Robustel R1510 User Manual

Industrial cellular vpn router 2 ethernet + 1 di + 1 do
Hide thumbs Also See for R1510:
Table of Contents

Advertisement

Quick Links

i

User Guide

R1510
Industrial Cellular VPN Router
2 Ethernet + 1 DI + 1 DO
Guangzhou Robustel LTD
www.robustel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R1510 and is the answer not in the manual?

Questions and answers

Related Manuals for Robustel R1510

Summary of Contents for Robustel R1510

  • Page 1: User Guide

    User Guide R1510 Industrial Cellular VPN Router 2 Ethernet + 1 DI + 1 DO Guangzhou Robustel LTD www.robustel.com...
  • Page 2 The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use of this document.
  • Page 3 Robustel accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the router, or for failure of the router to transmit or receive such data.
  • Page 4 Robustel R1510 User Guide Protecting Your Router To ensure error-free usage, please install and operate your router with care. Do remember the following: Do not expose the router to extreme conditions such as high humidity / rain, high temperature, direct sunlight, ...
  • Page 5 People's Republic of China, and can also be used for reference in the logistics process of electronic and electrical products. The orange logo below is used for Robustel products: Indicates its warning attribute, that is, some hazardous substances are contained in the product.
  • Page 6 Robustel R1510 User Guide Table 3: Toxic or Hazardous Substances or Elements with Defined Concentration Limits Name of the Hazardous Substances Part (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) (DEHP) (BBP) (DBP) (DIBP) Metal parts Circuit modules Cables cable assemblies Plastic...
  • Page 7 Robustel R1510 User Guide Document History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Date Firmware Version Document Version Change Description Dec. 18, 2019 3.1.1 v.1.0.0 Initial release Dec. 31, 2019 3.1.1...

  • Page 8: Table Of Contents

    Robustel R1510 User Guide Contents Contents ................................8 Chapter 1 Product Overview ......................... 10 Introduction.............................. 10 Package Contents ............................. 10 Specifications ............................12 Dimensions ............................... 13 Chapter 2 Hardware Installation ........................14 Pin Description ............................14 LED Indicators ............................14 Reset Button .............................
  • Page 9 Robustel R1510 User Guide 4.5.1 Syslog ..............................95 4.5.2 Event ..............................97 4.5.3 NTP ..............................100 4.5.4 SMS ..............................101 4.5.5 Email ............................... 102 4.5.6 DDNS ............................... 103 4.5.7 SSH ..............................104 4.5.8 Web Server ............................. 105 4.5.9 Advanced ............................106 System ..............................

  • Page 10: Chapter 1 Product Overview

    Chapter 1 Product Overview 1.1 Introduction Robustel’s R1510 router is a Dual Ethernet port (LAN + WAN) 3G/4G router with advanced software functions at a very competitive price point. The R1510 has many unique software innovations including, but not limited to: RobustVPN –...
  • Page 11 AC/DC power adapter (12V DC, 1 A; EU/US/UK/AU plug optional)  1 x SIM Card Sticker Note: If any of the above items is missing or damaged, please contact your Robustel sales representative. Optional Accessories (sold separately)  Wall mounting kit ...

  • Page 12: Specifications

    Robustel R1510 User Guide  Ethernet cable 1.3 Specifications Cellular Interface Number of antennas: 2 external antenna(MAIN + AUX)  Connector: SMA-K  SIM: 1 (3 V & 1.8 V) Standard SIM, eSIM optional  Ethernet Interface Number of ports: 2 x 10/100 Mbps, 2 x LAN or 1 x LAN + 1 x Wan ...

  • Page 13: Dimensions

    Robustel R1510 User Guide Physical Characteristics Ingress protection: IP30  Housing & Weight: Plastic, 150 g  Dimensions: 91.5 x 91.5 x 31.5mm  Installations: Desktop, wall mounting or DIN rail mounting (Wall mounting and Din rail mounting installation ...

  • Page 14: Chapter 2 Hardware Installation

    Robustel R1510 User Guide Chapter 2 Hardware Installation 2.1 Pin Description Power DI/DO Direction Router  Device Router  Device Router  Device Router  Device Router  Device 2.2 LED Indicators Name Color Status Description Green On, solid Router is powered on (System is initializing)
  • Page 15 Robustel R1510 User Guide OpenVPN connection is not established USR-IPsec Green On, solid IPsec connection is established IPsec connection is not established RSSI (Represented by Green On, solid Signal level: five bars signal.) Wireless module : 21-31 dB ( High Signal strength)

  • Page 16: Reset Button

    2.4 Ethernet Ports There are two Ethernet ports on R1510, including ETH0 (WAN/LAN), and ETH1. Each has two LED indicators. The yellow one is a link indicator but the green one doesn’t mean anything. For details about status, see the table below.

