AVENTOS HL
Lift mechanism set
Cover set
Arm assembly set
Oval stabilizer rod
NOTE:
For▀cabinets▀wider▀than▀48"▀two▀stabilizer▀rods▀and▀stabilizer▀rod▀connector▀set▀required▀
Wood/wide aluminum door hardware set
▀Arm▀assembly▀mounting▀plate▀(qty▀2)
▀
▀
Wood/wide▀aluminum▀hardware▀set
Installation▀screw▀for▀wood▀doors
Installation▀screw▀for▀aluminum▀
Wood/wide aluminum
hardware set
Lift▀mechanism▀(qty▀2)
▀
▀
#7▀x▀35▀mm▀(1-3/8")▀wood▀screw▀(qty▀10)▀
▀
▀
Right▀and▀left▀cover▀plate
▀
▀
Non-handed▀cover▀caps
▀
▀
Cover▀set
Right▀and▀left▀arm▀assembly
▀
▀
Stabilizer▀rod▀cover▀cap▀(qty▀2)
▀
▀
Cabinet▀height
300 (11-13/16")
— 349 (13-3/4")
350 (13-13/16")▀ — 399 (15-13/16")
400 (15-3/4")▀
— 550 (21-5/8")
450 (17-11/16")▀ — 580 (22-13/16")
Oval▀stabilizer▀rod
▀
▀
Aluminum▀rod▀length▀1061▀(41-3/4"),▀cut▀to▀size
▀
▀
Length▀ = ▀interior▀cabinet▀opening▀minus▀129▀(4-13/16")▀▀▀▀
▀
▀
Oval▀stabilizer▀rod
Mounting plate with bracket set
Part▀no.
20S4200
606N or 606P
7072A
Plate▀with▀bracket▀set
Subject to technical modifications without notice. © 2015
Mounting▀plate▀with▀bracket▀(left▀
▀
▀
and▀right)
For▀large▀overlay▀five-piece▀doors
▀
▀
20L2100.N5
20L2300.N5
20L2500.N5
20L2700.N5
20L2900.N5
Part▀no.
20L8000.N1
Part▀no.
20L3200.06
20L3500.06
20L3800.06
20L3900.06
▀▀ Part▀no.
20Q1061UA
Part▀no.
20S4F01
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVENTOS HL and is the answer not in the manual?

Questions and answers

Related Manuals for BLUM AVENTOS HL

Summary of Contents for BLUM AVENTOS HL

  • Page 1 AVENTOS HL Wood/wide aluminum hardware set Lift mechanism set Lift▀mechanism▀(qty▀2) ▀ ▀ #7▀x▀35▀mm▀(1-3/8")▀wood▀screw▀(qty▀10)▀ ▀ ▀ 20L2100.N5 20L2300.N5 20L2500.N5 20L2700.N5 20L2900.N5 Cover set Right▀and▀left▀cover▀plate ▀ ▀ Non-handed▀cover▀caps ▀ ▀ Part▀no. Cover▀set 20L8000.N1 Arm assembly set Right▀and▀left▀arm▀assembly ▀ ▀ Stabilizer▀rod▀cover▀cap▀(qty▀2) ▀ ▀...
  • Page 2 Assembly WARNING Risk▀of▀injury▀from▀spring-loaded▀arm Do▀not▀push▀arm▀assembly▀down▀or▀leave▀in▀the▀down▀position ▀ ▀ Remove▀mechanism▀before▀installing▀or▀removing▀cabinet ▀ ▀ Locating pin locations and minimum depth Panel Face frame 1 9 2 m i n 5 6 m i n 2 7 NOTE:▀Face▀frame▀cabinets▀must▀be▀ blocked▀out▀flush▀with▀the▀frame Part▀no. Universal▀individual▀template▀is▀available▀for▀pre-boring▀5▀mm▀locating▀pins 65.1051.02 Attaching the lift mechanism Align▀the▀lift▀mechanism▀in▀the▀cabinet▀using▀the▀5 mm▀locator▀pins▀and▀attach▀the▀mechanism▀with▀the▀five▀...
  • Page 3 Attaching the arm assembly Risk▀of▀injury▀from▀spring▀loaded▀arm NOTE:▀Before▀starting,▀see▀safety▀note▀on▀page▀2 Find▀the▀right▀and▀left▀arm▀assemblies▀and▀▀ match▀them▀to▀the▀correct▀side▀of▀the▀cabinet Attach▀the▀arm▀assembly▀to▀the▀lift▀mechanism▀▀ Lift▀up▀on▀the▀arm▀assembly▀to▀lock▀into▀place. as▀shown▀in▀illustrations.▀ Attaching the stabilizer rod Cut▀the▀stabilizer▀rod▀to▀fit▀the▀cabinet. Length▀=▀Interior▀cabinet▀opening▀minus▀129▀(5-1/16") After▀cutting▀the▀rod▀to▀size,▀slide▀the▀stabilizer▀arm▀cover▀caps▀onto▀the▀rod.▀Attach▀the▀stabilizer▀ rod▀to▀spring▀loaded▀arm▀assembly▀then▀slide▀stabilizer▀arm▀cover▀caps▀over▀rod▀on▀each▀end.▀ Subject to technical modifications without notice. © 2015...

