1473-1-7978 │
│ 14.06.2012
DALI potentiometer for broadcast operation
Pos: 2 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Titelblätter/Dimmer/Titelblatt - 2117 U @ 23\mod_1336123192553_15.docx @ 208974 @ @ 1
DALI potentiometer for
broadcast operation
Insert 2117 U-500
Insert 2117/11 U-500
=== Ende der Liste für Textmarke Cover ===
Advertisement
Table of Contents
Related Manuals for ABB 2117 U-500
Summary of Contents for ABB 2117 U-500
- Page 1 1473-1-7978 │ │ 14.06.2012 DALI potentiometer for broadcast operation Pos: 2 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Titelblätter/Dimmer/Titelblatt - 2117 U @ 23\mod_1336123192553_15.docx @ 208974 @ @ 1 DALI potentiometer for broadcast operation Insert 2117 U-500 Insert 2117/11 U-500 === Ende der Liste für Textmarke Cover ===...
-
Page 2: Table Of Contents
DALI potentiometer for broadcast operation Pos: 4 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Inhaltsverzeichnis (--> Für alle Dokumente <--)/Inhaltsverzeichnis @ 19\mod_1320649044386_15.docx @ 109653 @ @ 1 Safety ..................................3 Intended use ................................3 Environment ................................3 Operation ................................. 4 Dimming speed ............................4 Adjusting the basic brightness ........................ 4 Deleting the basic brightness ........................ -
Page 3: Safety
Pos: 10 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Bestimmungsgemäßer Gebrauch/Dimmer/Bestimmungsgemaesser Gebrauch - 2117 @ 21\mod_1331202666263_15.docx @ 201942 @ @ 1 DALI potentiometer 2117 U-500 and 2117/11 U-500 are used for light control in connection with DALI operating devices according to IEC 62386, e.g., DALI electronic ballast units. No other DALI controllers must be combined with DALI potentiometer 2117 U-500 and 2117/11 U-500. -
Page 4: Operation
DALI potentiometer for broadcast operation Operation Pos: 13 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/1. Ebene/A - F/Bedienung @ 11\mod_1279185541649_15.docx @ 83043 @ 1 @ 1 Operation Pos: 14 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Bedienung/Dimmer/Bedienung - 2117 @ 21\mod_1331210626890_15.docx @ 202059 @ 222222222 @ 1 Dimming speed Fig. -
Page 5: Deleting The Basic Brightness
DALI potentiometer for broadcast operation Operation Deleting the basic brightness 10 Sec. Fig. 4: Turn the control element slowly to delete the basic brightness. 1. Switch the lighting off. 2. Press the control element for 10 seconds. The load flashes once after the setting has been made. Activation with memory function At the factory, the DALI potentiometers are set to always switch on the illumination using the last brightness set (memory function). -
Page 6: Deleting The Switch-On Brightness
DALI potentiometer for broadcast operation Operation Deleting the switch-on brightness 2x Click Fig. 6: To delete a fixed switch-on brightness carry out the following steps: 1. Switch the lighting on. 2. Double click fast on the control element. The load flashes twice after the setting has been made. After the deletion of the switch-on brightness, the memory function continues to work (activation with the last brightness before deactivation). -
Page 7: Changing The Power-On Level (Optional Setting)
DALI potentiometer for broadcast operation Operation Changing the power-on level (optional setting): Press 10 Sek. Fig. 8: Changing the power-on level (switch-on brightness after mains power failure) effects a uniform brightness or deactivation of all connected operating devices with the last set brightness value before the power failure. To change the power-on level carry out the following steps: 1. -
Page 8: Technical Data
Pos: 16 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/1. Ebene/S - T/Technische Daten @ 11\mod_1279185386320_15.docx @ 83019 @ 1 @ 1 Technical data Pos: 17 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Technische Daten/Dimmer/Technische Daten - 2117 @ 21\mod_1331203423023_15.docx @ 201983 @ @ 1 2117 U-500 " Nominal voltage: 9.5 –... -
Page 9: Setup And Function
Pos: 21 /#Neustruktur#/Online-Dokumentation/Aufbau und Funktion/Dimmer/Funktionen - 2117 @ 21\mod_1331205101538_15.docx @ 201999 @ @ 1 DALI potentiometer 2117 U-500 and 2117/11 U-500 are used to control the brightness of connected DALI operating devices (e.g., DALI electronic ballast units, DALI LED modules, etc). -
Page 10: Installation And Electrical Connection
DALI potentiometer for broadcast Installation and electrical operation connection Pos: 25 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/1. Ebene/M - O/Montage und elektrischer Anschluss @ 23\mod_1336477157864_15.docx @ 209033 @ 1 @ 1 Installation and electrical connection Pos: 26 /#Neustruktur#/Online-Dokumentation/Sicherheitshinweise und Hinweise (--> Für alle Dokumente <--)/Warnhinweise/Sicherheit - Niederspannungs- und 230 V-Leitungen @ 23\mod_1336558868201_15.docx @ 209164 @ @ 1 Warning Electric voltage! Risk of death due to electrical voltage of 230 V during short-circuit in the low-voltage line. -
Page 11: Mounting
DALI potentiometer for broadcast Installation and electrical operation connection Pos: 30 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/2. Ebene/M - O/Montage @ 18\mod_1302615960458_15.docx @ 103424 @ 2 @ 1 Mounting Pos: 31 /#Neustruktur#/Online-Dokumentation/Sicherheitshinweise und Hinweise (--> Für alle Dokumente <--)/Warnhinweise/Sicherheit - 230 V @ 18\mod_1302606816750_15.docx @ 103308 @ @ 1 Warning Electric voltage! Risk of death and fire due to electrical voltage of 230 V. -
Page 12: Electrical Connection
Pos: 35 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/2. Ebene/A - F/Elektrischer Anschluss @ 21\mod_1328177051724_15.docx @ 138042 @ 2 @ 1 Electrical connection Pos: 36 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Anschluss/Dimmer/Anschluss - 2117 @ 21\mod_1331205283908_15.docx @ 202014 @ @ 1 Fig. 10: Function DALI power supply 2 DALI operating device 2117 U-500 | 1473-1-7978 — 12 —... - Page 13 L and N must not be assigned. The device is then supplied with current directly from the bus. ● Up to 3 DALI potentiometers 2117/11 U-500 and 5 DALI potentiometers 2117 U-500 can be operated in parallel. In the process, observe the maximum permissible power consumption. ●...
- Page 14 PO box contents of this document without prior notice. 58505 Lüdenscheid The detailed specifications agreed to at the time of ordering apply to all orders. ABB accepts no Freisenbergstraße 2 responsibility for possible errors or 58513 Lüdenscheid incompleteness in this document.