  • Page 17: Insert Or Remove Sim Card

    Robustel R1510 User Guide 2.5 Insert or Remove SIM Card Insert or remove the SIM card as shown in the following steps. Insert SIM card  Make sure router is powered off. To insert SIM card, press the card with finger until you hear a click.

  • Page 18: Attach External Antenna (Sma Type)

    Robustel R1510 User Guide Do not bend or scratch the card. Keep the card away from electricity and magnetism. Make sure router is powered off before inserting or removing the card. 2.6 Attach External Antenna (SMA Type) Attach an external SMA antenna to the router’s antenna connector and twist tightly. Make sure the antenna is within the correct frequency range provided by the ISP and with 50 Ohm impedance.
  • Page 19 Robustel R1510 User Guide First, drill holes on the wall, the distance between the two holes is 60mm, then knock the expansion pipe into the wall with a rubber hammer, align the screw with the expansion pipe, insert the screw and reserve the corresponding length, and finally fix the product on the wall.
  • Page 20 Robustel R1510 User Guide DIN rail mounting (measured in mm) Use 3 pcs of M3 screws to mount the router on the DIN rail, and then hang the DIN rail on the holder. You need to choose a standard holder.

  • Page 21: Connect The Router To A Computer

    Robustel R1510 User Guide 2.8 Connect the Router to a Computer Connect an standard Ethernet cable to the port marked ETH0~ETH1 at the front of the R1510 Router, and connect the other end of the cable to your computer. 2.9 Power Supply R1510 Router supports reverse polarity protection, but always refers to the figure above to connect the power adapter correctly.

  • Page 22: Chapter 3 Initial Configuration

    Robustel R1510 User Guide Chapter 3 Initial Configuration The router can be configured through your web browser that including IE 8.0 or above, Chrome and Firefox, etc. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista/7/8, etc.
  • Page 23 Robustel R1510 User Guide Click Properties in the window of Local Area Connection Status. Choose Internet Protocol Version 4 (TCP/IPv4) and click Properties. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 23/140...
  • Page 24 Robustel R1510 User Guide Two ways for configuring the IP address of PC Obtain an IP address from the DHCP server automatically; Click “Obtain an IP address automatically "; Use the following IP address: (Configured a static IP address manually within the same subnet of the router, click and configure "Use the following IP address"...

  • Page 25: Factory Default Settings

    Robustel R1510 User Guide 3.2 Factory Default Settings Before configuring your router, you need to know the following default settings. Item Description Username admin Password admin ETH0 WAN mode or 192.168.0.1/255.255.255.0, LAN mode ETH1 192.168.0.1/255.255.255.0, LAN mode DHCP Server Enabled 3.3 Log in the Router...

  • Page 26: Control Panel

    Robustel R1510 User Guide 3.4 Control Panel After logging in, the home page of the R1510 Router’s web interface is displayed, for example. In the home page, the user can save the configuration, restart the router, log out, and so on.
  • Page 27 Robustel R1510 User Guide Cancel Click to cancel the modification on current configuration page. Note: The steps of how to modify configuration are as bellow: 1. Modify in one page; 2. Click under this page; 3. Modify in another page;...

  • Page 28: Chapter 4 Router Configuration

    Robustel R1510 User Guide Chapter 4 Router Configuration 4.1 Status 4.1.1 System Information This section allows you to view the System Information of your Router. System Information Item Description Device Model Show the model name of your device. System Uptime Show the current amount of time the router has been connected.

  • Page 29: Internet Status

    Robustel R1510 User Guide 4.1.2 Internet Status This section shows the Internet status information of your Router. Internet Status Item Description Active Link Show the current active link. WWAN1 or WAN。 Uptime Show the current amount of time the link has been connected.

