless Siren
2. Enter the 16-digit serial number (MAC ID) printed on the transmitter using the
displayed keypad and select "Done".
NOTE: Enter only the 16 alpha-numeric characters.
Function and Action
2. New
4. Back Door
6. Motion Sensor
8. New
- 12 -
˄
