Huawei ME919Bs-567bN User Manual

Can be used as a wireless terminal

Advertisement

Quick Links

Copyright © Huawei Technologies Co., Ltd. 2016.
All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means without
prior written consent of Huawei Technologies Co., Ltd. And its affiliates ("Huawei").
The product described in this manual may include copyrighted software of Huawei and possible
licensors. Customers shall not in any manner reproduce, distribute, modify, decompile,
disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software,
unless such restrictions are prohibited by applicable laws or such actions are approved by
respective copyright holders.
Trademarks and Permissions
,
, and
are trademarks or registered trademarks of Huawei Technologies
Co., Ltd.
Other trademarks, product, service and company names mentioned are the property of their
respective owners.
Notice
Some features of the product and its accessories described herein rely on the software installed,
capacities and settings of local network, and therefore may not be activated or may be limited by
local network operators or network service providers.
Thus, the descriptions herein may not exactly match the product or its accessories which you
purchase. Huawei reserves the right to change or modify any information or specifications
contained in this manual without prior notice and without any liability.
DISCLAIMER

Advertisement

loading

Summary of Contents for Huawei ME919Bs-567bN

  • Page 1 No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. And its affiliates (“Huawei”). The product described in this manual may include copyrighted software of Huawei and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile,...
  • Page 2: Import And Export Regulations

    FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.
  • Page 3 Contents Getting to Know the ME919Bs-567bN ................... 1 HUAWEI ME919B LTE LGA Module Development Kit Guide ............3...
  • Page 4 Note: This manual briefly describes the preparation, Assembly and safety precautions.  You are recommended to read the manual before using the ME919Bs-567bN  Getting to Know the ME919Bs-567bN The module is standard LGA interface with a dimension of 35 mm × 35 mm × 1.2 mm. It is applied...
  • Page 5 Note: In certain cases, your development kit may be disassembled only by the professionals.  Before you install the ME919Bs-567bN onto the development kit, read HUAWEI ME919B LTE  LGA Module Development Kit Guide.
  • Page 6 The signals output from the module are transferred to the development board for secondary development. NOTE: In the following sections, “module” refers to the ME919Bs-567bN LTE LGA module.  1.2 Setting up DVK This chapter describes how to set up the DVK to ensure that the module can work normally.
  • Page 7 Figure 1 Layout of the DVK(TOP VIEW) Method 1: When the power is supplied by a 12V adapter rather than a 5V in USB interface, connect J305’s pin 3 and pin 2, and J605’s pin2 and pin1. The jump wire configuration is showed in Figure 2. Figure 2 12V Power Supply on the DVK...
  • Page 8 Method 2: When the power is supplied by a 5V in USB interface rather than a 12V adapter, connect J305’s pin 2 and pin 1, and J605’s pin2 and pin1. The jump wire configuration is shown in Figure 4. Figure 3 USB Interface Figure 4 Jump Wire Configuration...
  • Page 9 1.3 Power-up and Turning on the module When the MCU on the DVK is power-on, connect J307’s pin2 and pin1 to power the module up. The jump wire configuration is shown in Figure 5. Figure 5 J307’s Pins After powering the module up, press and hold the Power_on_off (silk-screen is ON_OFF) button for more than 0.5s to turn on the module, as is shown in Figure 6.
  • Page 10 Figure 6 Keys to Turning-on and Reset...