  • Page 30: Interface

    Robustel R1510 User Guide 4.2 Interface 4.2.1 Link Manager This section allows you to setup the connection of Link Manager. Link manager is a network link backup function that provides mobile network and Ethernet link backups. General Settings @ Link Manager...
  • Page 31 Robustel R1510 User Guide Link Settings allows you to configure the parameters of link connection, including WWAN1, WAN and WLAN. It is recommended to enable Ping detection to keep the router always online. The Ping detection increases the reliability and also costs the data traffic.
  • Page 32 Robustel R1510 User Guide Link Settings (WWAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link. WWAN1 Description Enter a description for this link. It can be null. Null WWAN Settings Automatic APN Click the toggle button to enable/disable the “Automatic APN Selection”...
  • Page 33 Robustel R1510 User Guide Link Settings (WWAN) Item Description Default Billing Day Specify the monthly billing day. The data traffic statistics will be recalculated from that day. Ping Detection Settings Enable Click the toggle button to enable/disable the ping detection mechanism, a keep-alive policy of the router.
  • Page 34 Robustel R1510 User Guide The window is displayed as below when choosing “Static” as the connection type. The window is displayed as below when choosing “PPPoE” as the connection type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 34/140...
  • Page 35 Robustel R1510 User Guide Link Settings (WAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link. Description Enter a description for this link. It can be null. Null Connection Type Select from “DHCP”, “Static”...
  • Page 36 Robustel R1510 User Guide the max continuous ping tries reached. Advanced Settings NAT Enable Click the toggle button to enable/disable the Network Address Translation option. Enter the Maximum Transmission Unit. 1500 Upload Bandwidth Enter the upload bandwidth used for QoS, measured in kbps.
  • Page 37 Robustel R1510 User Guide When "Connection Type" selects "PPPOE", enter the relevant parameters in the window below the static address settings: RT_UG_R1510_v.1.0.1 Dec. 31, 2019 37/140...
  • Page 38 Robustel R1510 User Guide Link Settings (WLAN) Item Description Default General Settings Index Indicate the ordinal of the list. Type Show the type of the link. WLAN Description Enter a description for this link. It can be null. Null Connection Type Select from “DHCP”...
  • Page 39 Robustel R1510 User Guide the max continuous ping tries reached. Advance Settings NAT Enable Click the toggle button to enable/disable the Network Address Translation option. Enter the Maximum Transmission Unit. 1500 Upload Bandwidth Enter the upload bandwidth used for QoS, measured in kbps.

  • Page 40: Lan

    4.2.2 LAN This section allows you to set the related parameters for LAN port. There are two LAN ports on R1510 Router, including ETH0, and ETH1. Wan is assigned as ETH0. The ETH0 and ETH1 can freely choose from lan0 and lan1, but at least one LAN port must be assigned as lan0.
  • Page 41 Robustel R1510 User Guide You may click to add a new LAN port, or click to delete the current LAN port. Now, click to edit the configuration of the LAN port. General Settings @ LAN Item Description Default Index Indicate the ordinal of the list.
  • Page 42 Robustel R1510 User Guide The window is displayed as below when choosing “Relay” as the mode. Item Description Default DHCP Settings Enable Click the toggle button to enable/disable the DHCP function. Mode Select the mode of DHCP from “Server” or “Relay”.
  • Page 43 Robustel R1510 User Guide Multiple IP You may click to add a multiple IP to the LAN port, or click to delete the multiple IP of the LAN port. Now, click to edit the multiple IP of the LAN port.

  • Page 44: Ethernet

    4.2.3 Ethernet This section allows you to set the related parameters for Ethernet. There are two Ethernet ports on R1510 Router, including ETH0 and ETH1. ETH0 can be configured as the WAN port for the router to access the outer network or the LAN port for the lower end devices to connect with the router.

  • Page 45: Cellular

    Click the row of status, the details status information will be display under the row. Please refer to the screenshot below. 4.2.4 Cellular This section allows you to set the related parameters of Cellular. The R1510 Router has one SIM card slot. Click the right most button of SIM 1 to edit the parameters.
  • Page 46 Robustel R1510 User Guide The window is displayed as below when choosing “Auto” as the network type. The window is displayed as below when choosing “Specify” as the band select type. Cellular Item Description Default General Settings Index Indicate the ordinal of the list.
  • Page 47 Robustel R1510 User Guide Cellular Item Description Default Network Type Select from “Auto”, “2G Only”, “2G First”, “3G Only”, “3G First”, “4G Only”, “4G Auto First”.  Auto: Connect to the best signal network automatically  2G Only: Only the 2G network is connected ...
  • Page 48 Robustel R1510 User Guide Click the row of status, the details status information will be displayed under the row. Status Item Description Index Indicate the ordinal of the list. Modem Status Show the status of the radio module. Modem Model Show the model of the radio module.
  • Page 49 Robustel R1510 User Guide Status Item Description IMEI Show the IMEI (International Mobile Equipment Identity) number of the radio module. Firmware Version Show the current firmware version of the radio module. Click the "AT Debug" to detect the AT command.

  • Page 50: Wifi

    Robustel R1510 User Guide 4.2.5 WiFi This section allows you to configure the parameters of WiFi AP and WiFi Clinet. Router supports either WiFi AP mode or Client mode, and defaults as AP. WiFi AP Configure Router as WiFi AP Click Interface >...
  • Page 51 Robustel R1510 User Guide The window is displayed as below when setting “WPA-Personal” as the security mode. The window is displayed as below when setting “WPA- Enterprise” as the security mode. The window is displayed as below when setting “WEP” as the security mode.
  • Page 52 Robustel R1510 User Guide General Settings @ Access Point Item Description Default Enable Click the toggle button to enable/disable the WiFi access point option. Wireless Mode Select from “11bgn Mixed mode”, “11b only”, “11g 11bgn Mixed only” and “11n only”.
  • Page 53 Robustel R1510 User Guide General Settings @ Access Point Item Description Default SSID Enter the Service Set Identifier, the name of your router wireless network. The SSID of a client and the SSID of the AP must be identical for the client and AP to be able to communicate with each other.
  • Page 54 Robustel R1510 User Guide General Settings @ Access Point Item Description Default PSK Password Enter the Pre share key password. Enter 8 to 63 Null characters. Group Key Update Interval Enter the time period of group key renewal. 3600 Radius Authentication...
  • Page 55 Robustel R1510 User Guide Advanced Settings @ Access Point Item Description Default Max Associated Stations Set the max number of clients allowed to access the router’s AP. Beacon Interval Set the interval of time in which the router AP broadcasts a beacon which is used for wireless network authentication.
  • Page 56 Robustel R1510 User Guide Advanced Settings @ Access Point Item Description Default 11% in data rates, but also result in higher packet error rates. Enable AP Isolation Click the toggle button to enable/disable the AP isolation option. When enabled, the router will isolate all connected wireless devices.