  • Page 4: Attaching▀The▀Mounting▀Plates

    Assembly Attaching▀the▀mounting▀plates For Wood/wide alumuminum doors For five-panel doors ü 12.5 more▀than 6 Standard▀mounting▀plate▀works 12.5 + Overlay 12.5 less▀than 6 Standard▀mounting▀plate▀does▀not▀work ü 12.5 Arm▀assembly 20L3200.06 20L3500.06 20L3800.06 Use▀mounting▀plate▀with▀bracket▀when▀panel▀ 20L3900.06 is▀less▀than▀6 mm▀from▀screw NOTE:▀All▀four▀screws▀must▀be▀installed Part▀no. 20S4200 20S4F01 Mounting▀plate Mounting▀plate 606N or 606P 606N or 606P Installation▀screw Installation▀screw...
  • Page 5 Adjusting the lift mechanism tension Use▀a▀screw▀gun▀with▀a▀#2x2▀POZI▀driver▀bit▀to▀adjust▀the▀lift▀mechanism▀to▀the▀desired▀tension.▀ The▀tension▀should▀be▀the▀same▀on▀both▀lift▀mechanisms. Adjusting the door Use▀a▀POZI▀screwdriver▀to▀adjust▀cam▀adjustments▀for▀each▀of▀the▀three-dimensional▀adjustments. Attach covers Snap▀the▀symmetrical▀cover▀caps▀on▀each▀cover▀plate.▀Place▀the▀left▀and▀right▀cover▀plates▀over▀ the▀appropriate▀lift▀mechanisms▀and▀snap▀them▀in▀place. Subject to technical modifications without notice. © 2015...
  • Page 6 Removal WARNING Risk▀of▀injury▀from▀spring-loaded▀arm Do▀not▀push▀arm▀assembly▀down▀or▀leave▀in▀the▀down▀position ▀ ▀ Remove▀mechanism▀before▀installing▀or▀removing▀cabinet ▀ ▀ Removing the door Open▀the▀door.▀Support▀the▀door▀with▀one▀ Lift▀the▀door▀off▀the▀mounting▀plates. hand▀and▀push▀down▀on▀tab▀to▀disengage▀the▀ CLIP▀mechanisms▀on▀the▀arm▀assemblies▀of▀ the▀mounting▀plates. Remove the covers Remove▀the▀cover▀caps▀and▀cover▀plate. Subject to technical modifications without notice. © 2015...
  • Page 7 Vystřelující ramena jsou zdrojem not glue the Blum dista Remove the stabilizer rod nce bumper / Ne pas encoller la butée Blum / Warnung / Warning / Attention / Attenzione / Advertencia / Ostr zeżenie / Risiko for at komme til skade ved oduzca el distanciado r de amortiguación de Blum /...

  • Page 8: Other Information

    146.5 .531 13.5 20L3800.06 400 (15-3/4”) – 550▀(21-5/8”) 178.5 .563 20L3900.06 450 (17-11/16”) – 580▀(22-13/16”) .594 *based▀on▀top▀and▀bottom▀reveals▀of▀0▀mm▀–▀B▀and▀Z▀dimensions▀can▀be▀±▀15▀mm▀ .625 due▀to▀range▀of▀adjustment,▀overpush▀and▀accuracy▀of▀installation .656 .688 17.5 .719 .781 .813 20.5 .844 .875 Blum,▀ Inc. .906 800-438-6788 sales.us@blum.com .938 blum.com .969 24.5 25.4 Subject▀to▀technical▀modifications▀without▀notice.▀©▀2015 INST-AVT10-04.15...
