Finding Your Password (Date Code) To Access Installer Options - Honeywell Home THX9321 Prestige 2.0 Manual

®
THX9321 PRESTIGE 2.0 AND THX9421 PRESTIGE
3. Type the sensor name and press Done. The sensor
names are used when selecting which sensor to use
for temperature, humidification, and dehumidifica-
tion control.
Fig. 51.
NOTE: If you link more than 1 wireless indoor sen-
sor, and forget to name them, you will be
prompted to name each wireless indoor sen-
sor after you exit wireless setup. See Fig. 52.
Fig. 52.
Linking Entry/Exit Remote or Vent Boost
Remote
1. Press and quickly release the CONNECT button.
Fig. 53. Connect button and status light on Entry/Exit
Remote or Vent Boost Remote.
2. After a short delay, the status light will glow green for
15 seconds. If the status light turns red, the remote
did not link with the thermostat for the connection
process.
NOTE: The thermostat can work with up to 3 Entry/Exit
remotes. Each Entry/Exit remote can control up to
16 thermostats.
68-0311—08
®
IAQ WITH EIM
NOTE: The thermostat can work with up to 6 Vent Boost
remotes.
Finding Your Password (Date Code)
to Access Installer Options
You will need the thermostat password to:
• Make changes to the Installer Setup.
• Setup Diagnostics.
• Perform an Installer Test.
• View Data Logs.
• Add, remove, rename or view connected RedLINK
accessories.
• Reset the thermostat to Factory Default settings.
The password (Date Code) is located on the back of the
thermostat.
Resideo
Assembled in Country of Origin/Assemblé au pays d'origine
Fig. 54. Finding thermostat password.
The password (Date Code) can also be found by following
these steps:
1. Touch Menu.
2. Select Dealer Information.
Fig. 55. Finding thermostat password.
20
1324
HoneywellHome.com
ForwardThinking@HoneywellHome.com
Resideo
Assembled in Country of Origin/Assemblé au pays d'origine
1324 Password
(Date Code)
HoneywellHome.com
ForwardThinking@HoneywellHome.com
Dealer Informa on
M38033
OK