  • Page 57: Wifi Client

    Robustel R1510 User Guide Note: WiFi is off by default. Follow the steps below to enable it and configure the router as WiFi client. WiFi Client Configure Router as WiFi Client Click Interface > WiFi > WiFi, select “Client” as the mode and regarding the AP type to choose the related Client Band then click “Submit”.
  • Page 58 Robustel R1510 User Guide This window allows you to scan for all available SSIDs in your area. Please click and “Scan Results” list to refresh the surrounding SSID. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 58/140...

  • Page 59: Di/Do

    This section allows you to set the DI/DO parameters. Digital Input and Digital Output are the specific interfaces for R1510. The DI interface can be used for triggering alarm, while the DO can be used for controlling the slave device so as to realize real-time monitoring.
  • Page 60 Robustel R1510 User Guide The window is displayed as below when choosing “Counter” as the mode. General Settings @ DI Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to "ON" to turn on the digital input function.
  • Page 61 Robustel R1510 User Guide The window is displayed as below when choosing “Pulse” as the alarm on action. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 61/140...
  • Page 62 Robustel R1510 User Guide The window is displayed as below when choosing “Pulse” as the alarm off action. General Settings @ DO Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to enable/disable this DO.

  • Page 63: Network

    Robustel R1510 User Guide General Settings @ DO Item Description Default square wave as specified in the pulse mode parameters. The low level widths are specified here. Enter from 1 to 3000 ms. High-level Set the high-level width. It is available when enabling Pulse as “Alarm On...

  • Page 64: Static Route

    Robustel R1510 User Guide Static Route Click to add static route. The maximum count is 20. Static Route Item Description Default Index Indicate the ordinal of the list. Description Enter a description for this route. Null Destination Enter the IP address of destination host or destination network.

  • Page 65: Firewall

    Robustel R1510 User Guide 4.3.2 Firewall This section allows you to set the firewall and its related parameters, including Filtering, Port Mapping, Custom Rules, DMZ and Status. Filtering rules allow users to custom accept or discard a specified access source, filtering its IP address or MAC address.
  • Page 66 Robustel R1510 User Guide Click to add filtering rules. The maximum count is 20. The window is displayed as below when defaulting “All” or choosing “ICMP” as the protocol. Here take “All” as an example. The window is displayed as below when choosing “TCP”, “UDP” or “TCP-UDP” as the protocol. Here take “TCP” as an example.
  • Page 67 Robustel R1510 User Guide Filtering Item Description Default Default Filtering Policy Select from “Accept” or “Drop”. Cannot be changed when filtering Accept rules table is not empty.  Accept: Router will accept all the connecting requests except the hosts which fit the drop filter list ...

  • Page 68: Port Mapping

    Robustel R1510 User Guide Filtering Item Description Default Target Address Defines if access is allowed to one or a range of IP addresses which are Null defined by Target IP Address, or every IP addresses. Target Port Enter the target port which the access originator wants to access.
  • Page 69 Robustel R1510 User Guide Port Mapping Rules Item Description Default Remote IP Specify the host or network which can access to the local IP address. Null Empty means unlimited. e.g. 10.10.10.10/255.255.255.255 or 192.168.1.0/24 Internet Port Set the internet port of router which can be accessed by other hosts from Null internet.
  • Page 70 Robustel R1510 User Guide DMZ Settings Item Description Default Enable DMZ Click the toggle button to enable/disable DMZ. DMZ host is a host on the internal network that has all ports exposed, except those ports otherwise forwarded. Host IP Address Enter the IP address of the DMZ host on your internal network.

