No.7(2/2)
Customer
Rocker bushing inside diameter and rocker shaft outside
Item
diameter - measure (2/2)
Measuring location
Measured value
Item
Rocker bushing inside diameter
No.
Direction
a
9
b
a
10
b
a
11
b
a
12
b
a
13
b
a
14
b
a
15
b
a
16
b
Remark
INSPECTION RECORD SHEET
X
Y
Engine Model
Serial No.
Standard
Item to be measured
Rocker bushing
inside diameter
Rocker shaft
outside diameter
Rocker shaft outside diameter
X
Y
Date
Unit
Nominal
Standard
φ36
36.000 to 36.040
[1.42]
[1.4173 to 1.4189]
φ36
35.966 to 35.991
[1.42]
[1.4160 to 1.4170]
Clearance
Maximum
Minimum
Approved by Checked by
SR
mm[in.]
Limit
36.09
[1.4209]
35.940
[1.4150]
Measured by
Advertisement
Chapters
Table of Contents
Need help?
Do you have a question about the S6R Series and is the answer not in the manual?
Questions and answers
how to check the rotation detection pickup the MPU for the speed control what is the gap
To check the rotation detection pickup gap for the MPU in a Mitsubishi S6R Series engine:
1. Turn the crankshaft to move the ring gear teeth to the centerline of the pickup installing hole.
2. Insert the pickup into the hole slowly and carefully by hand.
3. When the tip of the pickup contacts the ring gear tooth top, loosen the pickup to adjust the clearance to the standard value.
4. Fix the pickup in place using a lock nut.
5. Ensure the correct gap by verifying that the clearance is within the specified limit (typically around 0.45 mm).
This procedure ensures accurate rotation detection.
