Fault and Diagnostic Group

F604 [Fault 4 Code]
F605 [Fault 5 Code]
F606 [Fault 6 Code]
F607 [Fault 7 Code]
F608 [Fault 8 Code]
F609 [Fault 9 Code]
F610 [Fault10 Code]
A code that represents a drive fault. The codes appear in these parameters in the order they occur (b007 [Fault 1 Code] = the most recent fault). Repetitive faults are only recorded once.
Values Default:
Min/Max:
Display:
F611 [Fault 1 Time-hr] F612 [Fault 2 Time-hr]
F613 [Fault 3 Time-hr] F614 [Fault 4 Time-hr]
F615 [Fault 5 Time-hr] F616 [Fault 6 Time-hr]
F617 [Fault 7 Time-hr] F618 [Fault 8 Time-hr]
F619 [Fault 9 Time-hr] F620 [Fault10 Time-hr]
Displays the value of d362 [Elapsed Time-hr] when the fault occurs.
Values Default:
Min/Max:
Display:
F621 [Fault 1 Time-min] F622 [Fault 2 Time-min]
F623 [Fault 3 Time-min] F624 [Fault 4 Time-min]
F625 [Fault 5 Time-min] F626 [Fault 6 Time-min]
F627 [Fault 7 Time-min] F628 [Fault 8 Time-min]
F629 [Fault 9 Time-min] F630 [Fault10 Time-min]
Displays the value of d363 [Elapsed Time-min] when the fault occurs.
Values Default:
Min/Max:
Display:
F631 [Fault 1 Freq] F632 [Fault 2 Freq]
F633 [Fault 3 Freq] F634 [Fault 4 Freq]
F635 [Fault 5 Freq] F636 [Fault 6 Freq]
F637 [Fault 7 Freq] F638 [Fault 8 Freq]
F639 [Fault 9 Freq] F640 [Fault10 Freq]
Displays and stores the value of b001 [Output Freq] with the most recent 10 faults occurred.
[Fault 1 Freq] stores the most recent fault, [Fault 2 Freq] stores the second most recent fault and [Fault 3 Freq] stores the third most recent fault.
Values Default:
Min/Max:
Display:
Read Only
F0/F127
F0
Read Only
0/32767 hr
1 hr
Read Only
0.0/320.0 min
0.1 min
Read Only
0.00/500.00 Hz
0.01 Hz
Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Programming and Parameters Chapter 3
Related Parameter(s): b007-b009
Related Parameter(s):
Related Parameter(s):
Related Parameter(s):
d362
d363
b001
119
