Thank you for purchasing a quality product. To enjoy the full potential of your new
shower tray, please take time to read this guide thoroughly, and keep it handy for
future reference.
Important! The shower trays featured in this manual are available for use as riser
and non-riser products.
Mira Flight Shower Trays - are available in various shapes and sizes with or without
upstands and are all supplied with an 85 mm top access waste and trap.
Mira Flight Riser Conversion Kit - comprises of adjustable legs, panels, panel
securing clips, corners and optional end pieces. Riser Conversion Kits are available
to purchase separately.
Mira Flight Offset Leg Adaptor Fittings Kit - for use with the Mira Flight Riser
Conversion Kit, the Offset Leg Adaptor allows the installation of pipework behind the
adjustable legs. Offset Leg Adaptor Fittings Kits are available to purchase separately
(refer to section: 'Accessories').
Mira Flight Upstand Tiling Strip - Upstand Tiling Strips are available to purchase
separately (refer to section: 'Accessories').
Important! The shower trays featured in this manual are available for use as
riser and non-riser products.
The shower waste can cope with a flow rate of up to 25 L/min, with a pipe length
of 3 m for 40 mm pipe and 4 m for 50 mm pipe, with a fall of between 18 and
90 mm/m. The flow rate will be reduced with the introduction of bends or T fittings
in the waste outlet pipe.
Carefully unpack and check the tray for colour, size, general acceptability and
compatibility with the shower enclosure and other bathroom furniture.
Check for transit damage and report any faults immediately to your supplier.
No claims for the above will be considered after installation.
Carefully remove all of the blue protective film from the tray for inspection.
Caution! Additional protective coverings such as a dust sheet should then be
used to protect the tray from damage from falling objects.
Place the shower tray on a flat surface and using a spirit level check that it
is straight and flat and that the shower cubicle will sit on its surface correctly
when fitted.
Once the waste pipe has been connected pour water into the tray to check the
tray and pipe connection for correct drainage prior to final fix and tiling.
INTRODUCTION
IMPORTANT INFORMATION
