Hollis Explorer User Manual page 27

During Pre-dive additional information will be displayed on each Pre-dive
screen such as the PO and internal loop pressure (Fig. 3.5).
2
Your Hollis dealer may need access to this information to help with any
issues. Please see the separate EXPLORER Service Manual for details.
STATUS SCREEN COLORS
There are four color states of the STATUS screen. Each color provides
additional information. The four color states are:
Green - No problem with the information
Yellow - The system is informing you of a low level alarm such as low
HP gas supply. The STATUS Screen's Action Panel will give information
regarding the warning or action to be taken and in the case of the low HP
gas example, the value in the HP window will also be in yellow. This will
result in a flashing Green/Blue HUD
Magenta - indicates unreliable data on the reading being taken. This could
be caused by a failed sensor (such as a low wireless HP battery). This will
be coupled with an action to be taken displayed on the STATUS Screen's
Action Panel. This will result in a flashing green/blue or red.
Red - A major alarm Indicating that information/resource has now become
critical forcing, an open circuit bailout. OC Bailout will be displayed on the
STATUS Screen's Action Panel and the HUD will flash red and a vibrating
alarm will sound in the mouthpiece
From the Main Dive Screen a double press of the right button will bring up
the STATUS screen (Fig. 3.6) so that the user can determine at a glance
the status of the system while doing a check. This can be useful to deter-
mine why a check is not working correctly.
Fig. 3.5
Fig. 3.6
| 21
