3.8 Replacing Maintenance Section

Replacing Cap Head Assy

3.8.3
T I P
Replacing Procedure For Maintenance Part: Cap Head Assy.
This part will be referred to as the Cap Head. in this manual.
1. Remove I/H Cover.
"3.2.1 Removing I/H Cover" p.3-7
2. Remove Side Cover R.
"3.2.2 Remove Side Cover R" p.3-8
3. Move the Carriadge to the opposite side of origin.
"3.7.1 How To Release Carriage Lock" p.3-98
4. Shift cap slider toward the direction of the arrow shown below. Remove the protruding portion of
cap slider from the frame cap groove.
1
No.
Protruding portion of cap slider
1
Frame cap groove
2
3 Frame cap
5. Remove cap slider from frame cap.
3.8.3 Replacing Cap Head Assy
3
2
Name
6. While pushing cap head toward the direction of A, shift toward the direction of B shown below.
7. Unhook cap slider and lift up toward the direction of C shown below.
1
No.
1 Cap head
2 Cap slider
3 Cap slider hook
8. Remove cap tubes (3 pieces) from cap head.
3
No.
1 Pump cap Assy
2 Cap spring
3
Cap tube
9. Replace cap head.
1
2
C
3
Name
1
2
3
Name
VJ1324E-M-02
A
B