  • Page 71: Ip Passthrough

    Robustel R1510 User Guide 4.3.3 IP Passthrough Click Network > IP Passthrough > IP Passthrough to enable or disable the IP Pass-through option. If router enables the IP Pass-through, the terminal device (such as PC) will enable the DHCP Client mode and connect to LAN port of the router;...
  • Page 72 Robustel R1510 User Guide information output to the debug port. Tunnel Click to add tunnel settings. The maximum count is 6. General Settings @ Tunnel Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to enable/disable this IPsec tunnel.
  • Page 73 Robustel R1510 User Guide 192.168.1.0/24 Remote Subnet Enter the remote subnet’s address with mask protected by IPsec, e.g. 10.8.0.0/24 Null Link Binding Select from"WWAN1", "WAN", or "WLAN". bound The window is displayed as below when choosing “PSK” as the authentication type.
  • Page 74 Robustel R1510 User Guide The window is displayed as below when choosing “xAuth PSK” as the authentication type. The window is displayed as below when choosing “xAuth CA” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 74/140...
  • Page 75 Robustel R1510 User Guide IKE Settings Item Description Default IKE Type Select from “IKEv1” and “IKEv2”. IKEv1 Negotiation Mode Select from “Main” and “Aggressive” for the IKE negotiation mode in phase 1. Main If the IP address of one end of an IPsec tunnel is obtained dynamically, the IKE Mode negotiation mode must be aggressive.
  • Page 76 Robustel R1510 User Guide IKE Settings Item Description Default router, e.g., test.robustel.com  User FQDN: Uses a user FQDN type as the ID in IKE negotiation. If this option is selected, type a name string with a sign “@” for the local security router, e.g., test@robustel.com...
  • Page 77 Robustel R1510 User Guide If choose AH as protocol, the window of SA Settings is displayed as below. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 77/140...
  • Page 78 Robustel R1510 User Guide SA Settings Item Description Default Encrypt Algorithm Select from “3DES”, “AES128”, “AES192”or “AES256” when you select “ESP” 3DES in “Protocol”. Higher security means more complex implementation and lower speed. DES is enough to meet general requirements. Use 3DES when high confidentiality and security are required.
  • Page 79 Robustel R1510 User Guide SA Settings Item Description Default detected. This may help overcome restrictive firewalls. Expert Options Add more PPP configuration options here, format: config-desc;config-desc, null e.g. protostack=netkey;plutodebug=none Status This section allows you to view the status of the IPsec tunnel.

  • Page 80: Openvpn

    Robustel R1510 User Guide x509 Item Description Default X509 Settings certificate Certificate Files Index Indicate the ordinal of the list. Filename Show the imported certificate’s name. Null File Size Show the size of the certificate file. Null Modification Time Show the timestamp of that the last time to modify the certificate file.
  • Page 81 Robustel R1510 User Guide RT_UG_R1510_v.1.0.1 Dec. 31, 2019 81/140...
  • Page 82 Robustel R1510 User Guide The window is displayed as below when choosing “Client” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 82/140...
  • Page 83 Robustel R1510 User Guide The window is displayed as below when choosing “Server” as the mode. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 83/140...
  • Page 84 Robustel R1510 User Guide The window is displayed as below when choosing “None” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 84/140...
  • Page 85 Robustel R1510 User Guide The window is displayed as below when choosing “Preshared” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 85/140...
  • Page 86 Robustel R1510 User Guide The window is displayed as below when choosing “Password” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 86/140...
  • Page 87 Robustel R1510 User Guide The window is displayed as below when choosing “X509CA” as the authentication type. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 87/140...
  • Page 88 Robustel R1510 User Guide The window is displayed as below when choosing “X509CA Password” as the authentication type. When "mode" selects "Client", the window displays as follows: RT_UG_R1510_v.1.0.1 Dec. 31, 2019 88/140...
  • Page 89 Robustel R1510 User Guide When "mode" is selected "Server", the window displays as follows: When "mode" selects "Server" and "authentication mode" selects "X509 certificate and password", the window of "VPN > OpenVPN > OpenVPN” Click user password management to add a user name and password, as shown below.
  • Page 90 Robustel R1510 User Guide General Settings @ OpenVPN Item Description Default Index Indicate the ordinal of the list. Enable Click the toggle button to enable/disable this OpenVPN tunnel. Description Enter a description for this OpenVPN tunnel. Null Mode Select from “P2P” or “Client”.
  • Page 91 Robustel R1510 User Guide General Settings @ OpenVPN Item Description Default number Set the maximum number of clients allowed to access the OpenVPN clients server. Keepalive Interval Set keepalive (ping) interval to check if the tunnel is active. Keepalive Timeout Set the keepalive timeout.
  • Page 92 Robustel R1510 User Guide General Settings @ OpenVPN Item Description Default Click the toggle button to enable/disable the Dup Client. After being enabled, the tunnel IPs obtained by multiple clients are different, and Enable Dup Client the tunnel IP of the client is interconnected with the tunnel IP of the server.
  • Page 93 Robustel R1510 User Guide x509 Item Description Default X509 Settings Tunnel Name Choose a valid tunnel. Select from Tunnel 1, Tunnel 2, Tunnel 3, Tunnel 4, Tunnel 1 Tunnel 5 and Tunnel 6. Tunnel Mode Select from"P2P mode", "client mode" or "server mode"...

