Appendix B

Error codes, messages and actions

If one of the following error is detected, a message will be presented on the display together
with an error code on the module. In some cases, the module will turn off or at least shut down
the outputs, to increase safety.
The location of the LED indicators on the IQAN-XA2 module.
W
ARNING
Don't use the machine if an error message or error code is activated.
The following sections will present what measures to take for different error situations put into
appropriate context.
LED indicator showing different XA2 modes
Status
Normal operation (yel.)
Error Error
code
3:1 CAN error
3:2 Address error
4:1 a
Memory error
FE Fatal error
a. FRAM memory error.
Instruction book, IQAN-XA2
Yellow/ red, status LED
Green, power on
Flash
Primary Flash (red)
Error category
Error codes, messages and actions
Appendix B
Secondary Flash (yellow)
Error description
31
