Ruckus Wireless
SmartZone
™
Quick Setup Guide for SmartZone 3.5
This Quick Setup Guide provides basic instructions for setting
up the Ruckus Wireless SmartZone 100 (SZ100) on the
network. For information on advanced configuration and
management options, see the SmartZone 100 Getting Started
Guide and SmartZone 100 Administrator Guide, which are
available for download from the Ruckus Wireless Support
website:
https://support.ruckuswireless.com/documents
This Guide in Other Languages
请从以下网站获得该指南的简体中文版
https://support.ruckuswireless.com.
Vous trouverez la version française de ce guide à l'adresse
suivante https://support.ruckuswireless.com.
こ の ガ イ ド の⽇本語版は
https://support.ruckuswireless.com
で ご 覧 く だ さ い。
이 가이드의 한국어 버전은 웹 사이트
(https://support.ruckuswireless.com)
에서 확인하시기 바랍니다 .
Veja a versão em português (Brasil) deste guia em
https://support.ruckuswireless.com.
Puede ver la versión en español (América Latina) de esta guía
en
https://support.ruckuswireless.com.
Licensing Information
The SZ100 comes pre-shipped with 1000 temporary AP
Capacity Licenses, which are valid for a period of 90 days from
when the SZ100 is configured via the initial setup
configuration. For operation beyond 90 days, you MUST buy
permanent AP Capacity licenses. The purchased Licenses
MUST be activated for them to become valid.
The management of the AP Capacity Licenses and the ability
to activate the permanent License will be through the Ruckus
Wireless Support Portal (https://support.ruckuswireless.com).
An email will be sent to the User that is identified on the
Purchase Order and full instructions as to how to activate the
Copyright © 2017 Ruckus Wireless, Inc.
Published March 2017, Part Number 800-71450-001 Rev A
Licenses is included in the email. As a guide, full instructions
can be found at https://support.ruckuswireless.com/activate.
Using the LiMAN (license management) portal on the Ruckus
Wireless Support website, you can assign licenses to or from a
SZ100 or move them to another SZ100 (see a summary of
LiMAN features in
To physically manage the distribution of licenses from the
™
Support website to the actual SZ100, you must connect the
100
SZ100 directly to the Internet. In the event that the SZ100 is
disconnected from the Internet, you can download the actual
licenses from the Support Portal and manually upload to the
specific SZ100.
For step-by-step instructions on how to activate the SZ100's
licenses, see
Table 1. LiMAN features and how to activate them on the SZ100
LiMAN Features SZ100 Online
• Register SZ100
controllers,
licenses, sup-
port entitlement
• Add capacity
licenses to
SZ100 control-
lers
• Remove
licenses from
one SZ100 and
add to another
Before You Begin
Before deploying Ruckus Wireless products, please check for
the latest software and the release documentation.
•
Release Notes and other user documentation are available
at http://support.ruckuswireless.com/documents.
•
Software upgrades are available at
http://support.ruckuswireless.com/software.
•
Open source information is available at
http://opensource.ruckuswireless.com.
•
Software license and limited warranty information are
available at http://support.ruckuswireless.com/warranty.
Package Contents
•
One SmartZone 100 appliance with one AC/DC power
supply unit and power cord
•
One console cable
Table
1).
Step 5: Activate the SZ100's
Licenses.
SZ100 Offline
(Connected to
(Disconnected from the
the Internet)
Internet)
No action
Three steps required:
required. The
1 Download the license file
SZ100 syncs
from LiMAN.
with LiMAN
2 Log on to the SZ100,
automatically
and then upload the
within 24 hours
license file from LiMAN.
and applies the
3 Download the license
appropriate
response file from the
licenses.
SZ100, and then upload
it to LiMAN.
•
One rack mount kit
•
Service Level Agreement/Limited Warranty Statement
sheet
•
Regulatory Statement sheet
•
This Quick Setup Guide
What You Will Need
•
An administrative computer (admin PC) with a connection
to the local area network
•
A web browser, such as Internet Explorer, Mozilla Firefox,
Google Chrome or Apple Safari
•
The IP address, netmask, gateway and DNS server
addresses assigned to the SZ100 —if it has a static
network address (recommended)
Step 1: Connect the SZ100 to the Network
Connect the SZ100 to a convenient power source, and
#1
then press the power switch on the rear panel. The Alarm
LED shows a flashing red light as the SZ100 starts up.
When the SZ100 has started up successfully, the Alarm
LED turns to a solid green light.
Obtain an Ethernet cable. Connect one end of the Ethernet
#2
cable to one of the LAN ports (port 1 or 2 recommended)
on the SZ100, and then connect the other end to your
network's switch or router. DHCP server should be
available in the connected LAN environment for SZ100 to
get the IP address.
NOTE
The SZ100 is a Universal Plug and Play (UPnP) device.
Once you connect it to the network, it will automatically configure
itself, obtain an IP address, and make its presence known to other
devices on the network.
#3
Go to the admin PC and verify that the SZ100 is now
discoverable on the network. On Windows 7 and Windows
8, go to Control Panel > Network and Internet > View
network computers and devices, and then locate the
Network Infrastructure section. The SZ100 should appear
there. In such scenarios, SZ100 and a system (laptop or a
PC) should have cross-over connection and the system
should have an IP address in the same subnet as SZ100.
Configure SZ100 MGMT and CONTROL interface and add
it to the new LAN connection. Use the new IP address to
access SZ100.
Page 1 of 4
