TP-Link TL-WR850N Quick Installation Manual

Quick Installation Guide

300Mbps Wireless N Router
EN020-F5
TL-WR850N
TL-WR840N
Connect the Hardware
If your Internet connection is through an Ethernet cable from the wall
instead of through a DSL / Cable / Satellite modem, connect the
Ethernet cable directly to the router's WAN port as Step 2B, and then
follow Step 4 and 5 to complete the hardware connection.
Internet
Modem
Power adapter
Power adapter
4
Connect the power adapter
to the router.
1
Turn off the modem and
remove the backup battery if
it has one.
2.A
Connect the modem to the
router's WAN port with an
Ethernet cable.
3
Turn on the modem and
then wait about 2 minutes
for it to restart.
2 2
1 1
N N
W A W A
W E W E R R
P O P O
Router
5
Confirm that the following
LEDs are solid and on to
verify the hardware
connection is correct.
Power Wi-Fi Internet
On On
S / S /
W P W P T T
S E S E
R E R E
4 4
3 3
2.B
Connect the Ethernet cable
directly to the router's WAN
port.
On
