One-Channel Mode Cabling:
Artist I/O Port
1
2
3
4
Two-Channel Mode Cabling:
Artist I/O
1
2
3
4
Note: If the digital partyline connection to the matrix is in two-channel mode, each C44 / C44
plus Artist I/O port must be connected to an odd-numbered CAT-5 port of your matrix client
card (e.g. port 1, 3, 5 or7). The next even-numbered port of your matrix (e.g. 2, 4, 6, or 8)
must be left empty. This even-numbered port will be used for the B channel of your partyline -
no physical connection required!
9.2.2

Director Setup

When the physical connection between the C44 / C44plus system interface and the matrix is
established, start the Director software and establish the connection to the Matrix. Click on
'Network' tab on the left. Double click on the matrix the C44 / C44plus is connected to, to
view the "Port List" of the matrix in the right window.
If not already installed, install the CAT-5 client card in the correct bay by selecting the CAT-5
client card from the 'Card Type' pull down menu. For proper operation of the Performer
partyline with a Riedel matrix intercom system the client card software Version 5107Qxx or
higher is required. ( Director Manual – Client Card Setup)
Once the client card is installed, click on the corresponding client card port where the first
C44 / C44plus Artist port is connected to. Now select in the 'Type' pull down menu the "C3
Digital Beltpack" for this port as the device. The connection between the matrix and the e.g.
line 1 channel A of the digital partyline is now established.
Page 68
PERFORMER Digital Partyline, User Manual, Version 2.30
CAT 5 Client Card Port Partyline
1 Line 1 Channel A
2 Line 2 Channel A
3 Line 3 Channel A
4 Line 4 Channel A
CAT 5 Client Card Port Partyline
1 Line 1 Channel A
2 (leave empty!) Line 1 Channel B
3 Line 2 Channel A
4 (leave empty!) Line 2 Channel B
5 Line 3 Channel A
6 (leave empty!) Line 3 Channel B
7 Line 4 Channel A
8 (leave empty!) Line 4 Channel B