  • Page 94: Gre

    Robustel R1510 User Guide 4.4.3 GRE This section allows you to set the GRE and the related parameters. Generic Routing Encapsulation (GRE) is a tunneling protocol that can encapsulate a wide variety of network layer protocols inside virtual point-to-point links over an Internet Protocol network.

  • Page 95: Services

    Robustel R1510 User Guide Enable NAT Click the toggle button to enable/disable this option. This option must be enabled when router under NAT environment. Secrets Set the key of the GRE tunnel. Null Link binding Select from "WWAN1", "WAN", or "WLAN".
  • Page 96 Robustel R1510 User Guide Syslog Settings Item Description Default Enable Click the toggle button to enable/disable the Syslog settings option. Syslog Level Select from “Debug”, “Info”, “Notice”, “Warning” or “Error”, which from low to Debug high. The lower level will output more syslog in detail.

  • Page 97: Event

    Robustel R1510 User Guide 4.5.2 Event This section allows you to set the event parameters. Event feature provides an ability to send alerts by SNMP and RobustLink when certain system events occur. General Settings @ Event Item Description Default Signal Quality Threshold Set the threshold for signal quality.
  • Page 98 Robustel R1510 User Guide General Settings @ Notification Item Description Default Index Indicate the ordinal of the list. Description Enter a description for this group. Null Sent SMS Click the toggle button to enable/disable this option. When enabled, the router will send notification to the specified phone numbers via SMS if event occurs.
  • Page 99 Robustel R1510 User Guide Send Email Click the toggle button to enable/disable this option. When enabled, the router will send notification to the specified email box via Email if event occurs. Email Addresses Enter the email addresses used for receiving event notification. Use a space to separate each address.

  • Page 100: Ntp

    Robustel R1510 User Guide separate more than one filter message, such as message1&message2. 4.5.3 NTP This section allows you to set the related NTP (Network Time Protocol) parameters, including Time zone, NTP Client and NTP Server. Item Description Default Timezone Settings Time Zone Click the drop down list to select the time zone you are in.

  • Page 101: Sms

    Robustel R1510 User Guide 4.5.4 SMS This section allows you to set SMS parameters. Router supports SMS management, and user can control and configure their routers by sending SMS. For more details about SMS control, refer to 5.2.2 SMS Remote Control.

  • Page 102: Email

    Robustel R1510 User Guide User can test the current SMS service whether it is available in this section. SMS Testing Item Description Default Phone Number Enter the specified phone number which can receive the SMS from router. Null Message Enter the message that router will send it to the specified phone number.

  • Page 103: Ddns

    Robustel R1510 User Guide Email Settings Item Description Default Enable Click the toggle button to enable/disable the Email option. Enable TLS/SSL Click the toggle button to enable/disable the TLS/SSL option. Enable STARTTLS Click the toggle button to enable/disable STARTTLS encryption.

  • Page 104: Ssh

    Robustel R1510 User Guide DDNS Settings Item Description Default Enable Click the toggle button to enable/disable the DDNS option. Service Provider Select the DDNS service from “DynDNS”, “NO-IP”, “3322” or “Custom”. DynDNS Note: the DDNS service only can be used after registered by Corresponding service provider.

  • Page 105: Web Server

    Robustel R1510 User Guide cannot use username and password to access the router via SSH. In this case, only the key can be used for login. Import Authorized Keys Item Description Authorized Keys Click on “Choose File” to locate an authorized key from your computer, and then click “Import”...

  • Page 106: Advanced

    Robustel R1510 User Guide This section allows you to import the certificate file into the router. Import Certificate Item Description Default Import Type Select from “CA” and “Private Key”.  CA: a digital certificate issued by CA center  Private Key: a private key file HTTPS Certificate Click on “Choose File”...

  • Page 107: System

    Robustel R1510 User Guide  OpenVPN: USR indicator showing the OpenVPN status  IPsec: USR indicator showing the IPsec status Note: For more details about USR indicator, see “2.2 LED Indicators”. Reboot Item Description Default Periodic Reboot Set the reboot period of the router. 0 means disable.

  • Page 108: Update

    Robustel R1510 User Guide Syslog Item Description Syslog Details Log Level Select from “Debug”, “Info”, “Notice”, “Warn”, “Error” which from low to high. The lower level will output more syslog in detail. Filtering Enter the filtering message based on the keywords. Use “&” to separate more than one filter message, such as “keyword1&keyword2”.
  • Page 109 File Click on “Choose File” to locate the App file from your computer, and then click to import this file into your router. Note: File format should be xxx.rpk, e.g. R1510-robustlink-1.0.0.rpk. Installed Apps Index Indicate the ordinal of the list.

