MAJORITY OAKINGTON Instruction Manual

Dab / dab+ compact music system
Hide thumbs Also See for OAKINGTON:
Table of Contents

Advertisement

Quick Links

MAJORITY
OAKINGTON
DAB / DAB+ Compact Music System
OAK-CDAB-WAL
Instructions Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OAKINGTON and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MAJORITY OAKINGTON

Summary of Contents for MAJORITY OAKINGTON

  • Page 1 MAJORITY OAKINGTON DAB / DAB+ Compact Music System OAK-CDAB-WAL Instructions Guide...

  • Page 2: Table Of Contents

    Contents Controls And Functions ���������������������������������������������� What’s In The Box? ��������������������������������������������������� Instructions Guide ����������������������������������������������������� Connectivity �������������������������������������������������������������� Basic Operation �������������������������������������������������������� DAB/DAB+ Radio Functions �������������������������������������� DAB+ Manual Tuning ����������������������������������������������� How to store a preset station ���������������������������������� FM Radio ������������������������������������������������������������������ CD Playback ������������������������������������������������������������ Bluetooth and Phone Connection ��������������������������� Other Functions �������������������������������������������������������...

  • Page 3: Controls And Functions

    Controls And Functions Front View / Control Buttons Remote Sensor Mode Display Screen Power/Standby Standby Indicator Play/Pause/Menu Disc Port 10. Equaliser Previous 11. Info Next 12. Pair Bluetooth/Eject...

  • Page 4: Top View

    Controls And Functions Top View 13. Navigate - Rotate to move up or down the menu screen when in DAB or FM. OK: Press to skip to subsequent menu in DAB or FM. Volume +/- Rotate to increase or decrease the volume level.

  • Page 5: Back View

    Controls And Functions Back View 14. 5V 1A Port for charging 17. Earphone Jack Mobile Device 18. Power Switch 15. Audio Input 19. AC Power Connector 16. USB 20. Antenna...

  • Page 6: Remote Control

    Controls And Functions Remote Control 1. ON/STANDBY 2. MODE (CD/USB/Radio/BT) INTRO/AMS (Automatic Music Scan) Press to scan all tracks in CD or USB Press to automatically search for a INTRO REPEAT SLEEP AUDIO channel in FM. RANDOM Press again to stop search Bass Treble 4.
  • Page 7 Controls And Functions 15. EJECT - Press to put disc in or out 16. SLEEP - Press to set the sleep timer 17. AUDIO - Press Audio/CD/USB/DAB/FM/ BT (Bluetooth Connection) 18. RANDOM - Press to play tracks randomly in CD or USB. 19.

  • Page 8: What's In The Box

    What’s In The Box? Box Contents 1. Majority Oakington DAB/DAB+ Radio Music System 2. Remote Control 3. Power Adapter 4. Instructions Guide...

  • Page 9: Instructions Guide

    Instructions Guide Connectivity Analogue Inputs Connection AUDIO To connect the Music System/TV outputs to analogue inputs from the sound board, use the 3.5mm RCA audio cable (supplied) to connect the Music System/TV outputs with the AUX (L/R) input socket from the sound board. AUDIO...
  • Page 10 Instructions Guide Analogue Inputs Connection AUDIO Use a line-in audio cable 3.5mm (not supplied) to connect to the Music System/TV outputs with the AUDIO input socket from the sound board. You can also connect an external device such as an MP3 Player, iPod or iPhone.

  • Page 11: Basic Operation

    Instructions Guide Basic Operation Please note all (Ref.) refer to Page 1 Controls and Functions mapping guide. Plug the connector into the back of the system labelled AC- (Ref.19) and the power supply into the mains. Ensure the antenna (Ref.20) is extended as far as possible so that you can rotate it which will enable you to get the best signal you can.
  • Page 12 Instructions Guide Standby To put the music system in standby, press the ‘Power/Standby’ button (Ref.8) or the ‘ON/STANDBY’ button (Ref.1) on the remote. To turn off fully, switch it off at the mains. The cord must be out of reach of children. Language Setting The default display language is English.

