Assembly Guide
Panels
4
4
1
6
3
5
1 x
1
Side
1 x
2
Side
1 x
Base
3
2 x
4
Rail
2 x
Support Shelf Rail
5
6
1 x
Oven Support Shelf
7
2 x
Oven Spacer Panel
To protect your kitchen doors from any
excess heat emitted by your oven, it is
strongly recommended that an appropriate
Oven Heat Deflector Kit is fitted around
the oven aperture in this unit. Suitable kits
are available from B&Q and details can be
found in the kitchen price list.
Before you start ...
WArninG: Installation should be performed by a competent person only. This product could
be dangerous if incorrectly installed. All assembly fittings except legs and shelf pegs have
been pre-inserted. If any are missing or there is a problem with the panels, please call the
Helpline on 01769 575500 and our team will get things sorted.
Cleaning – Use mild soap and water only. Do not use abrasive cleaners.
Hardware
4 x
A
22 x
C
2
2 x
d
2 x
e
5
2 x
K
4 x
H
7
6 x
dd
Please use scissors to open the
bag of fittings and then empty
the contents into a bowl, so
that they do not get lost!
Legs
4 x
s
4 x
T
Built Under Oven Housing
Base
Cabinet
minimum Tools required
Cross Head Screwdriver
15mm
Hammer
Drill
25mm
50 mm
30 mm
Level
2 x
u
2 x
V
3mm
5mm
Drill Bit
Drill Bit
Advertisement
Table of Contents
Related Manuals for B&Q 5397007212969
Summary of Contents for B&Q 5397007212969
- Page 1 Built Under Oven Housing Base Assembly Guide Cabinet Panels Hardware minimum Tools required Cross Head Screwdriver 22 x 15mm Hammer Drill 25mm 50 mm Side Side 30 mm Base Rail Drill Bit Drill Bit Please use scissors to open the bag of fittings and then empty Support Shelf Rail the contents into a bowl, so...
- Page 2 Fit panels & to panel Tighten metal cams Fit panel to panels & Screw panel to panel using 3 x screws as shown. Repeat this procedure for panel...
- Page 3 Fit oven filler panel chosen. Position to the face of the cabinet at the bottom. Then affix the filler panel from Ensure panel is level and that the inside using clearance is allowed for oven door screws. above. Fix using 2 x brackets and screws to the inside of the cabinet.
- Page 4 Levelling, Joining & Fitting to Wall All legs are pre-set at 150mm height. Rotate to adjust up and down, to level the unit. Drill a 5mm hole through both side panels. Join together using joining bolts To Fit to wall, drill 3mm pilot hole into side panel of cabinet. Fix 2 x bracket using 2 x screws Wall Fitting not supplied Use appropriate fittings to secure cabinet...
