DELLA 048-GM-48265 User Manual

14000 btu portable air conditioner
Hide thumbs Also See for 048-GM-48265:
Table of Contents

Advertisement

Quick Links

14000 BTU PORTABLE AIR CONDITIONER
Model# 048-GM-48265
USER'S MANUAL
⚠CAUTION! WARNING: Do not use this device before reading these instructions.
Congratulation on your purchase of this DELLA protable Air Conditioner.
NOTICE:
If you are missing any parts or have any questions or concerns regarding installation, please call DELLA customer service
at 1-800-863-4143.
Have this manual open and ready for reference
CUSTOMER SERVICE:
manufacturer@dellausa.com
1-800-863-4143
www.dellausa.com
9:00AM - 6:00PM PST (Monday - Friday)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 048-GM-48265 and is the answer not in the manual?

Questions and answers

Related Manuals for DELLA 048-GM-48265

Summary of Contents for DELLA 048-GM-48265

  • Page 1 Congratulation on your purchase of this DELLA protable Air Conditioner. NOTICE: If you are missing any parts or have any questions or concerns regarding installation, please call DELLA customer service at 1-800-863-4143. Have this manual open and ready for reference CUSTOMER SERVICE: manufacturer@dellausa.com...
  • Page 2 WARNING When using electrical appliances, basic safety precautions should always be followed including the following: READ ALL INSTRUCTIONS BEFORE USE 1. DO NOT shake, hit, or damage the appliance. 15. DO NOT unplug the unit by pulling the power cord. 2.
  • Page 3 USER TIPS Portable Air conditioner is ideal for spot cooling. The compressor, condenser, and evaporator are built in a compack unit. The air is dehumidified and cooled while a flexible hose release heat outside. Permanent installation is not necessary, This protable air conditioner is easy to move from room to room and offers a wide range of air conditioning solution.
  • Page 4 DIAGRAM Air Outlet Control Panel Air Filter Remote Control Storage Exhaust Handle Air Filter Air Filter Water Drain Wheels Power Cord Exhaust Connector Exhaust Hose Window Adapter Remote Control Window Slider Kit...
  • Page 5 INSTALLATION GUIDE Exhaust Installation The air conditioner needs to be installed next to a window and connect the exhaust hose from the unit to the window. TOOLS NEEDED HARDWARE ESTIMATED TIME NEEDED 15 mins 2 person assembly 1. Extend the exhaust hose and attach the connector to one end. 2.
  • Page 6 INSTALLATION GUIDE (CONTINUE) 3. Attach the window adapter to the other end of the exhaust hose. 4. Attach the window adapter to the window slider kit.
  • Page 7 INSTALLATION GUIDE (CONTINUE) 5. Adjust the length of the window slider kit according to your window.
  • Page 8 INSTALLATION GUIDE (CONTINUE) Window Kit Installation 1. Open the window sash and place the window kit horizontally on the stool / vertically against the jamb. Adjust the length of the kit accordingly. 2. Close the window sash on the window kit. NOTE: Cut the window kit if the window width is shorter than the minimum length of the window kit.
  • Page 9 INSTALLATION GUIDE (CONTINUE) Grounding This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a power supply cord that has a three-pronged grounded plug. It must be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and applicable local codes and ordinances.
  • Page 10 USER INSTRUCTION (CONTROL PANEL / REMOTE CONTROL) POWER Turn ON / OFF the unit. MODE Cycle between cooling, heating, fan, dehumidifying, and fan mode. UP / DOWN Increase / decrease temperature or timer setting. SPEED Toggle between fan speed. TIMER Set turn ON / turn OFF timer.
  • Page 11 USER INSTRUCTION (OPERATING) Power ON/ OFF Plug the unit to a grounded socket. The display window will show the ambient temperature and turn into stand-by mode. Press the POWER button once to turn on the unit. The unit will automatically runs in COOL mode with set temperature 22°c / 72°f.
  • Page 12 USER INSTRUCTION (OPERATING) Turn ON Timer Press the timer button once when the unit is in stand by mode. (Plugged into power but have not power on) Press button to set your desire time from 0.5 - 20 hours. (0.5 hour increment) Press the timer button again to cancel the setting.
  • Page 13 USER INSTRUCTION (REMOTE BATTERY) Insert or Replace Batteries on Remote Control Remove the cover on the back of the remote control. Replace the old batteries with two new AAA 1.5V alkaline batteries. Replace the cover. NOTE: Remove the batteries if the remote control is not use for an extended period of time. ⚠CAUTION! WARNING: DO NOT mix old and new batteries.
  • Page 14 USER INSTRUCTION (WI-FI FUNCTION) Wi-Fi function Your air conditioner is built with a wi-fi function and you can control the unit using smart phone application. Make sure your mobile device is connected to a Wi-Fi router and the internet. 1. Scan the QR code or search “Tuya Smart” in app store. 2.
  • Page 15 USER INSTRUCTION (WI-FI FUNCTION) 3. Add your device by selecting “Air Conditioner” in “Large Home Appliance” category .
  • Page 16 USER INSTRUCTION (WI-FI FUNCTION) 4. Touch the “Timer button” on the air conditioner control panel for 5 seconds. The wi-fi icon should blink rapidly. 5. Tab “confirm indicator rapidly blink” on your phone. 6. Enter wi-fi password and confirm.
  • Page 17 USER INSTRUCTION (WI-FI FUNCTION) 7. Wait until the device is successfully added. 8. Once completed, you can control your unit via your phone such as set timer, change mode, set temperature, and set some extra functions. *Instruction on this manual reguarding the wifi function is based on the ver. of the app at the time writen. Follow the in-app instruction in the event of app update.
  • Page 18 CARE AND MAINTENANCE (WATER DRAINAGE) Condensate will residue inside the unit when operate. Tank full indicator will display on the display windows once the tank is full. Drain the water to keep the unit working properly. 1. Unplug the unit from all power source. 2.
  • Page 19 CARE AND MAINTENANCE (AIR FILTER) Cleaning the air filter Air filter need to be cleaned to keep the air conditioner working efficiently. 1. Unplug the unit from all power source. 2. Remove the filter from the unit. 3. Gentle immerse the filter in warm water. 4.
  • Page 20 CARE AND MAINTENANCE (STORAGE) Store your unit if not use for an extended period of time against wear and damage. 1. Turn off and unplug the unit from all power source. 2. Drain the water tank completely following the draining instruction. 3.
  • Page 21 TROUBLESHOOTING Problem Possible Reasons Solutions Make sure the unit is plugged into No Power a grounded power socket Water tank is full Drain the water Recommended ambient Unit does not work Ambient temperature is too temperature is 7°c - 40°c high / low / 45°f - 105°f Room temperature already meet...
  • Page 22 ERROR CODE CHART Error Code Description Solution Check the room temperature sensor and CH01 Room temperature sensor failure related circuit Check the tube temperature sensor and CH02 Tube temperature sensor failure related circuit The unit will restore all function automatically Anti-Freeze protection activated once the anti-freeze protection is over Water Tank Full...
  • Page 23 All returns must be shipped back to DELLA return center at the customer’s expense. If the reason of return is a result of an error by DELLA, DELLA will provide a pre-paid shipping label via-email. Boxes for return will not be provided by DELLA. Customer will be responsible to use the original boxex or purchase new boxes.