  • Page 13: Dab/Dab+ Radio Functions

    Instructions Guide DAB/DAB+ Radio Functions Press the ‘Mode’ button (Ref.7) multiple times on the unit to switch to DAB/DAB+ Radio. On first use when DAB Radio is activated for the first time the display will show “full scan”, press the ‘OK’ button on the unit (Ref.13) or the ‘enter/play’ button (Ref.22) on the remote.
  • Page 14 Instructions Guide When you turn on the radio again after it switching off, it will automatically tune to the same station (DAB or FM) that was last selected. In DAB/DAB+ mode, the radio will synchronize with the time and date of the station. Prune To remove stations that are listed but are unavailable.
  • Page 15 Instructions Guide Dynamic Range Compression (DRC) This function enables you to reduce the difference between the maximum and minimum audio volume being broadcast. This makes quiet sounds comparatively louder, and loud sounds comparatively quieter. DRC only works if it enabled by the broadcaster for a specific station.

  • Page 16: Dab+ Manual Tuning

    Instructions Guide DAB+ Manual Tuning As well as an auto tune function, you can manually tune the receiver. This can help you when aligning your aerial or when adding stations that were missed while auto tuning. Press the ‘Menu’ button (Ref.9) on the remote and use the ‘Next’ (Ref.23) and ‘Previous’...
  • Page 17 Instructions Guide How to play a preset radio station Up to 40 stations can be set. To store a station that you are currently Press the ‘Program’ button (Ref.20) on the remote. Press ‘Previous’ button (Ref.10) or ‘Next’ (Ref.23) to scroll through your preset stations, up to 40.

  • Page 18: Fm Radio

    Instructions Guide FM Radio Press the ‘Mode’ button (Ref.7) multiple times on the unit and choose “FM” or press the ‘FM/DAB’ button (Ref.2) on the remote. The first time you do this, the FM frequency “87.5 MHz” will be displayed on the screen. Fully extend the antenna (Ref.20).
  • Page 19 Instructions Guide FM Scan Setting Choose between scanning strong and weak signals (All) or only the stations with strong signal (Only). Press the ‘Menu’ button (Ref.9) on the remote. To make your choice, use the ‘Previous/Next’ buttons (Ref.10/23) to choose your option.
  • Page 20 Instructions Guide Audio Settings Mono or Stereo All stereo stations are reproduced in stereo. For weak stations this can result in poor audio quality. The audio quality can be improved using mono. Press the ‘Menu’ button (Ref.9) on the remote. To make your choice, use the ‘Previous/Next’...
  • Page 21 Instructions Guide How to play a preset radio station Press the ‘Program’ button (Ref.20) on the remote. Press ‘Previous’ button (Ref.10) or ‘Next’ (Ref.23) to scroll through your preset stations, up to 10. Press the ‘Enter’ button (Ref.22) to select your choice.

  • Page 22: Cd Playback

    Instructions Guide CD Playback Please note all (Ref.) refer to Page 1 Controls and Functions mapping guide. To choose CD Mode, press through your choices using the ‘Mode’ button (Ref.7). The choices will be displayed on the front screen (Ref.2) – select “CD”. Alternatively press the ‘CD’ button on the remote (Ref.2).
  • Page 23 Instructions Guide Playing Repeatedly For CDs, press the ‘REPEAT’ button (Ref.4) on the remote multiple times to view options: Repeat All (ALL), Current Track (SINGLE) or Repeat Off (OFF). Press ‘Enter’ on the remote to confirm your choice. Random Play For CDs, Random Play can be set by pressing the ‘RANDOM’...
  • Page 24 Instructions Guide Program tracks into a preselected order Press the ‘Stop’ button (Ref.24) on the remote, then press the ‘Program’ button (Ref.20) . The track number will then flash on the front display (Ref.2). Change this number to your first required track using the number keys on the remote (Ref.13).

