INDEX
Health
&
Safety Information for R600a Charged Appliances ................ 2 - 3
Industrial Code
&
Serial Number Format ................................... 4
Introduction ........................................................... 5
Technical Specifications ............................................. 6 - 7
Detailed View ......................................................... 8
Component Function ............................................... 9 - 10
Auto Test ............................................................ 11
Air Flow ......................................................... 12 - 13
Control Module Parameters ......................................... 14 - 15
Fault Diagnosis Quick Guide ........................................ 16 - 17
Servicing & Dismantling Instructions ................................. 18 - 19
Door Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 21
Wiring Connection Chart ............................................... 22
Control Module Connections ........................................... 23
Wiring Diagram ....................................................... 24
Thermistor Sensor Location ............................................ 25
INDUSTRIAL CODE I SERIAL NUMBER FORMAT
SIN = Serial Number 406250042
created from:
4 =Year of Manufacture -
06 =Month -
25 = Day of month -
0042 = Number of appliances
produced on this day
The Serial Number along with the Industrial Code and
Commercial Code are on the bottom line of the Rating Plate
as detailed in the example below.
Industrial
Code
Revision
changes
Commercial
Code
(positive ID
for model)
Factory
where
appliance
manufactured
4
.. I..
r~~ - · ~j
iOOMP. ES iJI
EN _ I . 19'3
l?f(I
eltd
11D
d
11nil'pBll! II
Day
Month
Year
odel RFA70P'
Sequential
number of
appliance
(per day)