  • Page 110: Tools

    Robustel R1510 User Guide 4.6.4 Tools This section provides users three tools: Ping, Traceroute and Sniffer. The Ping tool is used to detect the network connectivity of the router. Ping Item Description Default IP address Enter the ping’s destination IP address or destination domain.
  • Page 111 Robustel R1510 User Guide Traceroute Item Description Default Trace Address Enter the trace’s destination IP address or destination domain. Null Trace Hops Specify the max trace hops. Router will stop tracing if the trace hops has met max value no matter the destination has been reached or not.

  • Page 112: Profile

    Robustel R1510 User Guide Sniffer Item Description Default Interface Choose the interface according to your Ethernet configuration. Host Filter the packet that contain the specify IP address. Null Packets Request Set the packet number that the router can sniffer at a time.
  • Page 113 Robustel R1510 User Guide XML Configuration File Click on to locate the XML configuration file from your computer, and then click to import this file into your router. Export Configuration File Ignore Disabled Features Click the toggle button as “ON” to ignore the disabled features.

  • Page 114: User Management

    Robustel R1510 User Guide 4.6.6 User Management This section allows you to change your username and password, and create or manage user accounts. One router has only one super user who has the highest authority to modify, add and manage other common users.
  • Page 115 Robustel R1510 User Guide Common User Settings Item Description Default Index Indicate the ordinal of the list. Role Select from “Visitor” and “Editor”. Visitor  Visitor: Users only can view the configuration of router under this level  Editor: Users can view and set the configuration of router under this level Username Set the Username, 5-32 characters, valid characters: a-z, A-Z, 0-9, @, #, $, ., *, !, -...

  • Page 116: Configuration Examples

    Robustel R1510 User Guide Chapter 5 Configuration Examples 5.1 Cellular 5.1.1 Cellular Dial-Up This section shows you how to configure the primary and backup SIM card for Cellular Dial-up. Connect the router correctly and insert two SIM, then open the configuration page. Under the homepage menu, click Interface > Link Manager >...
  • Page 117 Robustel R1510 User Guide When finished, click Submit > Save & Apply for the configuration to take effect. The window is displayed below by clicking Interface > Cellular > Advanced Cellular Settings. Click the right most of edit button of SIM1 to set its parameters according to your application request.

  • Page 118: Sms Remote Control

    Password mode—Username:Password;cmd1;cmd2;cmd3;…cmdn (available for every phone number). Phonenum mode-- Password;cmd1;cmd2;cmd3;… cmdn (available when the SMS was sent from the phone number which had been added in R1510’s phone group). Both mode-- Username:Password;cmd1;cmd2;cmd3;…cmdn (available when the SMS was sent from the phone number).
  • Page 119 Robustel R1510 User Guide XML command: <lan> <network max_entry_num="2"> <id>1</id> <interface>lan0</interface> <ip>172.16.24.24</ip> <netmask>255.255.0.0</netmask> <mtu>1500</mtu> SMS cmd: set lan network 1 interface lan0 set lan network 1 ip 172.16.24.24 set lan network 1 netmask 255.255.0.0 set lan network 1 mtu 1500 The semicolon character (‘;’) is used to separate more than one command packed in a single SMS.

  • Page 120: Vpn Configuration Example

    Robustel R1510 User Guide ram_usage = "76M Free/128M Total" admin:admin;reboot In this command, username is “admin”, password is “admin”, and the command is to reboot the R1510 Router. SMS received: admin:admin;set firewall remote_ssh_access false;set firewall remote_telnet_access false In this command, username is “admin”, password is “admin”, and the command is to disable the remote_ssh and remote_telnet access.
  • Page 121 Robustel R1510 User Guide IPsec VPN_Server: Cisco 2811: RT_UG_R1510_v.1.0.1 Dec. 31, 2019 121/140...
  • Page 122 Robustel R1510 User Guide IPsec VPN_Client: The window is displayed as below by clicking VPN > IPsec > Tunnel. Click button and set the parameters of IPsec Client as below. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 122/140...
  • Page 123 Robustel R1510 User Guide When finished, click Submit > Save & Apply for the configuration to take effect. The comparison between IPec Server and Client is as below. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 123/140...

  • Page 124: Openvpn

    Robustel R1510 User Guide 5.2.2 OpenVPN OpenVPN supports two modes, including Client and P2P. Here takes P2P as an example. OpenVPN-Server OpenVPN-Client Internet WAN:202.96.1.100/24 WAN:59.1.1.1 192.168.1.0/24 192.168.2.0/24 The configuration of two points is as follows. OpenVPN_Server: Generate relevant OpenVPN certificate on the server side firstly, and refer to the following commands to configuration the Server: local 202.96.1.100...
  • Page 125 Robustel R1510 User Guide OpenVPN_Client: Click VPN > OpenVPN > OpenVPN as below. Click to configure the Client01 as below. When finished, click Submit > Save & Apply for the configuration to take effect. RT_UG_R1510_v.1.0.1 Dec. 31, 2019 125/140...