  • Page 25: Bluetooth And Phone Connection

    ‘Mode’ button (Ref.7) or select ‘BT’ on the remote control (Ref.2). The choices will be displayed on the front screen (Ref.2). Turn on Bluetooth on your phone and “Majority Oakington” will appear. Click on this to connect. When the unit makes a short sound, it has successfully connected.
  • Page 26 Instructions Guide Audio-In You can connect your phone or tablet with an Aux 3.5mm cable that connects to the Audio-in jack on the back of the unit (Ref.15). Insert the audio cable. To choose your mode press the ‘Mode’ button (Ref.7) on the unit. To scroll through your choices which will be displayed on the front screen (Ref.2) –...
  • Page 27 Instructions Guide Playing Repeatedly For a USB device, press the ‘Repeat’ button (Ref.4) on the remote multiple times to view options: Repeat All (ALL), Current Track (SINGLE) or Repeat Off (OFF). Press ‘Enter’ on the remote to confirm your choice. Random Play For a USB device, random play can be set by pressing the ‘Random’...
  • Page 28 Instructions Guide DAB/DAB+ Radio Press the ‘Info’ button (Ref.14) repeatedly to show the different programme information. Bit Rate: The data rate which the signal is being transmitted. Bit Error Rate (BER): Provide details of the signal error rate. Channel and Frequency: Displays the station’s transmission channel number and frequency.
  • Page 29 Instructions Guide FM Radio Press the ‘Info/Menu’ button (Ref.14) repeatedly to show the different programme information. Signal Strength: Displays a signal bar with the strength of the current station. Time and Date: Displays the time and the date. Frequency: Displays the station’s transmission frequency. Audio Type: Displays the audio type of the station you are listening to.

  • Page 30: Other Functions

    Instructions Guide Other Functions Manually Setting the Time The time will automatically update after the fist use of DAB Radio. However, you can still set the time manually as follows. Ensure the unit is in standby. Press and hold the ‘Clock’ button (Ref.26) on the remote for a few seconds.
  • Page 31 Instructions Guide Turn off alarm or turn on a preset alarm To turn the alarm off fully, press the ‘Timer’ button (Ref.28) on the remote multiple times and select “Alarm Off”. This will automatically turn the alarm off. To turn on a preset alarm, press the ‘TIMER’ button (Ref.28) on the remote control multiple times and select “Alarm Buzzer/ CD/DAB/FM/USB”.

  • Page 32: Alarm Or Timer Setting

    Instructions Guide Alarm or Timer Setting In Standby, The Setting Timer can be set to automatically turn on and off at certain times and can also be used as an alarm. Press and hold the ‘Timer’ button (Ref.28) on the remote control. The options available will flash on the display.
  • Page 33 Instructions Guide Sleep Setting This enables you to programme the radio to switch off at a specific time, up to 120 minutes from activation. In working mode, Press and the ‘’Sleep’ button (Ref.16) on the remote control. Choose from: Off/15mins/30mins/60mins/90mins or 120mins by pressing the ‘Sleep’...

  • Page 34: Troubleshooting

    Troubleshooting System Reset Press the ‘Menu’ button (Ref.9) on the remote control. Use the ‘Previous’ or ‘Next’ buttons (Ref.10/23) to scroll to “System” and press the ‘Enter’ button (Ref.22) on the remote control. Press the ‘Previous’ or ‘Next’ buttons (Ref.10/23) to scroll to “Factory Reset”, press the ‘Enter’...
  • Page 35 Troubleshooting Troubleshooting If the product does not work properly as desired, please check the following checklist. Minor problems can be easily resolved. Malfunction Possible causes/measures The station is not tuned in. Fine tune the station. The volume is set to a low position. Increase the No sound volume.

  • Page 36: Warranty

    Technical Information Specifications AC 200-240V 50/60Hz Power Supply FM(87.5MHz - 108MHz Mode DAB / DAB+ 174-240MHz 3.5mm Earphone jack Output Connector Integral telescopic aerial Aerial Warranty All products come with a standard 12 month warranty. All items www.majorityradios.co.uk must be registered on for the warranty to be valid.

  • Page 37: Safety Information

    Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 38 www.majorityradios.co.uk...
