Sealey LS370H Instructions For Use

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instructions protection
1. safety
1.1. electrical safety
Warning! it is the user's responsibility to check the following:
‰
check all electrical equipment and appliances to ensure that they are safe before using. inspect power supply leads, plugs and
all electrical connections for wear and damage. sealey recommend that an rcd (residual current device) is used with all electrical
products. You may obtain an rcd by contacting your local sealey dealer.
if used in the course of business duties, it must be maintained in a safe condition and routinely PAt (Portable Appliance test) tested.
electrical safety information, it is important that the following information is read and understood.
ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9
regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
9
Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the correct fuse - see
9
fuse rating in these instructions.
Do not pull or carry the appliance by the power cable.
8
Do not pull the plug from the socket by the cable.
8
Do not use worn or damaged cables, plugs or connectors. ensure that any faulty item is repaired or replaced immediately by a
8
qualified electrician.
This product is fitted with a BS1363/A 13 Amp 3 pin plug.
9
if the cable or plug is damaged during use, switch off the electricity supply and remove from use.
Ensure that repairs are carried out by a qualified electrician.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualified electrician.
a) Connect the GREEN/YELLOW earth wire to the earth terminal 'E'.
b) Connect the BROWN live wire to the live terminal 'L'.
c) Connect the BLUE neutral wire to the neutral terminal 'N'.
ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
Sealey recommend that repairs are carried out by a qualified electrician.
1.2. general safety
maintain the log splitter in good condition (use an authorised service agent).
9
replace or repair damaged parts. use genuine parts only. unauthorised parts may be dangerous and
9
will invalidate the warranty.
use a qualified person to lubricate and maintain the log splitter.
9
Do not use brake fluid to top up hydraulic unit.
8
locate the log splitter in a suitable work area, keep area clean and tidy and free from unrelated materials, and ensure that there is
9
adequate lighting.
Keep the log splitter clean for best and safest performance.
9
remove ill fitting clothing. remove ties, watches, rings and other loose jewellery, and contain long hair.
9
Maintain correct balance and footing, do not over-reach. Ensure the floor is not slippery and wear non-slip, protective footwear.
9
Keep children and unauthorised persons away from the work area.
9
Do not use the log splitter for a task it is not designed to perform.
8
Do not operate the log splitter if damaged.
8
Do not exceed the stated log capacity of the log splitter.
8
Do not operate the log splitter when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
Do not allow untrained persons to operate the log splitter.
8
Do not make any modifications to the log splitter.
8
Do not operate the log splitter in wet or damp areas or expose it to rain.
8
Do not operate the log splitter in areas where fumes from paint, solvents, or flammable liquids pose a potential hazard.
8
Do not operate the log splitter with the guards or guides removed.
8
Do not operate the log splitter on the ground as this will bring the operator's face too close to the machine where there is danger of
8
being struck by flying wood chips or debris.
Place the log splitter on a stable, flat and level workbench 60 to 75cm high where there is plenty of room for handling. Bolt the log
9
splitter to the bench if it tends to slip, walk or slide.
© Jack sealey limited
instructions for
horizontal log splitter 4 tonne 370mm
& 5 tonne 520mm capacity
model no:
Wear protective Wear safety
gloves footwear
Original Language Version
ls370h & ls520h
Keep in dry area
protect from rain
recommended fuse rating
13 Amps
lS370H, LS520H | Issue 4 02/05/17