  • Page 126: Gre Vpn

    Robustel R1510 User Guide 5.2.3 GRE VPN GRE VPN example topology: GRE-1 GRE-2 Internet WAN:58.1.1.1 WAN:59.1.1.1 192.168.2.0/24 192.168.1.0/24 The configuration of two points is as follows. GRE-1 ： The window is displayed as below by clicking VPN > GRE > GRE.
  • Page 127 Robustel R1510 User Guide GRE-2: Click button and set the parameters of GRE-2 as below. When finished, click Submit > Save & Apply for the configuration to take effect. The comparison between GRE-1 and GRE-2 is as below. RT_UG_R1510_v.1.0.1 Dec. 31, 2019...

  • Page 128: Chapter 6 Introductions For Cli

    Robustel R1510 User Guide Chapter 6 Introductions for CLI 6.1 What Is CLI The Command Line Interface (CLI) is a set of software interfaces that provide another way to configure device parameters. Users can connect to the router through SSH or telnet to configure CLI commands. After establishing a Telnet or SSH connection with the router, enter the login account and password (default admin/admin) to enter the router's configuration mode, as shown below.
  • Page 129 Robustel R1510 User Guide ping Send messages to network hosts reboot Halt and perform a cold restart route Static route modify dynamically，this setting will not be saved Set system configuration show Show system configuration status Show running system information tftpupdate...

  • Page 130: How To Configure The Cli

    Robustel R1510 User Guide 6.2 How to Configure the CLI Following is a table about the description of help and the error should be encountered in the configuring program. Commands /tips Description Typing a question mark “?” will show you the help information.

  • Page 131: Quick Start With Configuration Examples

    Example 2: Update firmware via tftp # tftpupdate （space+?） firmware New firmware config New configuration file # tftpupdate firmware （space+?） filename New file # tftpupdate firmware filename R1510-firmware-sysupgrade-unknown.ruf host 192.168.100.99 // enter a new firmware name Downloading Download success. Upgrading Upgrade success. //update success...
  • Page 132 Robustel R1510 User Guide ethernet Ethernet event Event Management firewall Firewall ip_passthrough IP Passthrough ipsec IPSec Local Area Network link_manager Link Manager openvpn OpenVPN reboot Automatic Reboot route Route syslog Syslog system System user_management User Management web_server Web Server wifi WiFi AP # set link_manager（space+?）...
  • Page 133 Robustel R1510 User Guide debug_enable Debug Enable verbose_debug_enable Verbose Debug Enable # set link_manager link 1 type wwan1 # set link_manager link 1 wwan（space+?） auto_apn Automatic APN Selection username Username password Password dialup_number Dialup Number auth_type Authentication Type data_allowance Data Allowance...
  • Page 134 Robustel R1510 User Guide netmask = 255.255.255.0 gateway = "" primary_dns = "" secondary_dns = "" wins_server = "" lease_time = 120 static_lease = "" expert_options = "" debug_enable = false vlan_id = 0 # set lan network Network Settings...
  • Page 135 Robustel R1510 User Guide network_type = auto band_select_type = all band_settings { gsm_850 = false gsm_900 = false gsm_1800 = false gsm_1900 = false wcdma_800 = false wcdma_850 = false wcdma_900 = false wcdma_1900 = false wcdma_2100 = false wcdma_1700 = false...
  • Page 136 Robustel R1510 User Guide pptp reboot route syslog system user_management web_server wifi # set cellular(space+?) sim SIM Settings # set cellular sim(space+?) Integer Index (1..1) # set cellular sim 1(space+?) card SIM Card phone_number Phone Number pin_code PIN Code extra_at_cmd...

  • Page 137: Glossary

    Robustel R1510 User Guide Glossary Abbr. Description Alternating Current Access Point Name of GPRS Service Provider Network ASCII American Standard Code for Information Interchange Conformité Européene (European Conformity) CHAP Challenge Handshake Authentication Protocol Command Line Interface for batch scripting Circuit Switched Data...
  • Page 138 Robustel R1510 User Guide Abbr. Description local area network Light Emitting Diode Machine to Machine Maximum Minimum Mobile Originated Mobile Station Mobile Terminated OpenVPN Open Virtual Private Network Password Authentication Protocol Personal Computer Personal Communications Network, also referred to as DCS 1800...
  • Page 139 Robustel R1510 User Guide Abbr. Description Wide Area Network RT_UG_R1510_v.1.0.1 Dec. 31, 2019 139/140...
  • Page 140 Robustel R1510 User Guide Guangzhou Robustel LTD Address: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Guangzhou, China 510660 Tel: 86-20-29019902 Email: info@robustel.com RT_UG_R1510_v.1.0.1 Dec. 31, 2019 140/140...
