FieldPoint
FP-DIO-550 and cFP-DIO-550
Eight-Channel Digital Input,
Eight-Channel Digital Output Module
These operating instructions describe how to install and use the
National Instruments FP-DIO-550 and cFP-DIO-550 digital I/O
modules, referred to inclusively as the [c]FP-DIO-550. For
information about configuring and accessing the [c]FP-DIO-550
over a network, refer to the user manual for the FieldPoint network
module you are using.
Features
The [c]FP-DIO-550 is a FieldPoint digital I/O module with the
following features:
• Eight digital input channels compatible with sinking, sourcing,
and differential devices
• Eight sourcing digital output channels
• Up to 30 VDC digital input
• Up to 30 VDC, 250 mA digital output
• On/Off LED indicators
• 250 V
rms
verified by 2,300 V
• Hot swappable
Installing the FP-DIO-550
The FP-DIO-550 mounts on a FieldPoint terminal base (FP-TB-x),
which provides operating power to the module. Installing the
FP-DIO-550 onto a powered terminal base does not disrupt the
operation of the bank.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
™
Operating Instructions
CAT II continuous channel-to-ground isolation,
, 5 s dielectric withstand test
rms
