Factory reset

The reader can be reset to a factory default state by carrying out the following operation:-
1. Connect together the yellow and green wires. (reset link)
2. Connect power to the reader.
3. The reader will beep 3 times to confirm the reset sequence.
4. Remove the power and remove the reset link.
This factory reset sequence results in the LCD reader images returning to the default images, the LCD reader
name will be cleared and the reader password will be blanked.
Environment
Operating temperatures - all items
Waterproof
Cable length
Silent operation feature
Electrical
DC supply voltage
DC supply current
Carrier frequency
Clock and data bit period
Dimensions
Read Range
PROXIMITY LCD reader
Reader mounting plate
Documentation
Option
Fixing Kit - LCD reader
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
Specifications
-20 °C (-4 °F)
Contents in box
Qty
fk1-087 4
4
5
1
Min
+55 °C (+131 °F)
IPX7
Min
10V DC 14V DC
165 mA 215 mA
Width
2 / inch 4
5
8
Token
2 1 / inch 2
2
No 6 x 3 / in pozi pan self tapping screw - zinc
4
22 mm Wall Plugs
Cable clips
LCD reader removal tool
Max
Outdoor Use
5 yards
Max
125 kHz
600 µs
Depth
Height
/ inch
1 1 inch
4
Keyfob Hands Free Token
1 / inch 16 inch
4
Description
Yes
