Event Output Tags - Allen-Bradley Compact 5000 Series User Manual

Table 71 - 5069-IB6F-3W Module Event Output Tags
Name
Eventxx.En
Eventxx.EventRisingEn
Eventxx.EventFallingEn
Eventxx.LatchEn
Eventxx.ResetEvent
Eventxx.IndependentConditionTriggerEn
Eventxx.EventNumberAck
Eventxx.CounterxxSelect
Eventxx.PtxxDataSelect
Eventxx.CounterxxValue
Eventxx.PtxxDataValue

Event Output Tags

Table 71 describes the 5069-IB6F-3W module event output tags. The event
output tags are displayed only if you select Data with Events in the Module
Definition window.
Size Definition
BOOL When set, the corresponding event trigger definition is
active and events are triggered when conditions match
the definition.
BOOL When set, an event is to trigger each time a condition
change results in conditions that match the event trigger
definition.
BOOL When set, an event is to trigger each time a condition
change results in conditions that no longer match the
event trigger definition.
BOOL When set, events are latched until acknowledged. A new
event is lost if the previous event has not been
acknowledged. When not set, new events overwrite old
events.
BOOL When the value transitions from 0 to 1, resets all events
and clears the event queue on the channel.
BOOL For events, determines whether each condition that is
indicated in the trigger definition can initiate an event
independently.
DINT The controller writes back the
EI:Event[<n>].EventNumber into this
EO:Event[<n>].EventNumberAck to indicate receipt of
the event. All events with I:EventNumbers that occurred
before EventNumberAck is acknowledged.
BOOL When set, indicates that the corresponding counter is to
participate in the event trigger definition.
BOOL When set, indicates that the corresponding data value is to
participate in the event trigger definition.
BOOL If the counter function is selected in the event trigger
definition, this member indicates that value that is to
trigger the event.
BOOL Input value of the event point data.
Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Module Tag Definitions Appendix B
Valid Values
0 or 1
0 or 1
0 or 1
• 0 = Not latched (default)
• 1 = Latched
• 0 = Events are not cleared
• 1 = Events are cleared when a rising edge
occurs
• 0 = When all selected conditions achieve the
configured values, an event is triggered.
• 1 = When any selected condition achieves the
configured value, an event is triggered.
All values.
0 or 1
0 or 1
0 or 1
• 0 = Input inactive
• 1 = Input active
251
