BOLT
ELECTRIC FOLDING SCOOTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOLT and is the answer not in the manual?

Questions and answers

Related Manuals for Jetson BOLT

Summary of Contents for Jetson BOLT

  • Page 1 BOLT ELECTRIC FOLDING SCOOTER...

  • Page 2: Table Of Contents

    What’s in the Box Features & Specs Attaching the Seat Attaching the Foot Rests Attaching the Fenders Charging the Battery Unfolding the Bolt Operating the Bolt Riding the Bolt Using the Thumb Throttle Using the Brake Using the Kickstand Connecting the Bluetooth®...

  • Page 3: What's In The Box

    1. WHAT’S IN THE BOX 1. FRONT TIRE 9. REAR FENDER 2. HEADLIGHT 10. REAR TIRE 3. STEM QUICK RELEASE 11. KICKSTAND 4. HANDLEBAR 12. FOOT REST 5. CARRYING HANDLE 13. FRONT FENDER 6. SEAT 14. FRONT TIRE 7. SEAT CLAMP 15.

  • Page 4: Features & Specs

    2. FEATURES & SPECS BOLT • Product Dimensions: 40” x 20” x 37” • Weight Limit: 250 lbs. • Product Weight: 34 lbs. • Recommended Age: 13+ • Tire Size: 12” • Max Speed: Up To 16 mph/ 26 km/h •...

  • Page 5: Attaching The Seat

    3. ATTACHING THE SEAT Slide Seat into Stem Tube Open Stem Clamp Close the Stem Clamp Turn the Knob clockwise to tighten Stem Clamp...

  • Page 6: Attaching The Foot Rests

    4. ATTACHING THE FOOT RESTS Place each Foot Rest onto the tubes and turn it towards the rear tire until it is secure.

  • Page 7: Attaching The Fenders

    5. ATTACHING THE FENDERS Bolt Front Fender Bolt Rear Fender Remove Bolt and Nut from the frame. Run the Bolt through the Fender and frame, and secure using the Nut.

  • Page 8: Charging The Battery

    Only use the included charger • Plug the charger into the wall before the Charging Port • Don’t turn on the Bolt while it’s charging (it needs its rest) • Charge the battery until it is fully charged - up to 5 hours •...

  • Page 9: Unfolding The Bolt

    7. UNFOLDING THE BOLT Slowly lift the Handlebars up Press the Stem Quick Release in to lock...

  • Page 10: Operating The Bolt

    Horn Cruise Control • Powering On/Off - To turn the Bolt on, flip the power switch to ON. To turn it off, flip the power switch to OFF. • Light Function - Once the Bolt is on, hold the Horn for 3 seconds to turn on the Headlight and Taillight.
  • Page 11 9. BATTERY INDICATOR Battery Indicator BATTERY LEVELS: • 4 Lights - 76-100% Power • 3 Lights - 51-75% Power • 2 Lights - 26-50% Power • 1 Light - 1-25% Power (please charge the Bolt immediately!)

  • Page 12: Riding The Bolt

    • While riding the Bolt, keep your feet on the Foot Rests. • Do not ride with your feet dangling over the sides and always stay seated while riding.
  • Page 13 11. USING THE TWIST THROTTLE Quick Note: Try to take it easy on the throttle until you get used to it.

  • Page 14: Using The Brake

    12. USING THE BRAKE Handbrake Quick Note: Squeeze the Brake slowly to avoid stopping abruptly or losing control.

  • Page 15: Using The Kickstand

    13. USING THE KICKSTAND...

  • Page 16: Connecting The Bluetooth

    14. CONNECTING TO BLUETOOTH® Your Jetson Bolt is Bluetooth® 4.0 enabled, so you can pair it with the Ride Jetson app on your personal Bluetooth® enabled device. The Ride Jetson app is available for download from the App Store and the Google Play Store, and it’s free!

  • Page 17: Folding The Bolt

    15. FOLDING THE BOLT 15.1 Unlock the Stem Quick Release 15.2 Slowly lower the Handlebars up...

  • Page 18: Care And Maintenance

    • Speed and Driving Style: Frequent starting and stopping will reduce driving distance. CLEANING THE BOLT To clean the Bolt, carefully wipe with a damp cloth, then dry with a dry cloth. Do not use water to clean the Bolt, as the electrical and electronic systems may get wet, resulting in personal injury or malfunction of the Bolt.

  • Page 19: Safety Warnings

    17. SAFETY WARNINGS • For your safety, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. •...
  • Page 20 MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from Jetson Customer Support. This will void any warranty, and can lead to malfunctions which may cause injury. ADDITIONAL OPERATION CAUTIONS Do not lift the product off the ground while it is on and the wheels are in motion.
  • Page 21 1 Rewe Street, Brooklyn, NY 11211 help@ridejetson.com www.ridejetson.com 1-(888) 976-9904...
