3M™ Drive-Thru System Model G5
Q. Split- and Cross-Lane Mode
In any Dual-Lane installation (tandem, side-by-side, or dual drive-thrus), the system can be configured to operate registered headsets in
Split- or Cross-Lane Mode. The difference between Split-Lane and Cross-Lane modes in this situation is:
• Split-Lane mode is intended for a drive-thru with two order takers. Each order taker hears beeps only for the lane for which the
headset is configured. Beeps from the other lane will not be heard.
• Cross-Lane mode is intended for a drive-thru with one order taker who will hear beeps for both lanes on one headset. You can
configure the system to permit non-order takers to hear orders and pages from one or both sides. See "Order Takers and Page
Messages in Cross-Lane Mode" on page 40.
R. Installer Setup
Installer setup is a special group of setup options typically only used by the installer.
Load Installation Settings
Installation settings are a complete set of configuration data that the installer can save after the initial installation configuration is completed.
It is essentially a backup save point in case configuration settings are inadvertently changed in ways that are not easy to identify or correct.
To load the installation settings:
i
IMPORTANT NOTE
By performing this procedure, you will be erasing the current configuration and reloading the configuration that was last saved, likely
when the system was first installed.
• Enter the configuration mode (see "Enter Configuration Mode" on page 28) and choose 1 System Menu.
• Select 14 Installer Setup.
• Change the value for Load Installation Settings to Yes.
• The system will then reboot.
Save Installation Settings
i
IMPORTANT NOTE
This function is only available to installers.
Perform the following procedure to save the current configuration into permanent memory over the existing installation settings:
i
IMPORTANT NOTE
By performing this procedure you will be erasing the existing saved installation settings, making it impossible to revert to the settings
that were saved after installation.
• Enter the configuration mode (see "Enter Configuration Mode" on page 28) and choose 1 System Menu.
• Select 14 Installer Setup.
• Change the value for Save Installation Settings to Yes.
44
Installation Instructions G5 - Revision C, September 2019
