- Page 1 Instructions...
- Page 2 Thank you for purchasing a Canon product. Canon RF35mm F1.8 MACRO IS STM is Camera Firmware a macro lens for use with EOS R series cameras. Please use the latest version of firmware with the camera in use. For details on whether the firmware is the latest version or not, and for details on updating the “IS”...
- Page 3 Safety Precautions Precautions to ensure that the camera is used Caution Details pertaining to risks that may result safely. Read these precautions thoroughly. Make in damage to property. sure all details are observed in order to prevent Do not leave the product in excessive heat such as risks and injury to the user and other people.
- Page 4 General Precautions Handling Precautions If the lens is taken from a cold environment into a warm one, condensation may develop on the lens surface and internal parts. To prevent condensation in this case, first put the lens into an airtight plastic bag before taking it from a cold to warm environment.
- Page 5 This device complies with Part 15 of the FCC Rules. CAN ICES-3 (B) / NMB-3 (B) Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 6: Table Of Contents
Nomenclature Macro Ring Lite/ Focus mode switch (→ 7) Macro Twin Lite mount (→ 15) Image stabilizer switch (→ 9) Lens mount index (→ 6) Hood mount (→ 13) Filter mounting thread (→ 13) Contacts (→ 6) Lens mount (→ 6) Control ring (→... -
Page 7: Mount
1. Attaching and Detaching the Lens Lens mount index Set the camera’s power switch to OFF when attaching or detaching the lens. Attach the lens cap before detaching the lens from the camera. When the power switch of the camera is set to OFF, the focus lens pushed forward is automatically stored.* Do not detach the lens until the lens is completely stored. -
Page 8: Focus Mode Switch
2. Setting the Focus Mode Focus mode switch Quickly turning the focusing ring may result in delayed focus. Due to the structural characteristics, the focus lens driving speed may vary according to the variation in the air temperature and posture. Do not touch the operating part in the front of the lens while the focus lens is operating. -
Page 9: Control Ring
There are cases in which the sound of control ring operations may be recorded when shooting movies. The clicking sensation of the control ring can be removed by the Canon Service Center. (chargeable) ENG-8... -
Page 10: Image Stabilizer Switch
4. Image Stabilizer This function provides image stabilization The shorter the focusing distance is, the less the appropriate for shooting conditions (such as image stabilizer effect. shooting still subjects, panning shots, and close- The Image Stabilizer cannot compensate for a up (macro) shooting). - Page 11 Image Stabilizer The Image Stabilizer for this lens is suited to hand-held shots in the following conditions. In semi-darkened areas such as indoors or outdoors at night. In locations where a flash cannot be used, such as art museums and theater stages. In situations where your footing is uncertain.
- Page 12 5. Hand-held Close-up (Macro) Shooting This lens allows users to focus from infinity to a magnification of 0.5x for close-up (macro) shooting. Hold the camera steadily Hold the camera steadily as shown in the illustration on the right when taking hand-held close-ups (macro), and shoot carefully to minimize camera shake and prevent focus blurring.
- Page 13 6. Exposure When Taking Close-up (Macro) Shots Setting the Exposure When deciding the exposure using a hand-held exposure meter, apply the following exposure When taking photographs using TTL metering, factor. no exposure compensation is necessary because the light coming through the lens is measured. Magnification With TTL metering, photographing with AE (auto Focusing distance...
-
Page 14: Filter Mounting Thread
Only one filter may be attached. If you need a polarizing filter, use the Canon Circular Polarizing Filter PL-C B. Turn OFF the power of the camera before attaching or detaching a filter. - Page 15 9. Close-up Lenses (Sold separately) Attaching a 250D/500D Close-up Lens enables close-up photography. It provides the following magnifications. 250D: 0.14 to 0.62x 500D: 0.07 to 0.56x MF mode is recommended for accurate focusing. ENG-14...
- Page 16 10. Macro Flash (Sold separately) The Macro Ring Lite MR-14EX II or Macro Twin ■ When the MR-14EX II is in use Lite MT-26EX-RT enables flash photography up • Effective Flash Range (Reference) to 0.5x magnification in E-TTL II autoflash mode. ISO100 ISO400 When using a macro flash and filter at the same...
- Page 17 Add 23.9 mm/0.94 in. when including the lens cap and dust cap. The maximum diameter, length and weight listed are for the lens itself only. All data listed is measured according to Canon standards. Product specifications and appearance are subject to change without notice.
- Page 18 CT1-D072-A 0818Ni © CANON INC. 2018...
